Pro'sKit MT-7602 User Manual

4 in 1 fiber optic power multi-meter
Hide thumbs

Advertisement

Quick Links

Download this manual
4 IN 1 Fiber Optic Power Multi-Meter
4 IN 1 Fiber Optic Power Multi-Meter
MT-7602 USER'S GUIDE
MT-7602 USER'S GUIDE
English

Advertisement

loading

Related Manuals for Pro'sKit MT-7602

Summary of Contents for Pro'sKit MT-7602

  • Page 1 4 IN 1 Fiber Optic Power Multi-Meter 4 IN 1 Fiber Optic Power Multi-Meter MT-7602 USER'S GUIDE MT-7602 USER'S GUIDE English...
  • Page 3 USER'S GUIDE 4 IN 1 Fiber Optic Power Multi-Meter English...

  • Page 4: Precautions For Use

    WARNING WARNING You are cautioned that changes or modifications not espressly approved in this document could void yout authority to operate this equipment.To reduce the risk of fire or electric shock,do not expose this apparatus to rain or moisture.To avoid electrical shock, do not open the cabinet.
  • Page 5 Description UNIT GLINT FUNC 1 2 3 4 5 6 7 8 1-InGaAs detector(FC/UPP) 2-LED 3-VFL optic adapter 4-LCD 5-Wavelength Select Button 6-Glint@VFL and Unit@VFL Function Button 7-Switch/Function Select Button 8-Network cable LED 9-MiniUSB Charging Socket 10-RJ45 Testing Socket 11-RJ11 Testing Socket...

  • Page 6: Installing The Battery

    Installing the battery 1.Pull the battery cover lock 2.Raise the battery cover 3.Installing the battery correctly 4.Push the battery cover and lock...
  • Page 7 On/Off and Permanent On UNIT GLINT FUNC 1 2 3 4 5 6 7 8 FUNC Press FUNC button will turn on the meter . Press button again for two seconds or more will turn off the meter. This meter has a power-saving function, normal boot and ten minutes without any operation, the device will automatically shut down.

  • Page 8: Function Selection

    Function Selection Optical Power Meter Visual Fault Locator UNIT GLINT FUNC FUNC 1 2 3 4 5 6 7 8 Flashlight Network cable/ Telephone wire Testing After booting, the default function is the optical power meter. Press button, you can cycle FUNC through switch to Optical Power Meter, VFL, Flashlight, Network cable/Telephone wire Tester.

  • Page 9: Optical Power Meter

    Optical Power Meter Optical Power Meter UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 As optical power meter, press button can select different wavelengths to measure. This meter's standardized wavelengths are 850nm, 1300nm, 1490nm, 1550nm, 1625nm. The unit displayed is mW / uW value and dBm value, which can switch through pressing button.

  • Page 10: Visual Fault Locator

    Visual Fault Locator Visual Fault Locator UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT As a visual fault locator, press button, you GLINT can choose the laser remains on or flashing. In the flashing state, the screen display identifier , and the flashing frequency is 2Hz.

  • Page 11: Led Flashlight

    LED Flashlight Flashlight UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT As a LED flashlight, press button, you can GLINT choose the LED light remains on or flashing in SOS encoding mode. Under SOS function status , the screen display identifier...
  • Page 12 Network cable/Telephone wire Tester Network cable/ Telephone wire Testing UNIT GLINT FUNC 1 2 3 4 5 6 7 8 Network cable/ Telephone wire Remote Network cable/Telephone wire testing function is used to cabling network, connecting and disconnecting network cable, verifying the line sequence. It cloud starts testing when this function be chosen.

  • Page 13: Power Indicator

    Power Indicator UNIT GLINT FUNC 1 2 3 4 5 6 7 8 Four levels indication of power detection Represents the remaining 80%---100% electricity Represents the remaining 40%---80% electricity Represents the remaining 20%---40% electricity Represents the remaining electricity less than 20%...
  • Page 14 Charge The instrument has a charging function. When use rechargeable batteries and a low battery indication shows on the instrument, you should promptly shut down it and recharge. Long time undervoltage will shorten the lifetime of the rechargeable battery. Connect the AC adapter to the device correctly, it can charge Automatically.

  • Page 15: Meter Maintenance

    Meter Maintenance General maintenance Optical fiber connect the adapter should avoid contacting with hard objects and keep clean. Should be stored in a dry and ventilated place to avoid moisture. When un use for long time,should remove the batteries before storage. Fault and solution Failure name Failure Cause...
  • Page 16 Detail Parameters MT-7602 Measurement -70~+6dBm Range 850nm,1300nm,1310nm,1490nm,1550nm,1625nm Wavelength cal. +6~-60dBm(0.01dB)/-60~-70dBm(0.1dB) Resolution (1550nm,1310nm) 0.2dB/(1490nm,1625nm) 0.3dB Accuracy /(850nm,1300nm) 0.4dB Linearity Freq. 270Hz,1KHz,2KHz Identification Detector type InGaAs Optic adapter FC/UPP Application 9/125 m~62.5/125 m fiber type Response range 700~1700nm Auto off Battery Type SIZE AA *2 >100H(Only OPM)
  • Page 19 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 2-LED- 3-VFL- (2.5mm UPP) ( VFL LED 9-MiniUSB 10-RJ45 11-RJ11...
  • Page 21 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 FUNC FUNC FUNC PERM...
  • Page 22 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 FUNC FUNC...
  • Page 23 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 850,1300,1310, 1490,1550,1625nm mW/uW UNIT GLINT UNIT GLINT...
  • Page 24 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT GLINT...
  • Page 25 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT GLINT...
  • Page 26 UNIT GLINT FUNC 1 2 3 4 5 6 7 8...
  • Page 27 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 80%---100% 40%---80% 20%---40%...
  • Page 28 UNIT GLINT FUNC 5V_500mA 1 2 3 4 5 6 7 8...
  • Page 30 MT-7602 -70~+6dBm 850nm,1300nm,1310nm,1490nm,1550nm,1625nm +6~-60dBm(0.01dB)/-60~-70dBm(0.1dB) (1550nm,1310nm) 0.2dB/(1490nm,1625nm) 0.3dB /(850nm,1300nm) 0.4dB 270Hz,1KHz,2KHz InGaAs /2.5mm 9/125 m~62.5/125 m 700~1700nm SIZE AA *2 >100H( 635~650nm,1mW,2.5mm Universal UTP LAN cable(8P8C),Telecom cable(6P2C/6P4C/6P6C) -10 ~+60 -20 ~+70 <90% 125mm*52mm*34mm 90g( -10dBm@1550nm 23 2 40%~60% +10~+5 dBm -62~-70 dBm...
  • Page 33 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 2-LED- 3-VFL- (2.5mm UPP) ( VFL LED 9-MiniUSB 10-RJ45 11-RJ11...
  • Page 35 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 FUNC FUNC FUNC PERM...
  • Page 36 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 FUNC FUNC...
  • Page 37 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 850,1300,1310, 1490,1550,1625nm mW/uW UNIT GLINT UNIT GLINT...
  • Page 38 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT GLINT...
  • Page 39 UNIT GLINT FUNC UNIT GLINT 1 2 3 4 5 6 7 8 UNIT GLINT...
  • Page 40 UNIT GLINT FUNC 1 2 3 4 5 6 7 8...
  • Page 41 UNIT GLINT FUNC 1 2 3 4 5 6 7 8 80%---100% 40%---80% 20%---40%...
  • Page 42 UNIT GLINT FUNC 5V_500mA 1 2 3 4 5 6 7 8...
  • Page 44 MT-7602 -70~+6dBm 850nm,1300nm,1310nm,1490nm,1550nm,1625nm +6~-60dBm(0.01dB)/-60~-70dBm(0.1dB) (1550nm,1310nm) 0.2dB/(1490nm,1625nm) 0.3dB /(850nm,1300nm) 0.4dB 270Hz,1KHz,2KHz InGaAs /2.5mm 9/125 m~62.5/125 m 700~1700nm SIZE AA *2 >100H( 635~650nm,1mW,2.5mm Universal UTP LAN cable(8P8C),Telecom cable(6P2C/6P4C/6P6C) -10 ~+60 -20 ~+70 <90% 125mm*52mm*34mm 90g( -10dBm@1550nm 23 2 40%~60% +10~+5 dBm -62~-70 dBm...
  • Page 45 MT-7602 1365 25 021-68183050 www.prokits.com.tw...
  • Page 48 PROKIT'S INDUSTRIES CO.,LTD http://www.prokits.com.tw Email: pk@mail.prokits.com.tw 2020 Prokit's lndustries Co rights reserved 2 020001C...
