Installation
To install the controller:
1. Remove the controller cover and locate the wire connector.
2. Connect the telephone line wires to the TELCO TIP and
RING terminals.
3. Connect the stripped cable wires of the indoor telephone
unit to the HOUSE TIP and RING terminals.
4. Connect the audio wires from the outdoor unit to the
KEYPAD1 TIP and RING terminals. If there is another
outdoor unit, connect the audio wires to KEYPAD2 TIP
and RING terminals.
5. Connect the 12V power wires from the outdoor unit to the
KEYPAD1 POWER V+ and V- terminals. If there is
another outdoor unit, connect the 12V power wires (if
available) to the KEYPAD2 POWER V+ and V-
terminals.
It is strongly recommended to use a 0.8 mm
section wire, so that the device will work properly at a
distance of up to 100 m.
6. Optional: Connect the wires of a backup battery to the
BATTERY V+ and V- terminals. A backup battery
supplies power to a powered-locked-state type door lock
relay in case of power failure so that the door can be
opened. A battery charger should be connected to the
CHARGER V+ and V- terminals.
7. Place the controller on its mounting bracket.
8. Plug the transformer output cable into the Power connector
located at the side of the controller.
9. Plug the transformer into a power outlet.
2.4

LED Indications

The door panels are equipped with three green LEDs located
between the keypad and panel body, as displayed in Figure 7.
When inactive, these LEDs are invisible, but when activated
their emitted light is clearly visible.
