Pro'sKit MT-2018 User Manual

Protective Function
MT-2018
Analog Multimeter
User's Manual
st ,
1 Edition 2011
©2011 Copyright by Prokit's Industries Co., Ltd.
Test
Range
Functions
DC V 0-0.1-0.5-2.5-10
-50-250 V
-1000V
AC V 0-10-50-250V
-1000V
DC mA 0-0.05-2.5-25-
250 mA,
Ω X 1: 0.2 ~ 2KΩ
midscale at 20Ω
X 10: 2 ~ 20KΩ
Midscale at
200Ω X 100: 20
~ 200KΩ
Midscale at
2000Ω X1K:
200~ 2MΩ
Midscale at
Accuracy Remarks
 3% FSD.
Input Impendence:
 4% FSD.
20KΩ/V Overload
For 1000V Protection: Max.
1000V AC/DC
BUT 0.1V/0.5V/
2.5V/10V/50V
/250V Max.
 4% FSD.
Input Impendence:
 5% FSD.
9KΩ/V Overload
For 1000V Protection: Max.
1000V AC/DC But
10V/50V only 250V
Max. Band width:
40 ~10K Hz
 3% FSD.
Drop Voltage: 250
mV Overload
protected by Fuses
0.5A/250V, and
Oxide Varactor.
<250V AC/DC(5s).
 4% of ARC
Overload protected
of Scale by the Oxide
Length Varactor & Fuse
<250V AC/DC(5s).
2
INTRODUCTION
This Multi-meter is an accurate, safe, battery operated, rear
tilt-stand, easy to operate handheld instrument with robust
protective holster alongside and the adjustable back tilt device
with hook-up design. It can offer accurate, reliable measurement
of DC/AC Voltage, DC Current, Resistance and Diode, LED,
Transistor, Decibels, and Capacitance with very high sensitive
quality movement, and good-designed circuit, as well as mirrored
Aluminum dial plate etc. It has the perfect full overload &
miss-used protection via Fuses, Oxide Varactor & Diodes. It is an
ideal instrument for indoor use in the laboratory, school, workshop,
hobby and home applications.
SPECIFICATIONS
Safety Category: IEC61010-1, CAT II 1000V, CAT III 500V and
Pollution Degree 2.
Common Environment: 23C5C, less than 75% RH.
Temperature Ranges:
0C to 40C, 32 F to 104 F for Operating condition.
-10 C to 50C, 14 F to 122F for Storage condition.
Humidity Scope: Operating condition less than 90% RH.
Storage condition: less than 80% RH.
Size: 160(W) x 105(D)x 40(H) MM
Weight: 380g approx. (including batteries 3pcs)
Accessories: One set of Test Leads; One Spare Fuse: 0.5A/250V,
Optional Accessory: MT-2007-C special for capacitance
measurements 1 set
20KΩ X10K: 2K
~ 20MΩ
Midscale at
200KΩ
Capacitan 0.025-0.25-25uF
ce (uF) (C2),
2000uF(C1)
BATT 0 ~ 1.5V: GOOD
Check - ? – BAD
0 ~ 9V: GOOD
- ? – BAD
Transistor hFE: 0-1000 via
Check special hFE
socket
LED, via special hFE
Diode socket
Check
Decibel -22 dB ~ + 62
dB (0dB=1mW
at 600Ω)
POWER Internal Battery:
Source R6P, AA, 1.5V
2pcs, 6F22,
NEDA1604, 9V
1pc
1
 3% FSD.
Use the Optional
Approximate Accessory Kit
Value MT-2007-C
Use the R x 1K
range
 5% of ARC
Load Current:
of Scale 270mA for 1.5V,
Length 25mA for 9V.
Overload protected
by Fuse & Oxide
Varactor .<250V
AC/DC(5s).
Approximate At Ω X 10 Range
Value
Approximate At Ω X 10 Range
Value
Approximate At ACV ranges
Value
3
