FUZHOU CANWELL IMPORT & EXPORT CO., LTD.
GPS VEHICLE TRACKER
USER MANUAL
Preface
Thank you for purchasing the GPS vehicle tracker TK103, This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before using this product.
Please note that specification and information are subject to changes without prior notice in this
manual. Any change will be integrated in the latest release. The manufacturer assumes no
responsibility for any errors or omissions in this document.
1
Tel:0086-591-87610093, 87614264 Fax:0086-591-83640189,87279269 E-mail:qqmd@fcanwell.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Xexun TK103
Summary of Contents for Xexun TK103
-
Page 1: User Manual
USER MANUAL Preface Thank you for purchasing the GPS vehicle tracker TK103, This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual. -
Page 2: Table Of Contents
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. Content 1 Summary--------------------------------------------------------------------------------------------------4 2 Application------------------------------------------------------------------------------------------------4 3 Hardware description 3.1 Front face-------------------------------------------------------------------------------------- 4 3.2 Rear face ------------------------------------------------------------------------------------- 4 3.3 Side face----------------------------------------------------------------------------------------4 3.4 Bottom face ---------------------------------------------------------------------------------- 5 4 Specifications--------------------------------------------------------------------------------------------5 5 Usage------------------------------------------------------------------------------------------------------6 5.1 SIM card installation-------------------------------------------------------------------------6 5.2 GPS Vehicle Tracker Installation ----------------------------------------------------------6 5.3 Quick Startup-----------------------------------------------------------------------------------8 5.4 Restart the tracker-----------------------------------------------------------------------------9... -
Page 3: Application
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 1 Summary Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or GPRS. 2 Applications Vehicle rental / Fleet management etc Provide peace-of-mind for businessmen Track every target secretly Protect wealth etc 3 Hardware Description... -
Page 4: Usage
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 4 Specs. Content Specs. Dim. 85mm x 63mm x 25mm(3.3”*2.5”*0.98”) Weight Network GSM/GPRS Band 850/900/1800/1900 GPS chip SIRF3 chip GSM/GPRS module Simcom900 GPS sensitivity -159dBm GPS accuracy Time To First Fix Cold status 45s Warm status 35s Hot status 1s Car charger... -
Page 5: Gps Vehicle Tracker Installation
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 5.2 GPS Vehicle Tracker Installation GPS/GSM/GPRS tracker should be installed by technical professional of local service centre. Without permission, the user can’t repair and move the tracker randomly. If users do, any unfortunate damage should be compensated by himself. -
Page 6: Restart The Tracker
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. Wire for cutting off oil of the tracker Wire for cutting off circuit of the tracker Yellow wire connects the relay feet 86; 85 White wire connects relay feet 86; 85 feet feet to 12 V DC anode, 87 feet and 30 feet in to 12 V DC anode, 87 feet and 30 feet are in series in the supply oil circuits. -
Page 7: Authorization
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. ok".666888 is new password.Make sure the new password is in 6 digits. Please remember the new password, because most of the instruction need the password to set. 5.6.2 you can Send "resume password" to the tracker, to restore the original setting in case of losing the new password,and it will reply "resume password,password is123456". -
Page 8: Movement Alert
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 5.12 Movement alert 5.12.1 Set up: When the unit stays immobile in a place for 3minutes, the user can send SMS "move123456" to the unit, then the unit will reply "move ok". After 10s, if the unit move over 200m, it will send SMS "Move+Geo-info"... -
Page 9: Auto Tracking By Platform
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 5.16.3 Send SMS "telephone123456" to device.if set successfully, the device will reply “set telephone ok”. And then, the device will send GPS data to your telephone by SMS. Remark:The default is sending the GPS data to the telephone. 5.17 Auto tracking by platform 5.17.1 Initialization : Send “begin123456”... -
Page 10: Count Mileage
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. 5.20 Count mileage 5.20.1 Dials up the unit, it will report a Geo-info,the Geo-info include mileage. 5.20.2 you can sent "clearmile123456", if set successfully, it will reply SMS "clearmile ok",the mileage change zero. 5.21 Remote control oil and circuit 5.21.1 Control oil Send SMS "stopoil123456 "... -
Page 11: Collection Of Commands
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. Faults Solution Check the battery and see if it is Startup Fail fully charged or correctly installed. In existence of an authorized number, an unauthorized number dials up the Hangup Fail unit.Please initialize the unit and re-set up the authorized numbers. -
Page 12: Use Setting Tool To Set Tracker
FUZHOU CANWELL IMPORT & EXPORT CO., LTD. set ip address and port Set first ip ip220.231.180.37port2332 5.17.5 set APN ok Set APN apn123456 #cmnet 5.17.5 Set APN user name and Set GPRS user user123456#cmnet#cmnet 5.17.5 password password ok Imei checking imei123456 IMEI:35771300558866 5.18... - Page 13 FUZHOU CANWELL IMPORT & EXPORT CO., LTD. ○ 1 ○ 11 5.17.3 ○ 2 ○ 12 5.17.6 5.17.4 ○ 3 ○ 13 5.17.5 5.16.3 ○ 4 ○ 14 5.11 5.20 ○ 5 ○ 15 5.20 ○ 6 ○ 16 Bands ○...
