- Page 1 Keysight N9030B PXA Signal Analyzer Option BU7 85 MHz to 160 MHz Analysis Bandwidth Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 85 MHz to 160 MHz Analysis Bandwidth Retrofit Kit 85 MHz to 160 MHz Analysis Bandwidth Retrofit Kit Products Affected: N9030B PXA Signal Analyzer with Option B85 Serial Numbers: To Be Performed By: (X) Keysight Service Center (X) Personnel Qualified by Keysight...
- Page 4 — Personal computer with internet access and USB port. — USB storage device with > 2 GB free memory — Keysight Calibration and Adjustment software, N7814A TME Calibration Application version E.16.00 or later — Test equipment and computer supported by the X-Series Performance Tests and Adjustment software.
- Page 5 USB Storage Device Configuration Menu 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Keysight License Manager will display a “Successful License Installation” message similar to the one shown in...
- Page 6 1. Cycle power on the signal analyzer. 2. Press System, Show System to display a list of installed options. 3. Verify that the newly installed options N9030B-B1X and N9030B-B1Y appear on the list. Functional Test 1. Tap the message balloon at the bottom of the main display. Tap Clear Message Queue. This will remove out-of-date errors.
- Page 7 If a full calibration is required, arrangements regarding the level of calibration must be made between the end user and the calibration provider. For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL: http://www.keysight.com/find/assist...
- Page 8 This information is subject to change without notice. © Keysight Technologies 2016 Edition 1, February 2016 N9030-90076 www.keysight.com...
