Summary of Contents for BE AC5080B

  • Page 1 AC5080B AC7580B user manual BEPOWEREQUIPMENT...
  • Page 2: Table Of Contents

    table of contents table of contents Introduction Installation Using the Operator’s Manual 19 Installation Diagram Product Identification Start Up Preparation Record Identification Numbers 20 Start Up Preparation Safety Maintenance Safety Precautions and Warnings 21 Stopping for Maintenance or Service 22 Daily Troubleshooting 22 Weekly Troubleshooting Chart...
  • Page 3: Introduction

    The operating manual is an important part of your Compressor. It should record the information in the places provided below. be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed.
  • Page 4: Safety

    • Do not depend on check valves to hold system pressure. 3. Adjust belt tension • A properly sized safety valve must be installed in the discharge piping 4. Check wire connections to ahead (upstream) of any shutoff valve (block valve), heat exchanger, make sure they are tight orifice or any potential blockage point.
  • Page 5 The longer the run of wire the larger the diameter must be to overcome the inherent voltage loss caused by the wire resistance. The supply voltage at the main panel could also be low as supplied by you local power company or you may have too many other pieces of equipment running off the same panel.
  • Page 6: Compressor Maintenance

    Check Pump Oil Level - All units have a sight glass the oil level non run- ning units should be no lower than ½ way on the sight glass if it is lower then you need to add oil until it is at least ½ way up the sight glass.
  • Page 7: Adjustments & Alignment

    As long limits by a pressure switch automatically stopping and starting the com- as both points measure the same distance the pulleys will be aligned if pressor as the air pressure reaches a maximum preset pressure (cut out) not you will need to move the pulley until its in alignment this may take a and then drops to a minimum presser pressure (cut in).
  • Page 8: Pre-Operation

    Depending on the size of the compressor and the size and construction your electrical conditions. (Volts-Phase-Hertz). of the compressor room it may be necessary to locate the air pickup point outside the room. Destructive pulsations can be induced by reciprocating NOTICE compressors that will damage walls and break windows.
  • Page 9: Safety Valves

    INGS MAY RESULT IN SERIOUS INJURY OR DEATH, PROPERTY DANGER DAMAGE AND/OR MECHANICAL FAILURE Failure to properly size, set & install pressure relief valves can be fatal. PRESSURE SWITCH CAUTION The pressure switch is automatic in operation and is adjusted to start...
  • Page 10: Manual Relief And Shutoff Valves

    FEEDER LINE those instances where the air receiver tank services a single compressor, AIR-FLOW the manual relief valve can be installed on the receiver. When a manual DRAIN LEG shut- off valve, and a safety relief valve installed upstream from the...
  • Page 11: Start Up Preparation

    4. Check to make sure all safety relief valves are in place and operational. the switch Informing of the unit being serviced. 5. Check to be sure all guards are in place and securely mounted. 2. Close shut-off valve (block valve) between receiver and com- 6.
  • Page 12: Daily

    ½ way on the sight glass if it is lower then you need to add oil until it is at least ½ way up the sight glass.
  • Page 13: Parts Breakdown

    parts breakdown parts breakdown CA1 and CA1U Parts Breakdown Item CAS # Part Description 049-0027 708000 Crankcase 053-0051 709000 Crankshaft 051-0053 050170 Bearing set front 045-0044 701000 Front bearing carrier 046-0168 070163 Gasket front cap 059-0166 110117 Capscrew hex M8x20 046-0179 060068 Seal - shaft...
  • Page 14 parts breakdown 046-0171 070166 Gasket unloader cover 048-0081 720002 Piston - HP 051-0055 050122 Insert rod - bearing half 043-0100 727001 Valve assembly - HP inlet 046-0177 090095 Shim .015 Brg Adjustment and/or 046-0176 090094 Shim .010 Brg Adjustment and/or 046-0175 090093 Shim .005 Brg Adjustment...
  • Page 15 THE POWER YOU NEED.
