Tripp Lite SMART5000XFMRXL Specifications

Model #: SMART5000XFMRXL
SmartPro 5kVA Line Interactive Sine Wave UPS, Extended-run & SNMPWEBCARD options, 3U Rack/Tower,
USB, Serial, EPO, 208+120V
Description
Tripp Lite 5kVA Smart RM UPS. 5000VA line-interactive UPS for server, network and telecommunications equipment. UPS with internal batteries
requires 3 rack spaces installed. Accepts 208V nominal input voltage. Simultaneous 208 & 120V output. Corrects brownouts and overvoltages from
167V to 260V. Sine wave output. Maintains battery-derived AC output during blackouts and severe voltage fluctuations. Expandable runtime with
optional external battery packs. 11 output receptacles. NEMA L6-30P input connection with support for user-supplied 50A or hardwire input.
Network-grade AC surge and noise suppression. Network management interfaces include USB, DB9 serial and SNMPWEBCARD slot. Supports
simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all network interfaces simultaneously.
Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated 8-bank switched PDU. 3-stage
metered current monitoring and battery charge LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rack mounting
accessories included; 2-9USTAND and 2POSTRMKITWM accessories available. Field-replaceable, hot-swappable internal batteries and battery
packs. Attractive all-black color scheme.
Package Includes
SMART 5000XFMRXL UPS System
PowerAlert Software and Cabling
Mounting hardware for 4-post rackmount installation
Instruction manual
Features
5000VA/3750 watt max. output power capacity compatible with North American 208V/60Hz input voltage
Supports full output at either 208V or 120V
3U rack/tower UPS installs in standard 19 inch rack enclosures with an installed depth of only 22.5 inches
Protects sensitive networking equipment from blackouts, voltage fluctuations and transient surges
Line Interactive Automatic Voltage Regulation (AVR) corrects 208V nominal input from 167 to 260VAC back to usable 208/120V levels
without consuming battery power
AVR circuits boost undervoltages by 12% and reduce overvoltages by 12%
Network interfaces support simultaneous communications via USB, DB9 serial and SNMPWEBCARD slot
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus
any number of additional servers over IP
Communications ports support on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge
current, battery capacity, internal UPS temperature, AC line frequency, timed inverter shutoff, activate self-test and load bank output power
control
Built-in Emergency Power Off (EPO) interface with cable
Sine wave output in AC and battery mode
Highlights
5kVA / 5000VA line interactive 3U rack/tower UPS; Sine wave output
208 & 120V output during brownouts to 167 and overvoltages to 260V
USB, Serial, EPO & optional SNMP/Web card monitoring options
3U all-in-one chassis; 8 single-outlet switched load banks; 95% efficiency
NEMA L6-30P input; 8 NEMA 5-15/20R, 2 L6-20R & 1 L6-30R outlets
