Telemark Cryogenics 1200 Instruction Manual page 5

Telemark Cryogenics Microprocessor Based Cryochillers
LIST OF FIGURES/ILLUSTRATIONS
Figures
1 Removing Unit from Transport Pallet
2 System Pressure Gauge
3 Services Panel
4 Water Flow requirements
5 Position of Hand Valves
6 Refrigerant Line Connections
7 Access Hand Valve
8 Refrigerant Manifold
9 Refrigerant Line Insulation
10 Metal "O" Ring Removal Tool
11 Main Isolator Wiring
12 Transformer Tapings
13 37 Way Amp Connector
14 Ethernet cable (crossed)
15 Network Connection Window
16 Network Properties
17 TCP/IP
18 TCP/IP Settings
19 TCP/IP GUI
20 Ethernet TCP/IP & RS232/485 Help
21 "cal2309" Setup Screen
22 Front Panel Push Buttons
23 Wait Start LCD Display
24 Pre-Cool LCD Display
25 Standby LCD Display
26 Cool LCD Display
27 Over Pressure Alarm LCD Display
28 DP High LCD Display
29 Emerson Compressor Front Panel
30 Emerson Compressor Internal Parts
Page 5 of 63
Page
18
18
19
20
21
21
22
22
24
25
26
27
30
32
33
33
34
34
36
38
39
42
42
43
43
43
48
48
54
54
Revision 1.0.7 October 2018
