- Page 1 C O N F I G U R A T I O N G U I D E Keysight B2980A Series Femto/Picoammeter and Electrometer/High Resistance Meter The world’s only graphical Picoammeter/Electrometer that can confidently measure down to 0.01 fA and up to 10 PΩ...
-
Page 2: Table Of Contents
Table of Contents Configure Your Keysight B2980A Series Femto/Picoammeter & Electrometer ����������������03 Step 1� Select a B2980A Series model ��������������������������������������������������������������������������������03 Step 2� Add optional localized User’s Guide �����������������������������������������������������������������������05 Step 3� Add optional productivity tools ��������������������������������������������������������������������������������05 Step 4� Choose optional accessories������������������������������������������������������������������������������������06 Step 4�... -
Page 3: Configure Your Keysight B2980A Series Femto/Picoammeter & Electrometer
This configuration guide contains a step-by-step process to help you configure your Femto/Picoammeter & Electrometer and related accessories to meet your specific test requirements� For detailed specifications, refer to the B2980A Series Femto/Picoammeter & Electrometer data sheet (literature number 5991-4878EN)�... - Page 4 The following items are supplied as standard with each B2980A Series model: Standard furnished items Number of pieces Description Orderable parts number B2981A B2983A B2985A B2987A Quick startup poster/Quick reference Product reference (manuals) CD-ROM Keysight IO Libraries CD-ROM Power cord...
-
Page 5: Step 2. Add Optional Localized User's Guide
Step 2. Add optional localized User’s Guide The B2980A manuals (User’s Guide etc�) are included in the CD-ROM shipped with the B2980A as PDF files� Printed manuals are not furnished� Order the following product number if required� Description Product Number Additional Information User Guide English for B2980 Series N1403A-ABA... -
Page 6: Step 4. Choose Optional Accessories
Step 4. Choose optional accessories Step 4-1. Choose a rack mount kit (optional) Applicable Model Description Product Number Additional Information B2981A B2983A B2985A B2987A Rack Mount Kit B2980A-1CM Includes a rack mount flange and front handle kit. √ √ √ √... - Page 7 Step 4. Choose optional accessories (continued) Step 4-3. Choose additional accessories for resistance measurements (optional) You can add the following accessories based on your measurement requirements� Also, you can add the optional N1414A High resistance measurement universal adapter which enables you to simplify the cabling and monitor source voltage at high resistance measurements�...
- Page 8 Step 4. Choose optional accessories (continued) The B2985A/87A supports the Keysight’s accessories for high resistance measurement� The N1413A High resistance meter fixture adapter is needed to use those accessories� Description Product Number Additional Information High resistance meter fixture adapter N1413A Resistivity Cell for N1413 with B2980 Series N1424A The N1413A High resistance meter fixture adapter is required to use these...
- Page 9 Step 4. Choose optional accessories (continued) Step 4-4. Choose additional accessories for voltage measurements (optional) You can add the following accessories based on your measurement requirements� Recommended Connection Simple Connection Typical connection Guarded measurement connection Guarded measurement connection example N1416A/B 16494A, Triax bulkhead connector N1415A...
-
Page 10: Step 4. Choose Optional Accessories
Step 4. Choose optional accessories (continued) Step 4-6. Choose additional accessories (optional) You can add the following optional accessories to meet your system requirement� Applicable Model Product Description Number Additional Information B2981A B2983A B2985A B2987A High value resistor box for N1299A-301 N1422A √... -
Page 11: Step 5. Choose Calibration Plan
Step 4. Choose optional accessories (continued) Applicable Model Product Description Number Additional Information B2981A B2983A B2985A B2987A Interlock cable, 4 pin terminal plug to 6 N1411A √ √ pin circular plug, 1.5 m The B2985A/87A is furnished with one 4 pin plug interlock connector head. -
Page 12: Related Literature
For more information on Keysight Technologies’ products, applications or services, please contact your local Keysight office. The complete list is available at: www.keysight.com/find/contactus Find us at www.keysight.com Page 12 This information is subject to change without notice. © Keysight Technologies, 2018, Published in USA, May 23, 2018, 5991-4879EN...
