Tripp Lite SMART5000TEL3U Specification Sheet

Model #: SMART5000TEL3U
SmartPro 5kVA Line Interactive Sine Wave UPS, SNMPWEBCARD option, 3U Rack/Tower, USB, Serial, EPO,
208V
Description
Tripp Lite's SMART5000TEL3U intelligent, line interactive UPS protects server, networking and telecommunications equipment from blackouts,
voltage fluctuations and surges in a compact rackmount housing. Completely self-contained UPS system occupies only 3 rack spaces (3U) in a
standard 19 inch rack, making this model one of the smallest 5kVA UPS systems available. Included accessories support mounting 4 post rack
enclosures. Large capacity 5000 VA/3750 watt UPS system accepts raw 208/240V AC input, adjusting output to normal 208V levels. One pair of
120V outlets support up to 600VA monitors and other low voltage accessories. Includes slot for internal SNMP/web card, plus 2 DB9 and 2 USB
enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS system and power data. Five outlets (two L6-20R, one
L6-30R and two 5-15R) allow the connection of high current 20 and 30 amp 208V connectors and up to two 120V devices (max 600VA at 120V).
Package Includes
SMART5000TEL3U UPS System
PowerAlert Software and cabling
Mounting hardware
Instruction manual
Features
Large 5000VA/3750-watt output capacity accommodates solitary large loads or multiple low-power loads
High power density 5kVA power module occupies only 3 rack spaces (3U)
16 minutes half-load runtime (with a continuous load 2500VA; much longer runtime available at smaller loads)
Line-interactive voltage regulation corrects severe brownouts and overvoltages without using battery power
High voltage output supports 208V server, internetworking and telecom applications
Pair of 120V outlets supports up to 600VA for standard 120V monitors, voicemail and other low-power networking devices
Five total outlets (two L6-20R, one L6-30R and two 5-15R)
Diagnostic LEDs provide visual indication of 17 separate performance conditions
Included PowerAlert Software provides e-mail or pager notification of power problems and simultaneous automatic unattended shutdown of
multiple servers
4 built-in communications ports (2 USB/2 DB9) for remote monitoring and unattended shutdown
Slot for SNMP/web card (part#: SNMPWEBCARD) and environmental sensor (part#: ENVIROSENSE) for remote communications in large
IP environments
Emergency Power Off (EPO) interface for emergency shutoff in large facilities
Hot-swappable/user-replaceable batteries allow on-site battery replacement through the front panel without powering off connected
equipment or removing the UPS from the rack
UPS ships fully assembled and ready for installation; no time-consuming user battery connections required
Highlights
5kVA / 5000VA line interactive 3U rack/tower UPS; Sine wave output
208V nominal output during inputs of 174-282V; Supports 600VA 120V output
USB, Serial, EPO & optional SNMP/Web card monitoring options
95% line-mode efficiency; Hot-swappable internal batteries
NEMA L6-30P input; 2 NEMA 5-15R, 2 L6-20R & 1 L6-30R outlets
