Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number _________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m.,
EST, Friday.
EB14695
EXOCET CEILING FAN
Purchase Date _________________________
1
ITEM #0651842
MODEL #40764
Français p. 20
Lowes.com/harborbreeze

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXOCET 40764 and is the answer not in the manual?

Questions and answers

Related Manuals for Harbor Breeze EXOCET 40764

Summary of Contents for Harbor Breeze EXOCET 40764

  • Page 1 ITEM #0651842 EXOCET CEILING FAN MODEL #40764 Harbor Breeze® is a registered trademark of LF, LLC. All Rights Reserved. Français p. 20 ATTACH YOUR RECEIPT HERE Serial Number _________________________ Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents ..............3 Hardware Contents .

  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Downrod Downrod Pin (preassembled to Downrod [A]) Downrod Clip (preassembled to Downrod [A]) Mounting Bracket Canopy Canopy Cover Motor Assembly Fitter Plate (preassembled to Motor Assembly [G]) Yoke Cover Light Kit Shade Cover Halogen Bulb Blade Arm Blade Motor Screw (preassembled to Motor Assembly [G])

  • Page 4: Hardware Contents

    HARDWARE CONTENTS (shown actual size) Wire Connector Blade Screw Blade Washer Blade Screw Pull Chain Extension Qty. 3 Qty. 9 Qty. 9 Qty. 2 + 1 extra + 1 extra + 1 extra Qty. 9 + 1 extra Secondary Support Washer Secondary Support Screw Qty.

  • Page 5: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure that all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.

  • Page 6: Preparation

    SAFETY INFORMATION CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present. CAUTION: Carefully check all screws, bolts, and nuts on the fan motor assembly to ensure they are secured. PREPARATION Before beginning the assembly of this product, ensure that all parts are present.

  • Page 7: Initial Installation

    INITIAL INSTALLATION 1. Turn off the circuit breakers and the wall switch to the fan supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. Determine the mounting method to use. Standard Mounting is best suited for ceilings 8 ft.
  • Page 8 INITIAL INSTALLATION 4. Attach mounting bracket (D) to outlet box (not Standard included) using screws and washers provided with Mounting the outlet box. CAUTION: It is very important to use the proper hardware when installing the mounting bracket (D) as this will support the fan.
  • Page 9 INITIAL INSTALLATION 7. Slide the downrod (A) into the yoke, align the holes, then re-install the downrod pin (B) and downrod clip (C). Secure with set screws (P) and slide the yoke cover (I) down until it rests on top of the motor assembly (G).
  • Page 10 INITIAL INSTALLATION 10. Install the ball end of the downrod (A) into the opening of the mounting bracket (D). Align a slot in the ball with the tab in the mounting bracket (D). Important: The downrod (A) should not rotate if Slot installed correctly.

  • Page 11: Secondary Hanging System

    SECONDARY HANGING SYSTEM WARNING: Secondary support is required for this Braided Cable product. Failure to follow the steps below could result in property damage and/or personal injury. 1. Feed the loop of the braided cable, preassembled to the motor assembly (G), up through the outlet box mounted Brace in the ceiling.

  • Page 12: Wiring

    WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12 gauges and there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use.

  • Page 13: Final Installation

    FINAL INSTALLATION 1. Remove one of the canopy screws (Q) from the bottom of the mounting bracket (D). Slide the key slot in the canopy (E) over the head of the canopy screw (Q) preassembled to the mounting bracket (D). Twist the canopy (E) clockwise to lock.
  • Page 14 FINAL INSTALLATION 3. Insert three blade screws (BB) along with blade washers (CC) through one blade arm (M) and into one blade (N) and into the blade screw caps (DD). Secure each blade screw (BB) with a Phillips screwdriver (not included), starting with the one in the middle.
  • Page 15 FINAL INSTALLATION 6. Remove shade covers (K) from light kit (J). Install bulbs (L) and replace the shade covers (K). IMPORTANT: Make sure you allow the bulbs (L) and light kit (J) to cool before you replace the bulbs (L). 7.

  • Page 16: Operating Instructions

    OPERATING INSTRUCTIONS 1. The pull chain on the side of the light kit (J) has four positions to control the fan speed. One pull is HIGH, two is MEDIUM, three is LOW, and four turns the fan OFF. The pull chain in the center of the light kit (J) turns the lights ON and OFF.

  • Page 17: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year, lower the canopy to check the downrod assembly, and then tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Bulb Replacement: Use GU-10 halogen bulbs.

  • Page 18: Limited Lifetime Warranty

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. The bulbs are not installed 1. Re-install the bulb(s). correctly. 2. Ensure the 9-pin connectors in the The fan operates 2. The light kit wire plugs are not light kit are connected properly. correctly, but the connected properly.

  • Page 19: Replacement Parts List

    PART # Downrod 0651842-A Mounting Bracket 0651842-D Canopy 0651842-E Canopy Cover 0651842-F Yoke Cover 0651842-I Blade Arm 0651842-M Blade 0651842-N Hardware Kit 0651842-HW Printed in China Harbor Breeze® is a registered trademark of LF, LLC. All Rights Reserved. Lowes.com/harborbreeze 9109 • 120214...
