Specifications - Tripp Lite SMART5000XFMRXL Specifications

Expandable runtime with optional BP48V60RT3U external battery packs
Half/full load runtime of 27/10 minutes with internal batteries
Includes 11 output receptacles (2 L6-20, 1 L6-30 & 8 NEMA 5-15/20R)
Ships with installed L6-30P input plug, supports user supplied 50A replacement plug or hardwire input
Integrated 8 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual devices
3 stage metered LEDs offer current monitoring and battery charge level
Mains power and voltage regulation LEDs offer at-a-glance power status information
Front panel switches support self-test and alarm cancel functions
Included adjustable mounting rails support installation in 4 post 19 inch racks
UPS ships fully assembled in full compliance with DOT regulations, no time consuming connection of internal batteries by user is required
Supports 2 post rackmount installation with optional 2POSTRMKIT accessory
Supports upright tower placement with optional 2-9USTAND accessory

Specifications

OUTPUT
Output Volt Amp Capacity
(VA)
Output kVA capacity (kVA)
Output Watt Capacity
(watts)
Output kW capacity
Output power factor
Nominal Output
Voltage(s) Supported
Frequency compatibility
Output voltage regulation
(line mode)
Output voltage regulation
(Battery mode)
Built-in UPS output
receptacles
Built-in controllable
switched load banks
Output circuit breaker
Output AC waveform (AC
mode)
Output AC waveform
(battery mode)
INPUT
Rated input current (at
maximum load)
Nominal Input Voltage(s)
Supported
UPS input connection type
UPS Input cord length (ft.)
UPS Input cord length (m)
5000
5
3750
3.8
0.8
120V; 208V
60 Hz
208 & 120V (+/- 10%)
+/- 5%
8 5-15/20R outlet(s); 2 L6-20R outlet(s); 1 L6-30R outlet(s)
Eight switchable single-outlet 5-15/20R load banks
20A double pole breaker supports L6-20R outlets, 20A branch rated breaker (x2) supports 4 5-15/20R outlets
each, L6-30R outlet is unbreakered
Sine wave
Pure Sine wave
27A
208V AC
L6-30P
10
3
