Meter Front Panel
1.
Laser pointer beam
2.
Non-contact temperature sensor
3.
LCD Display
4.
Function Softkeys
5.
Keypad
6.
External Contact Probe
7.
Probe Handle
8.
Paper compartment
9.
Printer paper
Meter Side View
1.
Printer
2.
Keypad
3.
LCD Display
4.
AC Adapter
5.
RS-232c TTL jack
6.
External temperature probe input jack
7.
Battery compartment
8.
Tripod mount
9.
IR sensor and laser pointer source
Meter Keypad
1.
Function softkeys F1 – F4
2.
LCD backlight key
3.
Printer paper advance
4.
Power button and measurement
button
5.
UP-DOWN arrow keys
6.
Alpha-numeric keypad
F 1
F 2
O N /O
8
9
1
4
5
6
F1
6
5
2
1
2
3
4
F 3
F 4
6
5
FF
Li ne
Fe ed
7
2
3
7
8
9
1
F2
F3
F4
2
ON / OFF
Line
3
Feed
4
