Anti-skating force adjustment

The anti-skating mechanism is shipped partially disassembled to avoid damage during transport. For
correct installation, please follow the steps below.
Step 1:
Prepare anti-skating sliding mechanism from the accessories bag.
The anti-skating sliding mechanism is supplied with a pre-mounted anti-skating weight and thread for
mounting on the tonearm.
Step 2:
Put the eye of the anti-skating thread around the hole for the HOOK SCREW and screw the HOOK
SCREW into the tonearm through the eye of the anti-skating thread as shown in the illustration below.
Step 3:
Put the anti-skating sliding mechanism on the end of the anti-skating support rod. The anti-skating
thread should fit into the groove in the tonearm.
Be careful when handing the anti-skating thread in order to avoid damaging it.
