Log Screen - Extech Instruments 42582 User Manual

Automatic Datalogging Mode
In the Automatic Datalogging mode the Model 42580 can automatically measure and
LOG
查询"42582"供应商
store 12,000 readings at a programmed sample rate. Data saved in the Automatic
Datalogging mode can be recalled in the display, printed or transferred to a PC.
Press the F3 softkey from the WELCOME display to access LOG screens 1 and 2:
LOG

Log Screen 1

Press F3 from the WELCOME screen to
LOG
access LOG SCREEN 1.
F1 EXIT: Return to the WELCOME screen
F2 START: Begin automatic Datalogging at the
pre-set sampling interval. Datalogging will
begin at the date/ time programmed in the
SETUP mode.
F3 SET: Setup mode.
F4 NEXT: Advances to LOG SCREEN 2:
Log Screen 2
F1 LOG: Previous Page (previous 100 stored
readings)
F2 N-PG: Next Page (next 100 stored readings)
F3 PRN: Print page
F4 BACK: Return to Log Screen 1
Automatic Datalogging SETUP mode
From LOG SCREEN 1, press the F3
enter the configuration screen:
BEGIN: Date when datalogging will automatically
begin
START: Time of day that datalogging will begin
END: Date when datalogging will end
SUSPEND: Time of day that datalogging will stop
each day
RATE: Sampling interval (time between recorded
readings)
EXPECT: Total memory capacity (12,000)
REMAIN: Memory locations remaining
The two SETUP screens are almost identical; only the softkeys are different (see
diagrams). The softkey functions for both SETUP
screens are as follows:
EXIT: Returns to WELCOME screen.
EDIT: Select display field for editing.
VIEW: Calls up the stored readings log.
NEXT: Switches to SETUP screen 2.
START: Activates the datalogger
CLR: Erases all readings stores in the automatic
datalogger memory.
PRN: Prints the datalogger memory record
BACK: Return to the SETUP screen 1.
00001:12-05
T: 82.0l F
00002:12-05
T: 82.0l F
00003:12-05
T: 82.0l F
EXIT START
LOG SCREEN 1
00001:12-05
T: 82.0l F
00002:12-05
T: 82.0l F
00003:12-05
T: 82.0l F
P-PG N-NP
button to
SET
LOG SCREEN 2
Begin:
Start:
End:
Suspend:
Rate:
Expect:
Remain:
EXIT EDIT
AUTO DATALOGGER SETUP 1
Begin:
Start:
End:
Suspend:
Rate:
Expect:
Remain:
START CLR
AUTO DATALOGGER SETUP 2
7
18:45:00
o
18:45:10
o
18:45:20
o
SET NEXT
18:45:00
o
18:45:10
o
18:45:20
o
PRN BACK
01-01-05
00:00:01
02-02-05
23:59:59
15 secs
12000 Points
11900 Points
VIEW NEXT
01-01-05
00:00:01
02-02-05
23:59:59
15 secs
12000 Points
11900 Points
PRN BACK
Model 42582 Version 6.0 Sept 2007
