BE AC708RB User Manual

Wheeled air compressor
Hide thumbs Also See for AC708RB:
Table of Contents

Advertisement

Quick Links

Wheeled Air
Compressor
User Manual
WARNING: This product can expose you to
chemicals including lead, which is known to the
State of California to cause cancer and birth
defects or other reproductive harm. For more
information, go to www.P65Warnings.ca.gov.
Wash hands after handling.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC708RB and is the answer not in the manual?

Questions and answers

Related Manuals for BE AC708RB

Summary of Contents for BE AC708RB

  • Page 1 Wheeled Air Compressor User Manual WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. Wash hands after handling.

  • Page 3: Table Of Contents

    table of contents Introduction 5  Using the Operators Manual Product Identification 6  Record Identification Numbers Safety 7  Safety Instructions 8  Safety Rules 8  Hazard Symbols and Meanings 11 General Safety Information Safety & Installation 12 Spraying Precautions 12 Hose Precautions 12 Installation and Location 12 Extension Cords Assembly Instructions...
  • Page 4 16 When performing maintenance or service 16 Daily 16 Weekly 16 Monthly 16 Six Months or 250 Operating Hours 16 Oil Change Troubleshooting 17 Troubleshooting Chart Parts 18 AC708RB/AC6508HB Pump Diagram 19 Pump List 20 AC908HB Pump Diagram 21 Pump List Warranty 22 Warranty...

  • Page 5: Introduction

    Using the Operator’s manual This manual gives information with respect to operation and main- tenance of the Compressor. Be sure to read it carefully first before operation. Following the manual can ensure the user’s safety and get the best results from the compressor.

  • Page 6: Product Identification

    product identification Record Identification Numbers If you need to contact an Authorized Dealer or Customer Service line (1-866-850-6662) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the machine and record the information in the places provided below.

  • Page 7: Safety

    · Damage may result in bursting, which can cause serious injury or property damage. · All damaged parts must be repaired or replaced as needed prior to operating this air compressor. · Check to see that all nuts, bolts and fittings are secure.

  • Page 8: Safety Rules

    safety Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards.
  • Page 9 Do not direct paint or other spray material towards the compressor. Read and follow all safely instructions for the material you are spraying. Be sure to use an approved respirator designed for use with your specific application. WARNING...
  • Page 10 Keep hands and fingers away from exposed metal parts on a running air compressor. Air compressors generate significant heat during normal operation, which can cause serious burns. The compressor will remain hot for some time after operation and should not be touched or moved until cool.

  • Page 11: General Safety Information

    13. Tanks rust from moisture build-up, which weakens the tank. Make sure to drain tank daily and inspect periodically for unsafe condi- tions such as rust formation and corrosion. 14. Fast moving air will stir up dust and debris which may be harmful.

  • Page 12: Safety & Installation

    20. Keep away from hot surfaces and chemicals. Installation INSTALLATION AND LOCATION The compressor must be used on a stable level surface. The air compressor must be used in a clean and well-ventilated area. The compressor requires an unobstructed airflow and must be located a minimum of 18 inches from any walls or other ob- structions.

  • Page 13: Assembly Instructions

    Place air compressor on a flat, level surface. Pour supplied oil into crankcase until the oil level reaches the red dot in the oil level sight glass. Be careful not to overfill. 1/2” Adjust tension of belt to ensure that a maximum of 1/2” / 12mm of slack exists when pressure is placed on belt at centre line.

  • Page 14: Product Features

    Water is produced whenever air is compressed. It is critical to drain water from the air tank on this compressor frequently. If unit is used only occasionally, tank should be drained after each use and prior to the next use. To drain the tank, slowly open the tank drain fitting by turning clockwise.

  • Page 15: Operating Instructions

    operation Operating Instructions Initial Start Up Disconnect tools and/or accessories from the air hose. Open the tank drain valve to allow air to escape preventing air pressure buildup in the air tank. Check to see that the belt is installed properly with the correct tension. Plug power supply cord into proper power source receptacle.

  • Page 16: Maintenance

    Remove dipstick to allow air to enter crankcase. Remove oil drain plug. Allow oil to drain completely. Clean and replace oil drain plug. Refill crankcase with SAE 20 or SAE 30 weight non-detergent oil to red dot on oil level sight glass. Be careful not to overfill.

  • Page 17: Troubleshooting

    troubleshooting Troubleshooting Chart Trouble Possible Cause Corrective Action No start condi- Gas engine not running Check operation of gas tion engine Low pressure Air leak in safety valve Check valve manually by pulling upward on rings. If condition persists, replace valve. Loose tube or fittings Tighten fittings Restricted air filter...

  • Page 18: Parts

    AC708RB/AC658HB Pump...
  • Page 19 parts Parts List No. Description Qty Part # No. Description Qty Part # Bolt Stud 6005880B 6013835 Spring Washer Cylinder 60018 52016550 Cylinder Head Gasket, Cylinder 5101UH30 5214UH30 Air Filter Assy Breather Assy 504034 533016A Front Cover, Air Filter Breather 504434 533316A Element, Air Filter Washer,Breather 504334 6014153 Rear Cover, Air Filter Ball 504534 5331113 Exht. Elbow Gasket Rod, Breather...

  • Page 20: Ac908Hb Pump Diagram

    parts AC908HB Pump...
  • Page 21 parts Parts List No. Description No. Description Safety Valve Oil Leveler Cooler Washer Washer, Oil Leveler In-Six Angle Bolt Oil Drain Plug Spring Washer Oil Drain pipe Exhuast Cooler In-Six Angle Bolt In-Six Angle Bolt Spring Washer Flange Soleplate Nipple seat gasket Air Filter Assy Crankshaft Check Washer, Air Filter Brearing Rear Cover, Air Filter Gasket, Bearing Seat Connect Seat, Air Filter Oil Seal Washer, Air Filter Bearing Seat Element, Air Filter Spring Washer Front Cover, Air Filter Bolt Pulley Cooler Elbow Washer Intercooler copper pipe Bolt Safety Valve...

  • Page 22: Warranty

    BE Pressure Inc. warrants that each new product will be free of any manufacture defects in workmanship for the set warranty period of the product. Warranty applies to the original purchaser of the product and cannot be transferred. This warranty does not cover normal wear items, including but not limited to: seals, packings, valves, o-rings, spark plugs etc.
  • Page 23 If freight company is arranged by dealer, then it is incumbent on them to contact their own freight company and file a claim directly with them. d. If freight was arranged by BE Pressure Inc, then contact BE Pressure Inc pressure supply with the following information (regardless of receipt...
  • Page 24 THE POWER YOU NEED. f you need assistance with the assembly or operation of this ompressor please call 1-800-663-8331 or visit our website at BEPOWEREQUIPMENT...

This manual is also suitable for:

Ac658hbAc908hb
