- Page 1 Keysight Technologies Making Time Domain Measurement with Continuous Source Using SMU B2900A Precision Source/Measure Unit Demo Guide...
- Page 2 The Keysight B2900A Series Precision Source/Measure Unit (SMU) is a compact and cost-effective bench-top SMU with the capability to output and measure both voltage and current. The B2900A Series SMU enables you to make a wide range of current versus voltage (IV) measurements more accurately and quickly than ever before. In...
- Page 3 03 | Keysight | Making Time Domain Measurement with Continuous Source Using SMU – Demo Guide Figure 2 shows the timing chart for the time domain measurement with continuous source with the front panel operation. In this case, the specified source value is sourced immediately after turning on the channel by pressing .
- Page 4 04 | Keysight | Making Time Domain Measurement with Continuous Source Using SMU – Demo Guide LAB: Make Time Domain Measurement with Continuous Source Using SMU Demonstration Objective 1. Change View mode to Channel 1 Single View This demo illustrates the function to make a time domain 1) Press repeatedly until the Channel 1...
- Page 5 05 | Keysight | Making Time Domain Measurement with Continuous Source Using SMU – Demo Guide 5) Press to change the keys shown in Assist keys, and then press to show Sweep Sub-Panel. 6) Press , then press to turn on Single Linear Sweep Mode. After turning on Single Linear Sweep Mode, you can see Source Shape which shows the single linear sweep mode.
- Page 6 06 | Keysight | Making Time Domain Measurement with Continuous Source Using SMU – Demo Guide 10) Rotate to select Channel 1 Trigger Parameters and set them up as below. Measurement Trigger Count defines the number of sampling and Measurement Trigger Period defines the interval of sampling.
- Page 7 2) Rotate and press to edit the Y-axis scaling, and then enter 2 V to adjust the graph scale. Now you can see the measurement result on the GUI of the B2900A series SMU as below.
- Page 8 08 | Keysight | Making Time Domain Measurement with Continuous Source Using SMU – Demo Guide 6. View the list of measurement results The measurement results including the measurement time stamp can be referred by the following steps. 1) If you aren’t on the top of the Function menu, press repeatedly to return to the top level.
- Page 9 In the default setting, the instrument selects the appropriate measurement speed and range automatically to get the fine accuracy. However, you can also specify these pa- rameters on the GUI of the B2900A series SMU to meet a variety of the requirement to the measurement conditions.
- Page 10 SMU with the capability to output and measure both voltage and current. Configuring the B2900A series SMU properly enables you not only to make a simple current versus voltage (IV) measurement, but also to make a time domain measurement with sourcing continuous current or voltage as if it were an oscilloscope.
- Page 11 Get the best of both worlds: Keysight’s measurement expertise and product www.keysight.com/go/quality breadth, combined with channel partner convenience. Keysight Technologies, Inc. DEKRA Certified ISO 9001:2015 www.keysight.com/find/b2900a Quality Management System This information is subject to change without notice. © Keysight Technologies, 2016 Published in USA, September 13, 2016 5992-1772EN www.keysight.com...
