U-Line ICE-MAKER/REFRIGERATOR User Manual page 19

Install the insert as follows:
Insert edges may be SHARP! Use care when installing.
1. Remove top hinge screw pin (large Phillips head, see Figure 25).
Hold door to keep it from falling.
2. Remove door, being careful not to scratch top of door on hinge.
3. Remove two small screws holding door handle. Slightly separate
door handle from door (see Figure 26).
Figure 25
4. Pull door gasket out of
groove (top edge of door
only). Start in the middle and
pull outwards,
towards the edge (see Figure
27). This may take some
force.
5. Pull handle up and off.
!
WARNING
UL131
moving
17
Figure 26
Figure 27
UL132
UL117
