- Page 1 Q960 Configuration Guide with RAS 2019/05/28...
- Page 2 Part one: Access the Camera 1. Open the IP utility tool on the desktop. 2. Find the camera (Q960) you would like to install. Note: MAC Address will be used in the second part of 1-2, please record it for easy operation.
- Page 3 6. Enter the ceiling height (from the floor) and click “Calibration”. 7. Adjust the detection area and the detection line as the picture below. *Note: The detection lines should be drawn on the same level (There should be no unevenness on the detection line) www.acti.com...
- Page 4 CONFIGURATION GUIDE Click to draw an orange detection line. Click to draw a polygon detection line. Click to change the direction of entry and exit. 8. Click “Save” for the settings. www.acti.com...
- Page 5 2. IP should be set the same as the MGB Server. 3. Please set URL as “/PeopleCountingApi/Q960Receiver” 4. Set the Port ” 9005” 5. Click “Save” to save the settings 6. Click “Advanced” 7. Click “Enter/Leave” for Flow Overlay www.acti.com...
- Page 6 2. Click “Network” 3. Click “Basic Settings” 4. Click “TCP/IP” 5. Uncheck “DHCP” to undo dynamic IP address setting 6. This is the IP address to configure 7. Subnet mask 8. Router address 9. Click “Save” to save the settings www.acti.com...
- Page 7 CONFIGURATION GUIDE 10. When the settings are done, restart to apply all the settings. Click OK to restart. www.acti.com...
- Page 8 2. Sign in RAS (admin/123456) 3. Add new device settings Click “Overview” “Setting” “MGB Server” 3-1. 3-2. Click the same name as the one attached to the server. (Ex: MGB Server) Click “Add new device” as the picture below 3-3. www.acti.com...
- Page 9 CONFIGURATION GUIDE 3-4 Choose “Q960A” for the Device Type (Please refer to the picture below) www.acti.com...
- Page 10 “Lock”. Click “Lock”→ Press “Save” （If there are still other devices that need to be added (except Q960), please click “Lock” after all the devices have been set without error.） Note: The saved settings cannot be changed after clicking “Lock”！...
- Page 11 （Please wait for the store to complete the related information, click “Lock” after confirmed.） Note: The saved settings cannot be changed after clicking “Lock”！ （If there’s any setting error and need to adjust, please contact ACTi customer service to unlock.） www.acti.com...
- Page 12 3. Click “Add a User” 4. Account Name：Fill in the login account 5. Email：Fill in the Email 6. Password：Fill in the Password 7. Role：Select “Manager” 8. Store：Click the store you set on step 4 9. Click “Save” to save the settings www.acti.com...
- Page 13 Copyright © 2019, ACTi Corporation All Rights Reserved 7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C. TEL : +886-2-2656-2588 FAX : +886-2-2656-2599 Email: sales@acti.com...
