B.A EAGLE
Glow and EP
ALL BALSA - PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER.
95% ALMOST READY TO FLY
SPECIFICATION
- Wingspan: 1,790mm (70.47 in).
- Length: 1,340 mm (52.76 in).
- Weight: 4 kg (8.8 lbs).
- Wing area: 45.7 dm
- Wing loading: 87.53 g/dm
- Wing type: Naca Airfoils.
- Gear type: Oleo struts (included).
- Spinner : 58mm.
- Servo mount: 42mm x 21mm.
Instruction Manual Book
Parts listing required (not included):
- Radio: 05 channels.
- Servo: 07 servos.
- Engine: .46 - .55ci 2 stroke/ 9cc 2 stroke Gas
.
2
- Motor: Brushless outrunner 1000-1800W, 400-800kV
.
2
- Propeller: Suit with your engine.
Recommended Motor and Battery set up
(not included):
- Motor: Admiral GP10 5030-400kV
- Lipo cell: 6 cells 4,000-5,000mAh.
- Receiver battery: 4.8- 6V/ 800 - 1200mAh NiMH.
- ESC: 65A
Item code: BH158
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B.A. EAGLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Horse Model B.A. EAGLE

Summary of Contents for Black Horse Model B.A. EAGLE

  • Page 1 Instruction Manual Book Item code: BH158 B.A EAGLE Glow and EP ALL BALSA - PLY WOOD CONSTRUCTION. COVERED WITH ORACOVER. 95% ALMOST READY TO FLY SPECIFICATION Parts listing required (not included): - Wingspan: 1,790mm (70.47 in). - Radio: 05 channels. - Length: 1,340 mm (52.76 in).

  • Page 2: Table Of Contents

    Thank you for purchasing Black Horse Model products. With over 19 years experience in production and fly testing, Black Horse Model is committed to bring the best quality products and good service to customers. Along with a team of creative engineers and skilled workers, we will always accompany with customers by our great experiences, fully enthusiasm...

  • Page 3: Warranty

    In that Black Horse Model has no control over the final assembly or material used for final assembly, SUGGESTION Black Horse Model is not responsible for loss of use , or other incidental or consequential damages. To avoid scratching your new airplane, do not...

  • Page 4: Covering Tools

    B.A Eagle Item code: BH158 Instruction Manual FLIGHT WARNINGS ADHESIVES AND REQUIRED TOOLS When ready to fly, first extend the transmitter aerial. Thin CA Switch on the transmitter. 30-minute epoxy Switch on the receiver. 6-minute epoxy Check that the wings are correctly fitted to the Threadlocker thread locking cement fuselage.
  • Page 5 B.A Eagle Item code: BH158 Instruction Manual • Officially designated AMA Air Show Teams (AST) are authorized to use devices and practices as defined within the Team AMA Program Document. (AMA Document #718.) (j) Not operate a turbine-powered aircraft, unless in compliance with the AMA turbine regulations. (AMA Document #510-A.) 3.

  • Page 6: Part Listing ( Not Included )

    B.A Eagle Item code: BH158 Instruction Manual PARTS LISTING (NOT INCLUDED). Servo extension leads....pcs. 320mm ..2pcs Engine: 15cc Gas. NGH GT17 recommended Propeller: Suit with your engine. LiPo. 6S 4000-5000mAh ..1 Packs Motor: Admiral GP10 Servos size: (39.9 x 20.1 x 38.1)mm. Torque: 4.8V (7.92kg/cm), 6V(9.43 kg/cm)...7pcs ESC: 85A ..
  • Page 7 B.A Eagle Item code: BH158 Instruction Manual Fuselage - - - 1 Wing panel (2a, 2b) Horizontal stabilizer 58mm Rudder - - - 1 Auminium tube Top hatch fuselage (6a Pilot, 6b Canopy, 6c Cockpit ) 3x12mm Tp Screw - - - 2 Fuel tank (7a Clunk,7b Stopper (three line)) Tail gear set Cowling...

  • Page 8: Preparations

    B.A Eagle Item code: BH158 Instruction Manual PREPARATIONS: Use a covering iron with a cover- ing sock on high heat to tighten the covering if necessary. Apply pressure over sheeted areas to thoroughly bond the covering to the wood. INSTALLING THE AILERONS AND FLAPS. <Bottom view>...

  • Page 9: Installing The Ailerons And Aps Servos

    B.A Eagle Item code: BH158 Instruction Manual <Bottom view> INSTALLING THE AILERONS AND FLAPS SERVOS. Place the servo into the servo tray. Center the servo within the tray and drill 1.5mm pilot holes through the block of wood for each of the four mounting screws provided with the servo. Using the thread as a guide and using masking tape, tape the servo lead to the end of the thread: carefully pull the thread out.
  • Page 10 B.A Eagle Item code: BH158 Instruction Manual Aileron Aileron servos. 2 mm approx.16mm 2x10mm Screw 1.5 mm For Aileron. For Aileron. Flap. Screw 2 m m 1.5 mm 1.5 mm <Bottom view> 2x10mm Tp Screw - - - - 16 2x10mm Tp Screw For Aileron.

  • Page 11: Installing The Control Horns And Linkages

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE CONTROL HORNS AND LINKAGES. Nylon Clevis - - - - - - - - - - - 4 1.7 x 100mm Push rod - - - - 4 Horn Horn - - - - - - - - - - - - 4 Flaslink - - - - - - - - - - - - - - 4 1.7x8mm Cap Screw...
  • Page 12 B.A Eagle Item code: BH158 Instruction Manual Pushrod Nylon Clevis Bend 90 Horn Pushrod Flaslink 1.7x8mm Cap Screw The number of times Cut off excess. the same way Assembly (in this case twice).

  • Page 13: Installing The Main Gear

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE MAIN GEAR. 4x15mm Cap Screw Collar - - - - - - - 8 - - - - - - - - - - - - - 4 4mm Spring Washer 6x55mm Socket Head - - - - - - - - - - 8 Cap Screw...
  • Page 14 B.A Eagle Item code: BH158 Instruction Manual <Bottom view> 2.5mm 2.5mm Apply instant glue Drill holes using the stated. (C.A glue, super glue). (in this case 1.5mm 1.5mm...
  • Page 15 B.A Eagle Item code: BH158 Instruction Manual <Bottom view> Cut off shaded portion carefully. Apply instant glue Assemble left and right (C.A glue, super glue). sides the same way.
  • Page 16 B.A Eagle Item code: BH158 Instruction Manual <Bottom view> Assemble left and right sides the same way.

  • Page 17: Installing The Fuselage Servos

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE FUSELAGE SERVOS 1) Install the rubber grommets and brass collets into the elevator, rudder and throttle servos. Test fit the servos into the servo tray. Trim the tray if necessary to fit your servos.

  • Page 18: Installing The Wing To The Fuselage

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE WING TO THE FUSELAGE Test t the aluminium tube dihedral brace into each wing haft. 19x455mm Aluminium tube. The brace should slide in easily. If not, use 220 grit sand around the edges and ends of the brace until it ts properly.

  • Page 19: Installing Horizontal Stabilizer

    B.A Eagle Item code: BH158 Instruction Manual Main wing must be inserted and attached completely before xing with screw. INSTALLING HORIZONTAL STABILIZER <Top view> Horn - - - - - - - - - - 2 Nylon Clevis - - - - - - - 2 1.7 x 800mm Push rod - - - - 2 Flaslink...
  • Page 20 B.A Eagle Item code: BH158 Instruction Manual Apply drops of thin CA to the top and bottom of Test fit the ailerons to the wing with the hinges. If each hinge. Do not use CA accelerator. After the CA the hinges don’t remain centered, stick a pin through the middle of the hinge to hold it in position.
  • Page 21 B.A Eagle Item code: BH158 Instruction Manual <Top view> <Bottom view> Horn The number of times Apply epoxy glue. Cut off shaded portion the same way Assembly (in this case twice).
  • Page 22 B.A Eagle Item code: BH158 Instruction Manual <Bottom view> Horn Pushrod Nylon Clevis 1.7x8mm Cap Screw Throttle Servo Rudder Servo Rudder Servo Servo arm Flaslink Push rod Bend 90º The number of times Cut off excess. the same way Assembly (in this case twice).

  • Page 23: Installing The Tail Gear, Rudder

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE TAIL GEAR, RUDDER <Bottom view> 4mm Wheel Colar - - - - - - - - 2 3x15 Tp screw - - - - - - - - 2 2.5mm 3x15mm Tp Screw 4mm Wheel Colar Drill holes using the stated.
  • Page 24 B.A Eagle Item code: BH158 Instruction Manual <Bottom view> Secure <Top view> Nylon Clevis - - - - - - - 1 1.7 x 800mm Push rod - - 1 - - - - - - - 1 Horn Flaslink - - - - - - - - - - 1 Rudder Cut off shaded portion...
  • Page 25 B.A Eagle Item code: BH158 Instruction Manual <Top view> Horn Horn Pushrod Nylon Clevis 1.7x8mm Cap Screw Cut off shaded portion Apply epoxy glue. carefully.

  • Page 26: Installing The Engine

    B.A Eagle Item code: BH158 Instruction Manual Servo arm Flaslink Push rod Bend 90º Throttle Servo Rudder Servo Rudder Servo INSTALLING THE ENGINE 3mm Hex Nut 500mm Pushrod wire - - - 1 - - - - - - - 4 Size: 46 M4 Blind Nut 3x25mm Cap Screw...
  • Page 27 B.A Eagle Item code: BH158 Instruction Manual <Fuselage top view> M4 Blind Nut Apply threadlocker (screw cement).

  • Page 28: Installing The Stopper

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE STOPPER...

  • Page 29: Installing The Fuel Tank

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE FUEL TANK 5. When satisfied with the alignment of the stopper assembly tighten the 3mm x 20mm machine screw until the rubber stopper expands and 1. Using a modeling knife, cut one length of silicon seals the tank opening.

  • Page 30: Installing The Throttle

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE THROTTLE direction. When the throttle stick is moved forward from idle to full throttle, the throttle barrel should also open and close using this motion. If not, - - - - - - 1 Connector reverse the direction of the servo, using the transmitter.

  • Page 31: Mounting The Cowl

    B.A Eagle Item code: BH158 Instruction Manual MOUNTING THE COWL While holding the cowl firmly in position, 1) Remove the muf f ler and needle valve assembly drill four 1,6mm pilot holes through both the from the engine. Slide the fiberglass cowl over the cowl and the side edges of the firewall.

  • Page 32: Installing The Switch, Receiver And Battery

    B.A Eagle Item code: BH158 Instruction Manual <Fuselage top view> 3x12mm Tp Screw INSTALLING THE SWITCH, RECEIVER AND BATTERY INSTALLING THE SWITCH 1) Plug the servo leads and the switch lead into the receiver. You may want to plug an aileron extension 1) The switch should be mounted on the fuselage into the receiver to make plugging in the aileron servo side, opposite the muffler, close enough to the...

  • Page 33: Installing The Electric Motor (Ep Version)

    B.A Eagle Item code: BH158 Instruction Manual <Fuselage top view> Switch Switch Battery INSTALLING THE ELECTRIC MOTOR (EP VERSION) 10x50mm Plastic 4x20mm Socket Head 4mm Flat washer - - - - - 4 - - - - - - - - 4 Cap Screw - - 4 10x5mm Plastic...

  • Page 34: Installing Cockpit Fuselage

    B.A Eagle Item code: BH158 Instruction Manual <Fuselage top view> Battery Battery INSTALLING COCKPIT FUSELAGE...
  • Page 35 B.A Eagle Item code: BH158 Instruction Manual...

  • Page 36: Installing The Propeller

    B.A Eagle Item code: BH158 Instruction Manual INSTALLING THE SPINNER, PROPELLER 3x12mm Tp Screw - - - 2 - - - 1 58mm - - - 1 Must be purchased separately!
  • Page 37 B.A Eagle Item code: BH158 Instruction Manual...

  • Page 38: Balancing

    B.A Eagle Item code: BH158 Instruction Manual BALANCING If one side of the wing fall, that side is heavier than the opposite. Add small amounts of lead weight to the bottom side of the lighter wing half's It is critical that your airplane be balanced wing tip.

  • Page 39: For Your Radio Installation Basic Connection For Airplane And Adjustment Of Servos

    B.A Eagle Item code: BH158 Instruction Manual FOR YOUR RADIO INSTALLATION BASIC CONNECTION FOR AIRPLANE AND ADJUSTMENT OF SERVOS Example of connection For more information, refer to radio system instruction manual. Follow instruction manual of Engine and Battery. Aileron Servo Aileron Engine Aileron Servo...

  • Page 40: Main Gear Dimensional Detail

    B.A Eagle Item code: BH158 Instruction Manual MAIN GEAR DIMENSIONAL DETAIL 31mm TAIL GEAR DIMENSIONAL DETAIL 28mm Wheel 35mm...

  • Page 41: Exploded View

    B.A Eagle Item code: BH158 Instruction Manual DECORATION <Top view> <Bottom view> <Side view> Left <Side view> Right #21- 023 - Ferri Red #21- 091 - Silver #21- 010 - White...
  • Page 42 B.A Eagle Item code: BH158 Instruction Manual...
  • Page 43 B.A Eagle Item code: BH158 Instruction Manual I/C FL YING W ARNINGS Always operate in open areas, away from fly near power lines,aerials or AL WAYS adjust the engine from behind NEVER factories, hospitals, schools, buildings other dangerous areas including airports, the propeller, and do not allow any part of and houses etc.
  • Page 44 B.A Eagle Item code: BH158 Instruction Manual I/C FL YING GUIDELINES Operate the control sticks on the ALWAYS land the model INTO When ready to fly, first extend transmitter and check that the the wind, this ensures that the the transmitter aerial. control surfaces move freely and in model lands at the slowest possible the CORRECT directions.
