ADC OmniReach MDU Rapid Fiber System Specification Sheet page 5

Rapid MDU Collector Enclosure
ADC's OmniReach
Enclosure serves as zoned, intermediate
distribution points within the MDU for designs
using MT cable stubs instead of splices. Each
enclosure is wall mounted within the MDU
building and accommodates up to six MT pairs
and ships with 72-fiber riser ribbon stubs.
Features and Benefits:
• Accommodates up to 6 MT mated pairs
• Ships with 72-fiber riser ribbon stubs
• Slotted foam grommet provides easy drop
installs while maintaining seal
• Same mounting pattern as the Fiber
Distribution Terminal
Specifications
Fibers:
Cable Ports:
Jumper Ports:
Rating:
Dimensions (HxWxD):
Ordering Information
Fiber Count
72 72 fiber
Cable Type
A Indoor/outdoor ribbon
B Riser ribbon
C Plenum ribbon
Length
A 50'
B 100'
w w w . a d c . c o m
Rapid MDU Collector
®
72
1 Top and Bottom
1 Top and Bottom
NEMA-12
6.0" x 9.0" x 2.5"
Catalog Number
MCA-S __ __ __ 1 __ __ __
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Rapid MDU Collector Enclosure
(open)
Enclosure Type
A 6 MT indoor enclosure
Stubbed End Configuration
0 Stub (no connector)
Enclosure End Configuration
M 12F MT's with enclosure
0 Stub (no connector)
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1 5
