Bluetooth Connection Manual
THERMAL LABEL PRINTER
Ver. 1.01
http://www.bixolon.co.kr
TX Series
DX Series
DL Series
XD Series
XL Series
XT Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON TX Series

Summary of Contents for BIXOLON TX Series

  • Page 1 Bluetooth Connection Manual THERMAL LABEL PRINTER Ver. 1.01 TX Series DX Series DL Series XD Series XL Series XT Series http://www.bixolon.co.kr...

  • Page 2: Table Of Contents

    Bluetooth Connection Manual ■ Table of Contents 1. Manual Information ......................3 2. Precaitions ........................3 3. Bluetooth Connection Instructions ................4 3-1 PIN Code Paring Instruction ..................4 3-2 Just Works Paring Instruction ..................8 3-3 Numeric Comparison Paring Instruction ..............10 3-4 Passkey Entry Paring Instruction ................

  • Page 3: Manual Information

    This Bluetooth Connection Manual provides information on the connection of Bluetooth- enabled iOS or Android Host devices with the printer. We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.

  • Page 4: Bluetooth Connection Instructions

    Bluetooth Connection Manual 3. Bluetooth Connection Instructions This manual focuses on the use of the following Host devices. For other Host devices, please refer to the relevant Host device manual. 3-1 PIN Code Paring Instruction Use Pin Code for verification(Legacy Pairing) instead of SSP. 3-1-1 iOS Mode 2) Select “Bluetooth”.
  • Page 5 Bluetooth Connection Manual 3) Select the printer to connect. 4) Enter Pin Code. (default: 0000). 5) Select “Pair”. 6) Bluetooth communication is available. - 5 - Ver. 1.01...
  • Page 6 Bluetooth Connection Manual 3-1-2 Android Mode 2) Select “Bluetooth”. 1) Select the icon. 3) Select the printer to connect. 4) Enter Pin Code. (default: 0000) - 6 - Ver. 1.01...
  • Page 7 Bluetooth Connection Manual 5) Select “OK”. 6) Bluetooth communication is available. - 7 - Ver. 1.01...

  • Page 8: Just Works Paring Instruction

    Bluetooth Connection Manual 3-2 Just Works Paring Instruction Designed for situation where one (or both) of the pairing Host device has neither a display nor keyboard for entering digits (e.g. Bluetooth headset). it does not verify any for pairing. 3-2-1 iOS Mode 2) Select “Bluetooth”.
  • Page 9 Bluetooth Connection Manual 3-2-2 Android Mode 2) Select “Bluetooth”. 1) Select the icon. 3) Select the printer to connect. 4) Bluetooth communication is available. - 9 - Ver. 1.01...

  • Page 10: Numeric Comparison Paring Instruction

    Bluetooth Connection Manual 3-3 Numeric Comparison Paring Instruction Numeric Comparison : Designed for situation where Host device and printer are capable of displaying a six-digit number and allowing user to enter “yes” or “no” response for pairing. *This function is supported on LCD model only. 3-3-1 iOS Mode 2) Select “Bluetooth”.
  • Page 11 Bluetooth Connection Manual 6) Press the ‘Pair’ button, if two codes 5) Confirm the code displayed on Printer are matched. XT Series XD/XL Series 7) Press the ‘Ok’ button, if two codes are matched. 8) Bluetooth communication is available. XT Series XD/XL Series - 11 - Ver.
  • Page 12 Bluetooth Connection Manual 3-3-2 Android Mode icon. 2) Select “Bluetooth”. 1) Select the 3) Select the printer to connect. 4) Check the code on the Host device. (6 characters long) - 12 - Ver. 1.01...
  • Page 13 Bluetooth Connection Manual 6) Press the ‘OK’ button, if two codes 5) Confirm the code displayed on Printer are matched. XT Series XD/XL Series 7) Press the ‘Ok’ button, if two codes are matched. 8) Bluetooth communication is available. XT Series XD/XL Series - 13 - Ver.

  • Page 14: Passkey Entry Paring Instruction

    Bluetooth Connection Manual 3-4 Passkey Entry Paring Instruction Designed for situation where Host device and printer are capable of displaying a six-digit number and allowing user to enter digits to verify and pairing. *This function is supported on LCD model only. 3-4-1 iOS Mode icon.
  • Page 15 Bluetooth Connection Manual 6) Press the ‘Select’ or ‘Ok’ button 5) Enter six-digit code. (6 characters long) XT Series XT Series XD/XL Series XD/XL Series 7) Bluetooth communication is available. - 15 - Ver. 1.01...
  • Page 16 Bluetooth Connection Manual 3-4-2 Android Mode icon. 2) Select “Bluetooth”. 1) Select the 3) Select the printer to connect. 4) Check the code on the Host device. (6 characters long) - 16 - Ver. 1.01...
  • Page 17 Bluetooth Connection Manual 6) Press the ‘Select’ or ‘Ok’ button 5) Enter six-digit code. (6 characters long) XT Series XT Series XD/XL Series XD/XL Series 7) Bluetooth communication is available. - 17 - Ver. 1.01...

  • Page 18: Bluetooth Setting Instruction

    4. Bluetooth Setting Instruction 1) Bluetooth setting is available through Unified Label Utility. ※ Latest file versions can be downloaded from the BIXOLON website. (www.bixolon.com) Please refer Software manual of Unified Label Utility Manual for more information. 2) Connect the interface cable between the printer and the PC.
  • Page 19 Bluetooth Connection Manual 5) Click the “Configure Printer Setting” button. 6) Click the “Interface” tab. 7) Select the checkbox of the interface to be configured between serial and Bluetooth. 8) Click the “Get” button and check the printer settings. 9) After setting the desired functions, click the “Set” button to store settings. - 19 - Ver.
  • Page 20 Bluetooth Connection Manual 10) Setting Menu Explanation List Explanation Explanation Device Name Name of Bluetooth device Explanation Setting Bluetooth authentication and encryption function Default Value Enable Encryption (Authentication Variable Value &Encryption) 1) Enable : Use authentication and encryption for Bluetooth connections and data transfer 2) Disable : Use not authentication and encryption for Bluetooth connection and data transfer...
  • Page 21 Bluetooth Connection Manual Explanation Secure simple pairing Default Value Disable Variable Value 1) Disable : Use Pin Code for verification(Legacy Pairing) instead of SSP. 2) Just Works : Designed for situation where one (or both) of the pairing Host device and printer has neither a display nor (Secure simple keyboard for entering digits (e.g.

  • Page 22: Troubleshooting

    Bluetooth Connection Manual 5. Troubleshooting Please follow the guide below if Bluetooth is not searched on iOS or Android Host device. 1) Check whether printer is connected to other Bluetooth Host device. - Printer is not able to be found on your iOS or android Host device if it is connected to other Bluetooth Host device.
  • Page 23 BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product. BIXOLON is not responsible for any direct or indirect damages, arising from or related to use of this information.
  • Page 24 Bluetooth Connection Manual Revision history Rev. Date Page Description 1.00 07.12.15 4~17 Bluetooth Connection Instructions (PIN Code, Just Works, Numeric Comparison, Passkey 1.01 07.01.20 Entry) added 18~21 Bluetooth setting Instruction added Troubleshooting revised - 24 - Ver. 1.01...
