4. Model 29AD only - The auto-
matic defrost timer, located
behind the front grill, must
be set whenever the refrig-
erator is put into operation.
To set the defrost timer,
proceed as follows (see
Figure 32):
• Observe the time of day.
• Set the defrost timer screw
with a flat-blade screwdriver
to the number on the timer
dial which corresponds to
the time the refrigerator
was plugged in. Turn the
adjustment dial only in the
CLOCKWISE direction.
For example, if the refrigerator
was started at 10:00 AM set the timer screw to 10 AM. Or, if it was
started at 4:00 PM, set the screw to 4 PM.
The defrost timer will automatically defrost the refrigerator between
midnight and 3:30 AM each night.
In the event of an extended power outage or when the
refrigerator has been unplugged, RESET the current time
on the defrost timer.
TIMER MUST BE SET TO THE CORRECT
TIME OF DAY. IN THE EVENT OF AN
EXTENDED POWER OUTAGE RESET TIMER.
12
10
8
6
4
6:00 PM IS SHOWN HERE
12
10
8
6
PM
4
Figure 32
21
12
2
4
6
8
2 12 10
12
2
4
6
AM
8
2 12 10
