User's Manual
8. Allow at least 1-1/2 inches clearance behind the unit for electri-
cal and water supply connections.
It is important that the unit, primarily the ice maker assembly, is level.
All 75 and 15 Series units are equipped with adjustable feet for level-
ing and height adjustment (see Figure 9). All other units have rubber
feet.
Model SP18 Icemakers come with the grill already installed.
1. With a standard blade screwdriver (or 1/4" nutdriver), remove
the screw needed to attach the grill (see Figure 10).
2. Remove the control knob by pulling it toward you.
3. Carefully remove the grill from inside the unit. A small screw hole
is located toward the top of the middle recessed section of the
grill.
LEVELING THE UNIT
TURN FOOT TO ADJUST
Figure 9
GRILL INSTALLATION
NOTE
8
UL105
