PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
LEAVE A COPY FOR THE USER / MAINTENANCE ENGINEER FOR FUTURE REFERENCE
IMPORTANT INSTALLATION INFORMATION
WARNING
RISK OF ELECTRIC SHOCK
Disconnect power before performing installation or maintenance
•
Verify that supply voltage is correct by comparing it with LED strip label
•
information.
Make all electrical grounded connections in accordance with the latest
•
edition of the National Electric Code (NEC) and applicable local code
requirements.
If the supply wire is damaged. It must be replaced by the manufacturer
•
or its service agent or a similar qualified person in order to avoid a
hazard.
All wiring connections should be capped with UL approved wire
•
connections.
WARNING
RISK OF BURNS
Do not exceed maximum wattage on LED strip label used with this
•
profile.
Follow all manufacturer's warnings and recommendations for the
•
driver type, mounting position, methods, replacements and recycling.
For indoor applications: grooves (profile can fit slim design and thin furniture pieces, wall surfaces and drywall).
Installation Guide:
1.
Make sure that groove is deep enough to take the entire depth of the profile (Figure 1).
Figure 1
LED STRIP PROFILE
FOR MODEL: AU-CH102&AU-CH103
Aurora Lighting Inc., 12035 34th St N, Suite 2, St Petersburg, FL 33716 USA
Website: www.auroralighting.com Email: info@auroralighting.com
Document Version - IS_AU-CH102-103 V2
WARNING
CAUTION
If electrical appliances are disposed of in landfill or dumps, hazardous
•
substances can be damaging to health and well-being.
The LED strip used with this profile is not intended for use with
•
emergency exit fixtures or emergency exit lights.
Improper Installation will VOID warranty
•
WARNING
RISK OF FIRE
Operating Temperature is -4°F to 122°F / -20°C to 50°C "Keep LED
•
Strip out of direct sunlight"
Incorrect installation may result in electrical shock or a risk of a fire
•
