Installation
To install the PanDoor Panel:
1. Remove the PanDoor panel cover and locate the wire
connector.
2. Connect the 12V wires from the controller to the +12V and
-12V terminals.
3. Connect the audio wires from the controller to the TIP and
RING terminals.
4. Connect the door lock relay wires to the DLR and -DLR
terminals. Alternatively, if the door lock relay is a powered-
locked-state type lock, connect the door lock relay wires to
the /DLR and -DLR terminals.
5. If an external bypass switch is installed, connect its wires to
the SW and /SW terminals.
6. Place the PanDoor panel onto its mounting bracket.
7. If required to install another outdoor unit, repeat steps
1 to 6.
2.3

Installing the Controller

The controller is installed indoors. It receives power from a
12VAC transformer supplied with the unit. The controller
powers the outdoor units through 12VDC wires connected to its
KEYPAD POWER terminals.
Figure 6 illustrates the terminal locations on the wire connector
of the controller.
Verify correct connection of the connectors to the
controller. The polarity sign (+ or -) appears on the
connectors.
10 PanDoor Installation and Programming Manual
Note
