Summary of Contents for BE AC205

  • Page 1 AC205 operation manual...
  • Page 2: Table Of Contents

    table of contents Introduction 4    Using the Operators Manual Specifications 4    Specifications Product Identification 5    Record Identification Numbers Safety 6   Safety Instructions 7   Safety Rules 7   Hazard Symbols and Meanings 10   General Safety Information 11   Spraying Precautions 11   Hose Precautions Installation and Grounding 12   Installation and Location 13   Extension Cords Assembly Instructions 14   Assembly Product Features 15   Automatic ON/OFF 15   Regulator 15   Tank Pressure Gauge 15   Safety Valve 15   Tank Drain Fitting 15   Thermal Shutdown Switch...
  • Page 3 Operating Instructions 16   Initial Start Up 16   Start Up 16   Storage 16   Shut Down Maintenance 17 When performing any maintenance or service 17   Daily 17   Weekly 17   Monthly 17   Six Months or 250 Operating Hours 17   Oil Change Parts 18   AC205 Parts Diagram 19   AC205 Parts List...
  • Page 4: Introduction

    Attention: Read through the complete manual prior to the initial use of your compressor. Using the Operator’s manual Thank you for choosing our compressor. The manual gives information  with respect to operation and maintenance of the AC205 Compressor  and be sure to read it carefully first before operation. Following the manual can ensure the user’s safety and get the best  results from the compressor. All information and diagrams in this manual  are in accordance with the newest products at the publishing time. We  strive for accuracy and this manual is accurate for the models described  at the time of printing. We reserve the right to make improvements or  changes at any time without notice or obligation. Please keep this manual with the engine permanently, even if the engine  ownership is transferred. specifications Specifications · 4 Gallon Twin Tank Design · Oil Lubricated for Extended Durability · 3450 Rpm Induction Motor for Long Life · 120V, 60Hz, 12.4Amps · Air Delivery: 4.2CFM output @ 40 PSI and 3.5 CFM output @90 PSI · Maximum Pressure: 125 PSI · Thermal Overload Protection for safety · High Flow regulator and Dual Pressure Gauges for Precision Air Flow ...
  • Page 5: Product Identification

    product identification Record Identification Numbers Compressor If you need to contact an Authorized Dealer or Customer Service line  (1-866-850-6662) for information on servicing, always provide the  product model and identification numbers. You will need to locate the model and serial number for the machine and  record the information in the places provided below.  Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:...
  • Page 6: Safety

    Safety Instructions · Carefully read through the entire owners manual before operating this    compressor.  · Keep manual with important records for safety instructions, operating    procedures and warranty. · After unpacking your new air compressor, please inspect it carefully for    any damage that may have occurred during transit.  · Do not operate this air compressor if damaged during shipment,    handling or misuse. · Damage may result in bursting, which can cause serious injury or    property damage.  · All damaged parts must be repaired or replaced as needed prior to    operating this air compressor. · Check to see that all nuts, bolts and fittings are secure.  · Check to see that the proper lubrication oil, which has been included    with the air compressor, is used to fill the compressor crankcase to the    proper level. · Please contact our customer service department at the numbers listed    on the back of this instruction manual for any questions or comments     regarding this air compressor.
  • Page 7: Safety Rules

    safety Save these Instructions Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol (      ) is used with a signal word (DANGER,  CAUTION, WARNING), a pictorial and/or a safety message to alert  you to hazards.  DANGER indicates a hazard which, if not avoided, will result in death ...
  • Page 8 WARNING AIR TANK WARNING: Drain liquid from air tank daily,  or after each use, using the drain valve located on the  bottom of the lower air tank. Failure to properly drain  liquid from the tank will cause rust from moisture build- up, which weakens the tank and could lead to a violent  tank explosion, Periodically inspect the tanks for unsafe  conditions such as corrosion. Never attempt to repair or make modifications to the tank or its at- tachments. Welding, drilling or any other modifications may weaken  the tank, which may result in damage from rupture or explosion. Never  remove or attempt to adjust the pressure switch, safety valve, or other  factory set operating pressures. WARNING FIRE WARNING: Avoid dangerous environments. Do  not use compressor near gasoline or other flammable  materials. Keep work area well lit. Normal sparking of  a motor or sparking from grinding metal could ignite  fumes. Do not spray flammable materials in the vicinity  of an open flame or other ignition source, including the  air compressor itself. Do not direct paint or other spray  material towards the compressor. Read and follow all safely instructions for the material you are spray- ing. Be sure to use an approved respirator designed for use with your  specific application. WARNING BREATHABLE AIR WARNING: This air compressor in  not designed, nor intended for the supply of breathable  quality air. Air produced by this unit may contain carbon  monoxide or other toxic vapors.  Do not inhale air from the compressor or from a breathing device con- nected to it.
  • Page 9 WARNING ELECTRIC SHOCK WARNING: When using electric  powered tools, machines or equipment, basic safety  precautions should always be followed to minimize the  risk of electrical shock or personal injury to yourself and  others.  This air compressor is powered by electricity and should never be used  without properly grounded electrical connections. Do not use in wet or  damp locations or expose to rain. WARNING AIR TOOLS AND ACCESSORIES WARNING: Do  not exceed the pressure rating of any air tools, spray  guns, air accessories, or inflatables. Excess pressure  can cause them to explode, resulting in serious injury.  Follow the manufacturers recommended pressure set- tings for all air tools and air accessories. WARNING Do not direct compressed air stream at people or pets.  The powerful compressed air stream can damage exposed skin and easily propel loose dirt and other  small objects. Always wear eye protection that meets ANSI Z28.1 specifications. WARNING Keep hands and fingers away from exposed metal parts  on a running air compressor. Air compressors gener- ate significant heat during normal operation, which can  cause serious burns. The compressor will remain hot for  some time after operation and should not be touched or  moved until cool.
  • Page 10: General Safety Information

    General Safety Information Do not operate unit if damaged during shipping, handling or use. Damage  may result in bursting and cause injury or property damage. Since the air compressor and other components (filters, lubricators,  hoses, etc.) used, make up a high pressure pumping system, the follow- ing safety precautions must be observed at all times: 1. Read all manuals included with this product carefully. Be thoroughly       familiar with the controls and the proper use of the equipment. 2. Follow all local electrical and safety codes 3. Only persons well acquainted with these rules of safe operation should      be allowed to use the compressor. 4. Keep visitors away and NEVER allow children in the work area. 5. Wear safety glasses and use hearing protection when operating the      pump or unit. 6. Do not stand on or use the pump or unit as a handhold. 7. Before each use, inspect compressed air system and electrical      components for signs of damage, deterioration, weakness or leakage.        Repair or replace defective items before using. 8. Check all fasteners at frequent intervals for proper tightness. WARNING Motors, electrical equipment and controls can cause  electrical arcs that will ignite a flammable gas or vapor.  Never operate or repair in or near a flammable gas or  vapor. Never store flammable liquids or gases in the  vicinity of the compressor.  WARNING Compressor parts may be hot even if the unit is  stopped. 9. Keep fingers away from a running compressor; fast moving and hot       parts will cause injury and/or burns. 10. If the equipment should start to abnormally vibrate, STOP the engine/      motor and check immediately for the cause. Vibration is generally a      warning of trouble. 11. To reduce fire hazard, keep engine/motor exterior free of oil, solvent,      or excessive grease. Never remove or attempt to adjust safety valve.      Keep safety valve free from paint and other accumulations. 12. Never attempt to repair or modify a tank! Welding, drilling or any other ...
  • Page 11: Spraying Precautions

        modification will weaken the tank resulting in damage from rupture or      explosion. Always replace worn or damaged tanks. Drain liquid from     tank daily. 13. Tanks rust from moisture build-up, which weakens the tank. Make       sure to drain tank daily and inspect periodically for unsafe conditions       such as rust formation and corrosion. 14. Fast moving air will stir up dust and debris which may be harmful.      Release air slowly when draining moisture or depressurizing the      compressor system. Spraying Precautions 15. Do not smoke when spraying paint, insecticides, or other flammable      substances. 16. Use a face mask/respirator when spraying and spray in a well      ventilated area to prevent health and fire hazards. 17. Do not direct paint or other sprayed material at the compressor.      Locate compressor as far away from the spraying area as possible to      minimize overspray accumulation on the compressor. 18. When spraying or cleaning with solvents or toxic chemicals, follow      the instructions provided by the chemical manufacturer. WARNING Do not spray flammable materials in vicinity of open  flame or near ignition sources including the compressor unit. Hose Precautions 19. Inspect hose before use. Do not exceed working pressure marked on      hose. Do not twist, bend knot, or abrade hose. Do not wrap hose      around body. 20. Keep away from hot surfaces and chemicals. WARNING Arcing Parts. Keep the compressor/motor at least 6m  away from explosive vapour.
  • Page 12: Installation And Grounding

    & installation grounding Installation and Location The compressor must be used on a stable level surface. The air compres- sor must be used in a clean and well-ventilated area. The compressor  requires an unobstructed airflow and must be located a minimum of 18  inches from any walls or other obstructions. Grounding Instructions This product should be grounded. In the event of an electrical short cir- cuit, grounding reduces the risk of electric shock by providing an escape  wire for the electric current. This product is equipped with a cord having  a grounding wire with an appropriate grounding plug. The plug must be  plugged into an outlet that is properly installed and grounded in accor- dance with all local codes and ordinances. DANGER ELECTRIC SHOCK: Improper installation of the  grounding plug can result in a risk of electric shock. If  repair or replacement of the cord is necessary, do not  connect the grounding wire to either flat blade terminal.  The wire with insulation having an outer surface that is  green with or without yellow stripes is the grounding  wire. This product is for use on a nominal 120-volt circuit and has a three- prong grounding plug that looks like the plug illustrated in Figure 2. Make  sure that the product is connected to an outlet having the same configuration as the plug. No adapter could be used with this product. The use of a GFCI outlet is strongly recommended. The third prong is to be used ground the tool and provide protection against electrical shock. Never remove the third prong. Check with a qualified electrician or serviceman if the grounding instruc- tions are not completely understood, or if In doubt as to whether the  product is properly grounded. Do not modify the plug provided; if it will  not fit the outlet, have the proper outlet installed by a qualified electrician. Figure 2 Grounding Pin...
  • Page 13: Extension Cords

    & installation grounding Extension Cords We do not recommend the use on an extension cord with this product as  this may result in the loss of power and overheating of the motor. An  additional air hose should be used instead of an extension cord. However,  if the use of an extension cord is unavoidable, use only UL listed wire  extension cords that have three-pronged grounding type plugs and three  prong receptacles that accept the tool’s plug. Improper use of extension  cords may cause inefficient operation of you tool, which can result an  overheating.  Be sure your extension cord is rated to allow sufficient flow to motor.  Refer to the guide for minimum gauge required for extension cords. Extension Cord Length Wire Size (A.W.C.) Up to 25 Feet 26 to 50 Feet 51 to 100 Feet Use of an extension cord heavy enough to carry the current the tool will  draw is very important. Especially when the power source is of great  distance. An extension cord that is insufficient will cause a drop in line  voltage, resulting in power loss and causing the motor to overheat. Guard against electrical shock. Avoid body contact with grounded ser- vices such as pipes, radiators, ovens, stoves, and refrigerator enclosures.  If not properly grounded, this power tool can incur the potential hazard of  light trickle shock, particularly when used in damp locations. If an electri- cal shock occurs, there is the potential of a secondary hazard such as  your hands contacting an operating air tool.
  • Page 14: Assembly Instructions

    Assembly Read all safety instructions before using air compressor.     WARNING The compressor is shipped without oil in the crankcase.  Add oil as indicated below. Oil Level OK Check Oil  Level Daily Refill Oil Immediately 1. After opening the carton, please remove all parts and check      against photograph on carton. If any parts are missing, please call at      1-866-850-6662. 2. Place air compressor on a flat, level surface. 3. Pour supplied oil into crankcase until the oil level reaches the red dot in      the oil level sight glass. Be careful not to overfill. 4. Install oil fill plug, supplied for compressor operation, before starting      compressor. 5. Close tank drain valve on the bottom of the air tank by turning the valve      clockwise until fully closed. 6. Attach the air coupler to the compressor regulator valve. Use Teflon      thread-sealing tape on the threads to make sure you have an airtight      connection. Do not over tighten fittings. 7. Attach the supplied air filter to the air intake port on the pump head. 8. Attach air hose and any desired air accessories (which are not      included). Use Teflon thread-sealing tape on the threads to make sure      you have an airtight connection. Do not over tighten fittings. NOTICE Do not operate the compressor without lubricant or with low lubricant  level. We are not responsible for damage caused to the compressor  due to operation without proper lubrication.
  • Page 15: Product Features

        switch is in the “I”(ON) position. 2. Regulator     The regulator allows you to select the amount of air pressure that is      output through the air hose into tools and     accessories. Please refer to the air delivery requirements of your tools       for the proper pressure settings. 3. Tank Pressure Gauge     The tank pressure gauge provides a reading of the air pressure inside      of the compressor tank. 4. Safety Valve     This compressor is equipped with a safely valve switch that will engage      when the pressure in the tank exceeds the     maximum rated pressure. DO NOT attempt to modify or remove safely      valve. 5. Tank Drain Fitting     Water is produced whenever air is compressed. It is critical to drain      water from the air tank on this compressor frequently. If unit is used      only occasionally, tank should be drained after each use and prior to      the next use. To drain the tank, slowly open the tank drain fitting by      turning clockwise. Once all water has drained out, close the fitting      securely. NOTE: tank will not pressurize while fitting is open. 6. Thermal Shutdown Switch     The electric motor is equipped with an automatic thermal overload      protector. If the unit is overheating, the motor will automatically shut      down. Turn the unit off and wait 5-10 minutes before turning the unit      back to the “I”(ON) position. If the unit shuts down again, please      contact the manufacturer for assistance.
  • Page 16: Operating Instructions

    operation Operating Instructions Initial Start Up 1. Disconnect tools and/or accessories from the air hose. 2. Open the tank drain valve to allow air to escape preventing air pressure      buildup in the air tank. 3. Plug power supply cord into proper power source receptacle. (See      Grounding Instructions) 4. Run the compressor for a minimum or twenty minutes in this no-load      position to lubricate the bearings and piston. 5. Turn off compressor, drain liquid from tanks and close drain valve. 6. The compressor is now ready for use. Start Up 1. Slowly open tank drain by turning clockwise. Allow any water in tank to      drain out. Close fitting securely. 2. Before connecting the compressor to the grounded outlet, check for      broken components and accessories, and check for damage to the      hose. 3. Make sure the power switch is turned “O”(OFF) position. 4. Plug the unit into a grounded outlet. 5. Attach desired tool to the end of the air hose. 6. Turn the switch on the “I”(ON) position. 7. Adjust regulator knob to desired pressure level once the pump has      shut off and the compressor has stopped running. Storage 1. Disconnect unit from grounded outlet. 2. Disconnect tools and/or accessories from the air hose. 3. Locate drain valve on bottom side of tank. 4. Open drain valve to release remaining pressurized air and moisture      from the air tank. Moisture buildup in the tank is normal with air      compressors, so a small amount of water may come out while      draining the tank. Draining the tank is vital for longevity and safety of      your air compressor. 5. Close valve and store the compressor in a cool, dry place. Shut Down 1. Do not turn off the air compressor by unplugging it from the power ...
  • Page 17: Maintenance

    & operation maintenance 6. Slowly open air tank drain valve to release remaining pressurized air,      and tilt unit to fully drain accumulated liquid from air tanks. Moisture      build-up in the tank is normal with air compressor, so a small amount of      water may come out while draining the tank. Draining the tank is vital      for the longevity and safely of your air compressor. 7. Close drain valve. 8. Allow compressor to cool down. 9. Clean and store compressor. Maintenance When performing any maintenance or service · The air compressor must be turned off. · Disconnect compressor from the power source. · Drain tanks. · Allow compressor to cool down. Daily · Check oil level. · Drain accumulated liquid from tanks. · Check for oil leaks. · Check for unusual noise and/or vibrations · Check that all fasteners are secure. Weekly · Check safety relief valve. · Inspect and clean air filter. · Clean breather holes on oil check dipstick. Monthly · Check for air leaks.  · Apply a solution of soapy water around joints.  · Look for air bubbles around joints when compressor reaches the    pressure cut-out limit and pump turns off. Six Months or 250 Operating Hours · Change compressor oil. ...
  • Page 18: Ac205 Parts Diagram

    AC205 Parts Diagram...
  • Page 19: Ac205 Parts List

    AC205 Parts List No. Description No. Description Bolt 39 Washer Washer 40 Crankcase Air Filter includes element 41 Over-load Cylinder Head 42 Nut Elbow 43 Capacitor Shroud 44 Motor Washer 45 Rear cover Washer 46 Fan Bolt 47 Clip 10 Head  Gasket  48 Outlet Tube Assy 11 Valve plate 49 Rubber strip...
  • Page 20 If you need assistance with the assembly or operation of this Compressor please call 1-866-850-6662...
