Stamina Studio Tower Combination Unit Owner's Manual
  1. Manuals
  2. Brands
  3. Stamina Manuals
  4. Fitness Equipment
  5. Studio Tower Combination Unit
  6. Owner's manual
Stamina Studio Tower Combination Unit Owner's Manual

Stamina Studio Tower Combination Unit Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAUTION:
Weight on this product should not exceed 250 lbs.
2008, 03
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 (800) 375-7520
www.staminaproducts.com
Owner's
Manual
WARNING
Exercise can present a health
risk. Consult a physician
before beginning any exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Follow all safety instructions in
this manual.
When calling for parts or
service, please specify the
following number.
20-1200
Patent(s) pending
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2008 Stamina Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Studio Tower Combination Unit and is the answer not in the manual?

Questions and answers

Related Manuals for Stamina Studio Tower Combination Unit

Summary of Contents for Stamina Studio Tower Combination Unit

  • Page 1 Weight on this product should not exceed 250 lbs. Product May Vary Slightly From Pictured. This Product is Produced Exclusively by 2040 N. Alliance, Springfield, MO 65803 Customer Service Number 1 (800) 375-7520 www.staminaproducts.com 2008, 03 2008 Stamina Products, Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Page Safety Instructions Operational Instructions Before You Begin Storage Equipment Warning & Notice Labels Warranty Hardware Identification Chart Product Parts Drawing Assembly Instructions Parts List Maintenance Fax/Mail Ordering Form SAFETY INSTRUCTIONS WARNING: To reduce the risk of serious injury, read the following Safety Instructions before using the Studio Tower .
  • Page 3 Monday - Thursday, 7:30 A.M. - 5:00 P.M. Central Time. Friday, 8:00 A.M. - 3:00 P.M. Central Time. TELEPHONE ONLINE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. Tel: 1 (800) 375-7520 Fax: (417) 889-8064 parts@staminaproducts.com ATTN: Customer Service cust-srvc@staminaproducts.com P.O. Box 1071 www.staminaproducts.com...

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Studio Tower . We Although Stamina constructs its products with the take great pride in producing this quality product and finest materials and uses the highest standards of hope it will provide many hours of quality exercise to...

  • Page 5: Equipment Warning & Notice Labels

    EQUIPMENT WARNING & NOTICE LABELS This chart is provided to help identify the warning & notice labels on the Studio Tower . Please take a moment to familiarize yourself with all of the warning & notice labels. Label is larger than actual size WARNING LABEL(63)

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers, the ends of the bolts, or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Attach the WOODEN BARRE(13) to the LEFT and RIGHT SLIDERS(8, 10) with BUTTON HEAD BOLTS (M8x1.25x55mm)(49), LOCK WASHERS(M8)(62), and ACORN NUTS(M8x1.25)(55). Do not tighten the bolts until STEP 5. STEP 4 Note the correct position of the holes and EYEBOLTS(23) on the TOP BEAM(22) in the illustration above. Insert the TOP BEAM(22) into the LEFT and RIGHT UPRIGHTS(7, 9) and secure with the SECURING KNOBS(25).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 7 STEP 8 STEP 7 Refer to illustration step 7. Place the MAIN FRAME(1) with the cushion side face down. Attach the EXTENSION FRAME(5) to the MAIN FRAME(1) with BUTTON HEAD BOLTS(M8x1.25x55mm)(48), WASHERS(M8)(59), and NYLOCK NUTS(M8x1.25)(56). STEP 8 Refer to illustration step 8.

  • Page 10: Maintenance

    Check the FOAM SLEEVE(29), and SPRING SLEEVE(33) and replace if damaged or worn. Check the CUSHIONS(2, 4, 6) and replace if it is damaged or worn. Only Stamina Products supplied components shall be used to maintain/repair the Studio Tower . Keep your Studio Tower clean by wiping with an absorbent cloth after use.
  • Page 11 OPERATIONAL INSTRUCTIONS SET-UP FOR THE PUSH-THRU BAR NOTE: a. There are three adjustment holes in the LEFT and RIGHT UPRIGHTS(7, 9) that allow you to attach the PUSH-THRU BAR(26) at one of three different heights. Refer to the inset drawing. Push down the button on the "T" end of the LOCKING PIN(30) to release the steel ball on the other end of the pin.
  • Page 12 OPERATIONAL INSTRUCTIONS TO USE THE ACCESSORIES: PUSH-THRU BAR(26) When doing exercises that require the spring resistance to come from above the bar, attach the PUSH- THRU SPRING(34) to the loop on the upper side of the PUSH-THRU BAR(26) with the DOUBLE ENDED CLIP(38).
  • Page 13 OPERATIONAL INSTRUCTIONS TO USE THE ACCESSORIES: (continued) SAFETY STRAP(37) Refer to the illustration. The SAFETY STRAP(37) must be used as follows: When using the PUSH-THRU BAR(26) with the PUSH-THRU Loop SPRING(34) attached from below for bottom load exercises, attach the SAFETY STRAP(37) to another side of the tower from the spring.

  • Page 14: Storage

    STORAGE Store the Studio Tower in a clean, dry place. WARNING: When folding or unfolding the Studio Tower , keep all children away from the Studio Tower and make sure your hands are clear of any folding or pinch point. Follow these steps and refer to the illustration to fold the Studio Tower for easy storage.

  • Page 15: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071 or call us at 1 (800) 375-7520. If the defect is covered under this limited warranty, you will be requested to return the product or part to us for free repair or replacement at our option.

  • Page 16: Product Parts Drawing

    PRODUCT PARTS DRAWING BACK FRONT...

  • Page 17: Parts List

    PARTS LIST DIAGRAM# PART NAME Main Frame Main Cushion Base Frame Base Cushion Extension Frame Extension Cushion Left Upright Left Slider Right Upright Right Slider Slider Bushing Spring Pin Wooden Barre Inner Cover Outer Cover Wheel Cap Base Stand Round Stand Locking Knob Handle Strap Hand Strap...
  • Page 18 PARTS LIST DIAGRAM# PART NAME Bolt, Button Head (M8 x 1.25 x 55mm) Bolt, Button Head (M8 x 1.25 x 60mm) Bolt, Button Head (M8 x 1.25 x 70mm) Bolt, Hex Head (M6 x 1 x 20mm) Bolt, Hex Head (M6 x 1 x 55mm) Bolt, Flat Head (M6 x 1 x 15mm) Acorn Nut (M6 x 1) Acorn Nut (M8 x 1.25)

  • Page 19: Fax/Mail Ordering Form

    FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina has a Customer Service Department with a toll-free number. Should a part be missing or a defective part found, please call 1 (800) 375-7520 (in the U.S.) from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M. to 3:00 P.M.
