AIR COMPRESSOR
operation manual
AC5060B
AC5060B(p)
CAUTION READ THIS MANUAL CAREFULLY before operating or servicing this
air compressor, to familiarize yourself with the proper safety, operation, and standard
operating procedures of this unit. FAILURE TO COMPLY WITH INSTRUCTIONS IN
THIS MANUAL COULD RESULT IN THE VOIDING OF YOUR WARRANTY, AND
PERSONAL INJURY, AND/OR PROPERTY DAMAGE. THE MANUFACTURER
OF THIS AIR COMPRESSOR WILL NOT BE LIABLE FOR ANY DAMAGE
BECAUSE OF FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL.
By following the instructions and recommendations in this manual you will ensure a
longer and safer service life of your air compressor.
Advertisement
Table of Contents
Related Manuals for BE AC5060B
Summary of Contents for BE AC5060B
-
Page 1: Air Compressor
THIS MANUAL COULD RESULT IN THE VOIDING OF YOUR WARRANTY, AND PERSONAL INJURY, AND/OR PROPERTY DAMAGE. THE MANUFACTURER OF THIS AIR COMPRESSOR WILL NOT BE LIABLE FOR ANY DAMAGE BECAUSE OF FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL. By following the instructions and recommendations in this manual you will ensure a... -
Page 2: Table Of Contents
table of contents Safety Safety Rules Safety Warnings Installation & Operation Installation 11 Mounting 11 Wiring Before Operating the Air Compressor Compressor Lubrication Filling the Compressor with Oil Oil Changes Engine Lubrication Operation 14 Operating Your Air Compressor Maintenance 15 Maintenance 15 Checking Belt Tension 16 Maintenance Chart Troubleshooting... - Page 3 Using the Operator’s manual The operating manual is an important part of your Compressor and should be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury or damage to your pump.
- Page 4 product identification Record Identification Numbers Compressor If you need to contact an Authorized Dealer or Customer Service (1-866-850-6662) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the pump and record the information in the places provided below.
-
Page 5: Safety
safety Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards. - Page 6 • A spark arrester must be added to the muffler of this engine if it is to be used on any forest covered, brush covered or grass covered unimproved land.
-
Page 7: Safety Warnings
• Be certain to disconnect the battery ground terminal before servicing. When disconnecting the cable from the battery, start with the negative terminal, and when connecting them start with the positive cable. - Page 8 When you use a Gasoline Air Compressor, remember that you cannot smell or see carbon monoxide. Even if you can’t smell exhaust fumes, you may still be exposed to carbon monoxide. • If you start to feel sick, dizzy or weak while using this unit, get to fresh air right away.
- Page 9 All repairs to the air compressor should be made by an Authorized Service person. • Do not operate without protective covers/guards. Always turn off air compressor before removing any guard.
- Page 10 • Never allow children or adolescents to operate this air compressor! • Stay alert-watch what you are doing. Do not operate the air compressor when fatigued or under the influence of alcohol or drugs. • Know how to stop the air compressor. Be thoroughly familiar with controls. WARNING Risk of major repair.
-
Page 11: Installation & Operation
INSTALLATION proper care, maintenance and lubrication ensures longevity. The compressor should always be level for proper lubrication. Use only in a clean, dry, and well-ventilated area. The compressor has heat dissipation fins for proper cooling. Keep the fins and other parts that collect dust clean. -
Page 12: Before Operating The Air Compressor
1) Check to see that nuts and bolts are all snug. 2) Check if the quantity and quality of oil is correct. 3) If the intake filters are dirty, they should be replaced or cleaned. COMPRESSOR LUBRICATION WARNING •... -
Page 13: Filling The Compressor With Oil
& installation operation FILLING THE COMPRESSOR WITH OIL 1) Remove the oil filler plug 2) Slowly pour the proper oil into the pump crankcase. 3) Always keep oil level in the middle of the sight glass. OIL CHANGES NOTICE • Initial oil change due at 100 hours. •... -
Page 14: Operating Your Air Compressor
Operation OPERATING YOUR AIR COMPRESSOR WARNING • EXTRA CARE ShOULD BE TAKEN TO AVOID pERSONAL INJURIES WITh AUTOMATIC CONTROLLED COMpRESSORS. 1) Check unit for any damage. All compressors are tested and inspected at the factory and supplied in perfect condition. Any damage is the freight carriers’... -
Page 15: Maintenance
1/2” slack (see diagram below). CheCKing belt tension (if belt driven) If the belt is installed too tight, the motor might be overloaded. This will cause the motor to overheat. If the belt is installed too loosely, it will Adjust belt(s) so when pressure is applied at the center, there is approxi- slip and excessive wear and vibration will occur. -
Page 16: Maintenance Chart
maintenance MAINTENANCE CHART MAINTENANCE ChART pROCEDURE DAILY WEEKLY MONThLY QUARTERLY /300 hRS Check oil level Drain condensation from air receiver Check for unusual noise/vibration Tighten nuts and bolts Clean dust and foreign matter Clean air filter Replace worn filters Check V-belts for wear Inspect unit for leaks Tighten joints if leaks found Check V-belts for tension... -
Page 17: Troubleshooting
troubleshooting Troubleshooting TROUBLESHOOTING CHART pROBLEM pROBABLE CAUSE CORRECTIVE ACTION Will not start. Incorrect power supply and/ Make sure power is turned or wiring. on. (Consult with a licensed electrician). Air receiver is at full Drain air receiver. pressure. Low pressure Safety valve leaks. - Page 18 troubleshooting pROBLEM pROBABLE CAUSE CORRECTIVE ACTION Insufficient output, low Clogged inlet filter. Clean or replace as discharge pressure necessary. Leaks in air lines, air valves, Replace worn components fittings, etc... as necessary. Drive belts slipping. Tension V-belts. Drain valve left open. Close drain valve.
- Page 19 troubleshooting pROBLEM pROBABLE CAUSE CORRECTIVE ACTION Excessive vibration / Loose compressor, motor Tighten components. compressor knocks or engine guard. Compressor not level. Level compressor Feet bolts over tightened to Loosen feet bolts. floor. Excessive discharge Reduce operating pressure. pressure. Wrong oil being used. Drain and replace with proper oil.
- Page 20 If you need assistance with the assembly or operation of your Compressor please call 1-866-850-6662...
