- Page 1 7649‐K454 Rear Customer LCD Hinge Assembly Kit Instructions Issue A...
- Page 2 Revision Record Issue Date Remarks Nov 2011 First Issue...
- Page 3 Introduction This kit provides a mount for integrating an LCD Customer Display on the NCR 7649 terminal. The following LCD models are supported. • NCR 5943 12” LCD • NCR 5982 6.5” LCD The following feature is also required to be present in the terminal. • 7649‐K021: Extended I/O Daughter Card (provides three additional 12 V Powered USB ports) Kit Contents There are three display cables included. Usage is display dependent. Screw, 6-32 x 5/16, Phil, PH (5982) 007-7000205 Screw, M4x10, Phil, PH (5943) 006-8608196 Swivel Mount 497-0443228 Customer Display rew, 6-32 x 0.375, Phil, PH, Ext Washer...
- Page 4 Installation Procedures 1. Remove the Filler Plug from the hole in the rear of the terminal chassis. Filler Plug...
- Page 5 2. Remove the Rear Cover. a. Press UP on the two latches on the bottom of the unit to release the cover from the chassis. Rear Cover Rear Cover Latches 30356 b. Pivot the bottom of the cover out as shown to remove it. 30357...
- Page 6 3. Install the Swivel Mount on the back of the LCD (4 screws). Be careful to use the correct screws (see Kit Contents section). Swivel Mount 30379 4. Install the Customer Display Integration Pole onto the LCD Swivel Mount. Customer Display Integration Pole 30585...
- Page 7 5. Align hole in the pole with the slot in the Swivel Mount. 6. Insert the Dome Plug into the hole in the pole. The plug locks the plastic components together and provides display rotation limitations. 30388 Dome Plug 7. Install the Customer Display Pole Support in the hole in the terminal cabinet. 8. Install the Customer Display Assembly into the terminal. Customer Display Pole Support 30389...
- Page 8 9. Connect the cables. 5943 Display: • Connect the Powered USB Cable to the 12V USB connectors on the terminal and display. • Connect the VGA Cable to the VGA connectors on the terminal and display. 12V USB 30581 5982 Display: • Connect the Powered USB to DC Cable to the 12V USB connector on the terminal and to the Power connector on the display. • Connect the VGA Cable to the VGA connectors on the terminal and display. Power 30582 VGA Port 12 V USB Ports 30381 10. Replce the Rear Cover.
