Tripp Lite SmartPro SMART5000RT3U Specification Sheet

Model #: SMART5000RT3U
SmartPro 5kVA Line Interactive Sine Wave UPS, Extended-run & SNMPWEBCARD options, 6U Rack/Tower,
USB, Serial, EPO, 208+120V
Description
Tripp Lite's line-interactive SMART5000RT3U UPS System protects server, networking or telecommunications equipment from blackouts, voltage
fluctuations and surges in a compact tower/rackmount housing. In rack configuration, the power module and battery pack occupy only 3 rack spaces
(3U) each. Large capacity 5000VA/4000W power module converts raw 208V AC input to fully regulated dual output 208/120 voltage for simultaneous
protection of both high- and low-voltage equipment loads. True sine wave output at all times offers guaranteed compatibility with all equipment
types. Includes 14 outlets, 8 of which can be individually reset via software interface to selectively reboot remote equipment or shed less critical
loads to extend battery runtime for more critical equipment. Battery support can be extended indefinitely with additional external 3U rackmount
battery packs. Includes slot for internal SNMP/web card, plus two DB9 and two USB enhanced monitoring ports for unattended shutdown, remote
control and monitoring of UPS system and power data.
Package Includes
SMART5000RT3U UPS System
BP48V60RT3U battery pack
PowerAlert Software and cabling
Mounting hardware
Instruction manual
Features
Large 5000VA/4000W output capacity with full-time sine wave output offers guaranteed compatibility with all equipment types
High power density 5kVA power module and battery pack occupy only 3 rack spaces (3U) each (UPS and battery pack require 6U total
installed)
38 min. half load runtime, expandable with multiple external battery packs (part# BP48V60RT3U)
Line-interactive voltage regulation corrects severe brownouts and overvoltages without using battery power
Dual voltage output is simultaneously compatible with both 208V and 120V equipment
14 total outlets (120V: 10 x 5-15R, 2 x 5-20R/208V: 1 x L6-30R, 1 x L14-30R)
Diagnostic LEDs provide visual indication of 17 separate performance conditions
Included PowerAlert Software provides e-mail notification of power problems and simultaneous automatic unattended shutdown of multiple
servers
4 built-in communications ports (2 x DB9, 2 x USB) for remote monitoring and unattended shutdown
Slot for SNMP/web card
8 customized load management receptacles can be individually powered off and back on again via software interface to reboot remote
equipment or perform "load shedding" of less critical loads to extend battery runtime for the most critical equipment
Emergency Power Off (EPO) interface for emergency shutoff in large facilities
Hot-swappable/user replaceable external battery pack(s) allow on-site battery replacement without powering off connected equipment or
Highlights
SNMPWEBCARD and environmental sensor
5kVA / 5000VA / 4000W line interactive 6U rack/tower UPS; Sine wave output
208 & 120V output during brownouts to 151V and overvoltages to 260V
USB, Serial, EPO & optional SNMP/Web card monitoring options
Expandable runtime; 8 single-outlet switched output load banks
NEMA L6-30P input; 10 5-15R, 2 5-15/20R, 1 L6-30R & 1 L14-30R outlets
ENVIROSENSE for remote communications in large IP environments
