question mark. Proceed to the setup cell screen and turn the "Cell Modem" or "Network"
to "Off". Press the return/exit button to return to the main screen.
Plug your modem into the Omniguard's USB port and wait. It can take a few minutes
for the Omniguard to recognize the modem. The wireless icon in the lower right should
change from a tower with an "X" across it to a tower with or without a question mark.
Touch the icon and proceed to the setup screen. Set the "Cell Service Provider" to
"Verizon" if you are using a Verizon SIM or "Other" if you are using any other provider.
Press the return/exit button to return to the main screen. If the provider needs to be
changed in the modem you will see a warning. Press the "Start" button to change the
modem to match the SIM being used.

Authorizing

If you did not purchase your modem directly from Engineering Solutions it will need
to be authorized for use by the Omniguard. When your modem is connected and the
Omniguard is turned on, you will be informed that the modem is "Not Authorized" along
with a serial number. Contact Engineering Solutions, provide us with the serial number
shown on the screen and we will give the passcode to authorize the modem. To enter the
passcode into the Omniguard use the up and down arrow keys to change a digit and the
right and left arrow keys to move between the digits. When all the digits have been
entered press SAVE to authorize the modem. You will get the message "Modem ready".
The modem will now work with any compatible Omniguard.

Configuring

Touch the wireless icon in the lower right corner of the screen above the time. On the
cell setup screen two wireless phone numbers can be programmed directly into the
Omniguard. A text message will be sent to each phone number when the Omniguard
enters normal operation and when an alarm condition occurs. The minimum time
between alarm text messages is limited to the Message Rate to prevent frequent messages
if the unit is going in and out of the alarm state.

Normal Operation Message

Alarm Message

JOB:
1234 Jacksonville Ave N
NORMAL OP 12:59:16
Reply with 0 for menu.
Omniguard 4
# G400000
>> ALARM <<
JOB:
1234 Jacksonville Ave N
ALARM 1: +0.010" WC
12:59:07 +0.011" WC
Reply with 0 for menu.
Omniguard 4
# G400000
