2. Attach the new display to the door with the 8 nuts. See Figure 5.
Door
Figure 5
1. Connect all the cables to the new display.
2. Turn on the Touch Screen.
You are done! If you need more help, call us at 1-888-660-4655.
LT-6656 Rev 1
Display on door (back view)
4 nuts
4 nuts
Display
assembly
Page 3 of 3
