THIS MANUAL COULD RESULT IN THE VOIDING OF YOUR WARRANTY, AND PERSONAL INJURY, AND/OR PROPERTY DAMAGE. THE MANUFACTURER OF THIS AIR COMPRESSOR WILL NOT BE LIABLE FOR ANY DAMAGE BECAUSE OF FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL. By following the instructions and recommendations in this manual you will ensure a...
table of contents Introduction Using the Operators Manual Specifications Specifications Product Identification Record Identification Numbers Safety Safety Instructions Safety Rules Hazard Symbols and Meanings 10 General Safety Information Safety & Installation 11 Spraying Precautions 11 Hose Precautions 11 Installation and Location 11 Extension Cords Assembly Instructions 12 Assembly...
Page 3
table of contents Operating Instructions 14 Initial Start Up 14 Start Up 14 Storage 14 Shut Down Maintenance 15 When performing any maintenance or service 15 Daily 15 Weekly 15 Monthly 15 Six Months or 250 Operating Hours 15 Oil Change Troubleshooting 16 Troubleshooting Chart Parts...
Using the Operator’s manual Thank you for choosing our compressor. The manual gives information with respect to operation and maintenance of the Compressor and be sure to read it carefully first before operation. Following the manual can ensure the user’s safety and get the best results from the compressor.
product identification Record Identification Numbers COMPRESSOR If you need to contact an Authorized Dealer or Customer Service line (1-866-850-6662) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the machine and record the information in the places provided below.
· Damage may result in bursting, which can cause serious injury or property damage. · All damaged parts must be repaired or replaced as needed prior to operating this air compressor. · Check to see that all nuts, bolts and fittings are secure.
safety Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards.
Page 8
Do not direct paint or other spray material towards the compressor. Read and follow all safely instructions for the material you are spray- ing. Be sure to use an approved respirator designed for use with your specific application. WARNING...
Page 9
Keep hands and fingers away from exposed metal parts on a running air compressor. Air compressors gener- ate significant heat during normal operation, which can cause serious burns. The compressor will remain hot for some time after operation and should not be touched or moved until cool.
Installation INSTALLATION AND LOCATION The compressor must be used on a stable level surface. The air compres- sor must be used in a clean and well-ventilated area. The compressor requires an unobstructed airflow and must be located a minimum of 18 inches from any walls or other obstructions.
2. Place air compressor on a flat, level surface. 3. Pour supplied oil into crankcase until the oil level reaches the red dot in the oil level sight glass. Be careful not to overfill. 1/2” 4. Adjust tension of belt to ensure that a maximum of 1/2” / 12mm of slack exists when pressure is placed on belt at centre line.
Water is produced whenever air is compressed. It is critical to drain water from the air tank on this compressor frequently. If unit is used only occasionally, tank should be drained after each use and prior to the next use. To drain the tank, slowly open the tank drain fitting by turning clockwise.
operation Operating Instructions Initial Start Up Disconnect tools and/or accessories from the air hose. Open the tank drain valve to allow air to escape preventing air pressure buildup in the air tank. Check to see that the belt is installed properly with the correct tension. Plug power supply cord into proper power source receptacle.
3. Remove oil drain plug. 4. Allow oil to drain completely. 5. Clean and replace oil drain plug. 6. Refill crankcase with SAE 20 or SAE 30 weight non-detergent oil to red dot on oil level sight glass. Be careful not to overfill.
troubleshooting Troubleshooting Chart Trouble Possible Cause Corrective Action No start condition Gas engine not running Check operation of gas engine Low pressure Air leak in safety valve Check valve manually by pulling upward on rings. If condition persists, replace valve. Loose tube or fittings Tighten fittings Restricted air filter...
parts Parts Diagram Parts List No. Description Qty Part # No. Description Qty Part # Angle Nut Exhaust Pipe Assembly Tank Wheel Collar 0.37M Air Tank Exhaust Pipe Wire 42.004.007 Gas throttle line 42.004.007 Safety Guard Gas throttle 42.004.007 M5x0.8x8 Screw Air Connector 42.004.008 Bolt...
Page 18
parts Parts List No. Description Qty Part # No. Description Qty Part # 28 Exhaust Elbow In-Six Angle Bolt Copper Pipe Assy, Spring Washer Exhaust Cylinder Head 30 Cooler Air Filter Assembly 31 Exhaust Pipe 42.004.006 32 Exhaust Nut Six Angle Bolt 42.004.006 33 Bolt Washer...
