- Page 1 TK102 GSM/GPRS/GPS TRACKER MANUAL custom_efficiency@yahoo.com www.customsales.webs.com Phone: +316-5326-7060...
-
Page 2: Table Of Contents
Preface This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual. Any change will be integrated in the latest release. -
Page 3: Summary
Summary Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. Applications Vehicle rental / Fleet management etc • Powerful magnet+water proof, adsorbing in the hidden place of car. •... -
Page 4: Bottom Face
Specs Content Specification Dimension 64 x 46 x 17mm (1.8” x 2.5” x 0.65”) Weight Network GSM / GPRS Bandwidth 850/900/1800/1900Mhz or 900/1800/1900Mhz GPS Chip SIRF3 chip GSM / GPRS module Simcom Sim 340 or Simcom Sim 300 GPS sensitivity -159dBm GPS accuracy 5 meter... -
Page 5: Usage
Usage SIM card installation Make sure that there is no call transfer and call display is on, and PIN code off. The SMS message must in Text format, can’t be identified for PDU format. Steps: 1. Open the rear cover, and pick out the battery. 2. -
Page 6: Initialization
When this unit receives GPS signals normally, you can use it and do all the following • settings. Initialization Send “begin+password” in SMS to the unit, it will reply “begin ok” and initialize all the settings. (default password: 123456) For example,send SMS“ begin123456” to the tracker via a cell phone, If succeeded, “begin OK”... -
Page 7: Auto Track
*Tracking location, the SMS information about the lat./long. Received is the place received the GPS signal when the GPS signal is weak. Please check the time received the SMS if there are some errors of the location. Auto Track Report a Geo-info at 30s intervals to the authorized numbers for 5 times: 5.8.1 Set up: Send SMS t030s005n+password to the unit, it will report the Geo-info at 30s intervals for 5 times.(s: second, m: minute, h: hour). -
Page 8: Geo-Fence
5.11 Geo-fence Set up a geo-fence for the unit to restrict its movements within a district. The unit will send the message to the authorized numbers when it breaches the district. 5.11.1 Set up: When the unit stays immobile in a place for 3-10 minutes, the user can Send SMS stockade+password+space+latitude,longitude;... -
Page 9: Sos Button
5.15 SOS button Press the SOS for 3 seconds, it will send “ help me !+ Geo-info” to all the authorized numbers every 3 minutes. It will stop sending such a SMS when any authorized number reply SMS “help me!” to the tracker. 5.16 Low battery alert It begins to alert when it is 3.7V and sends you SMS in 30m interval. -
Page 10: Modes Switch Between "Sms" And "Gprs
5.19 Modes switch between “SMS” and “GPRS” 5.19.1 The default mode is “SMS” 5.19.2 Send SMS “GPRS+password” to the unit, and it will reply “GPRS ok!” and switch to “GPRS”mode. 5.19.3 Send SMS “SMS+password” to the unit, it will reply “SMS ok!” and restore to “SMS” mode. -
Page 11: Contents Package
Contents package Item Q'ty GPS Real Time Tracker Battery 3.7V (rechargeable) Wall Charger 110 / 220V w/ docking Car Charger 12 / 24V GPS software application (CD-rom) Magnetic back cover Waterproof bag/cover English manual custom_efficiency@yahoo.com www.customsales.webs.com Phone: +316-5326-7060...
