Attach the new display
1. Secure the new display to the brackets with the 8 screws. See Figure 2.
bracket
Figure 2
Figure 3
Front
Figure 4
LT-6656 Rev 1
Display assembly (back view)
Back
Included screws
Front
Display assembly from above
Included screws
Back
Display assembly side view
8 screws
bracket
display
bracket
bracket
Page 2 of 3
