7. OPERATIONS - BASIC LEVEL
The controller has easy access to resources that are relevant to the user of the oven.
7.1 Adjustment of oven temperature and timer
To adjust oven temperature and timer, perform a quick touch on the
value of the parameter. To advance and/or terminate the adjustement, perform another quick touch on the
key.
ADJUSTMENT OF THE DESIRED TEMPERATURE (SETPOINT) OF
THE OVEN:
Defines the working temperature of the oven. This parameter can be adjusted between the
values defined in F02- Minimum value allowed to configure the oven temperature setpoint and
F03 - Maximum value allowed to configure the oven temperature setpoint.
TIMER ADJUSTMENT:
Defines the cooking time. When the time expires, the audible alarm output is switched on
intermittently until any key on the controller' s front panel is pressed. The timer can be adjusted
between 00:01 and 99:59. The time scale is adjusted in parameter F14 - Time base of the timer.
7.2 Steam activation
The steam operating mode is defined in parameter F18 - Steam Operating Mode. Steam activation depends on
parameters F20 - Time interval between steam activations and F21 - Minimum temperature to activate the steam,
available in the advanced configuration menu. These conditions must be met for the injection of steam in the oven
to occur.
7.2.1 Steam activation times
Press the % key and hold for 4 seconds to adjust. Use the < and > keys to adjust the value of the parameter.
To confirm, perform a quick touch on the%key.
FAN CONTROL MODE:
Selects the control mode for the fan:
[ON,]= On, the fan is controlled via output FAN 1.
i [ALT]= Alternated, reverses the rotation direction of the fan via outputs FAN 1 and FAN 2, in
accordance with parameters F23 and F24.
Turbine shutdown option: If option I09 - Enable the stand-by oven function is set to ''YES'', the turbine output
can be temporarily disabled in the following ways:
- Manual shutdown : Press the < key and hold for approx. 4 seconds.
- Automatic shutdown: Via function F26 - Automatic turbine shutdown after completion of the cooking
time the turbine can be temporarily disabled after completion of the cooking process timer;
The turbine output will remain deactivated respecting the time set in function F25 - Maximum turbine off time after
deactivation and while the timer is not activated, otherwise the turbine will also be activated again. While it is off, a
message will appear on the lower display informing that the turbine is off. You can activate the turbine output
again at any time by pressing < again for 4 seconds.
However, turning off the turbine is only allowed while the timer is deactivated, otherwise an error message will be
displayed indicating that the turbine cannot be switched off.
STEAM OUTPUT ON TIME:
This parameter can be adjusted between 1 and 30 seconds, and the factory default is 5
seconds.
STEAM OUTPUT OFF TIME:
This parameter can be adjusted between 1 and 600 minutes, and the factory default is 3
minutes.
NOTE: This parameter is available for adjustment when the steam control mode selected is
cyclic [F18]=[CYC,].
7.3 Presets
A preset includes the configuration of oven temperature, timer, and steam operating mode. The controller has 20
presets that can be edited by the user, and the presets can be selected in a simplified way.
7.3.1 Preset selection
To select a preset in the controller, perform a quick touch on the
>to select the desired preset.
REC
- QUICK TOUCH: cancel preset selection;
REC
- PRESS AND HOLD: confirm preset selection;
The * icon indicates that the preset mode is active.
7.3.2 Preset configuration
To access the preset configuration menu, keep the
select the parameter to be adjusted, use the
the value of the parameter. To leave the preset menu and return to the normal operating mode (temperature and
REC
time indication), keep the ddddd key pressed down (press and hold) until [----]is displayed.
7.3.2.1 Preset configuration table
FUN FUNCTION
Selects the number of the preset to be
Select the preset to be
[rCnF]
configured. There are 20 presets that can
configured
be customized by the user.
Adjustment of the oven temperature
Oven temperature setpoint
[,rsP]
setpoint for the preset selected by
for the selected preset
parameter [rCnF].
Timer adjustment for the Adjustment of the timer for the preset
[rtm,]
selected by parameter [rCnF].
selected preset
Defines the steam operating mode for the
selected preset [rCnF]:
[OFF,]Off: does not inject steam.
[MAN,]M anual: injects steam when the
%key is pressed.
[AUT,] Automatic: automatically injects
Steam operating mode for
[rUa,]
steam after the timer is activated. The
the selected preset
steam is activated after the time set in F19
has elapsed.
[CYC,]Cyclic: injects steam in cycles
using the times configured in[UAon]
and[UAof].
key. Use the < and > keys to adjust the
SET
REC
ddddd
REC
ddddd key pressed down for 4 seconds. Then use < or > to
REC
key to access the parameter, and then use < or > to adjust
dddd
DESCRIPTION MIN
1
(F02) (F03)
00:01 99:59 F14 18:00
OFF CYC
7.4 Functions lock
SET
7.5 Enable Default (standard) operating mode
IN THIS OPERATING MODE THE FLAME SENSOR IS IGNORED AND THE CONTROLLER WILL
NOT DETECT THE PRESENCE / LACK OF FLAME, BEING ESSENTIAL FOR THE OPERATOR TO
PAY SPECIAL ATTENTION TO THE CONTROL OF THE OVEN IN ORDER TO PREVENT GAS
ACCIDENTS
7.6 STAND-BY Function
When function I09 - Enable stand-by oven functionality is set to YES, the controller can be put on standby at
any time by the user. This functionality allows for the control to be kept disable (all outputs off). To put the
controller on stand-by mode, press > for approx. 4 seconds, until the message [OFF] is displayed.
While the controller is on stand-by, the display will flash the > key icon to indicate for the key to be pressed
againd for 4 seconds to reactivate the oven control.
8. OPERATIONS - ADVANCED LEVEL
8.1 Changing the controller parameters
Use the < or > keys to select the desired function. The value can be edited with a quick touch on the
key. Use the < or > keys to change the value and press the key with a quick touch when ready to save the
configured value and return to the functions menu. To leave the configuration menu and return to the normal
operating mode (temperature and time indication), press
8.2 Parameters table
FUN
[CoD]
Access Code (123)
Temperature sensor indication
[F01]
offset
Minimum value allowed to
c o n f i g u r e t h e o v e n
[F02]
temperature setpoint
Maximum value allowed to
[F03] c o n f i g u r e t h e o v e n
temperature setpoint
Oven temperature differential
[F04]
(Hysteresis)
key and then use < or
Delay to switch off the
[F05] temperature control
when the door of the
oven is opened
Number of attempts to light the
[f06]
flame (GAS-FIRED OVEN)
MAX UNIT DEFA
-
20
1
Ignition output on time (GAS-
[f07]
FIRED OVEN)
ºC 180
(ºF) (356)
Interval between activations
[f08]
of the ignition output (GAS-
FIRED OVEN)
Delay to activation of the
i g n i t i o n o u t p u t a f t e r
[F09]
controller start up (GAS-
- FIRED OVEN)
MAN
Delay of the temperature
control after controller start
[F10]
up (GAS-FIRED OVEN)
To enable / disable the function lock, press < and > and hold for the time configured in
parameter. F28 - Time for function lock.
When this configuration is active, the parameters cannot be changed, but they can be viewed.
When the lock is active, the parameters available for adjustment are defined in parameter F27
- Functions Lock.
Icon& indicates the status of the lock. Icon lit indicates the functions lock is active.
To enable the Default (standard) operating mode of the oven, the controller must be powered
up with the $ and % keys pressed until the message appears on the display. This mode is
available when the type of oven selected is GAS. For more details about this operating mode
check item 6.4 Default Mode (standard).
Access the advanced configuration menu by pressing the
[FuNc]is displayed. When [CoD] is displayed press the key again (quick touch). Use the <
or > keys to enter the access code 123 and press
dddd
SET
FUNCTION DESCRIPTION
Required when you want to change the advanced
configuration parameters.
Allows compensating deviations in the
sensor temperature reading.
These parameters serve as the lower and
upper thresholds for the adjustment of
parameter ''SP'' - oven temperature
setpoint. They are used to block
temperature adjustments and to avoid an
improper configuration for the operation of
the oven.
The temperature difference to switch on
the heating output. This function allows
defining a temperature interval within
which the heating output will remain off.
Defines the delay to switch off the
temperature control when the oven door is
opened to allow furnishing the oven without
switching off the control. To disable this
function, change the adjustment to the
minimum until [no,]is displayed. In this
case, the temperature control is switched
off as soon as the door is opened.
Defines the maximum number of attempts
the controller will try to ignite the flame.
After using up all attempts, the controller
will signal error [ER5]-Out of Gas.
Note: This parameter is used when the
type of oven selected is GAS.
Defines the time the ignition output will stay
switched on to try to ignite the flame.
Note: This parameter is used when the
type of oven selected is GAS.
Defines the interval between attempts to
activate the flame.
Note: This parameter is used when the
type of oven selected is GAS
Defines the delay to activate the ignition
output after the gas output is activated in
the first attempt to ignite the flame. This
time is used so that the gas from the
cylinder reaches the burner and then the
ignition is activated.
Note: This parameter is used when the
type of oven selected is GAS.
When the controller is powered up, the fan
is actived first and then the flame ignition
process commences after the time
adjusted in this parameter has elapsed.
Note: This parameter is used when the
type of oven selected is GAS.
dddd SET key for 4 seconds until
dddd SET (quick touch) again when ready.
(press and hold) until [----]is displayed.
MIN MAX UNIT
-
0 9999
-20 20 °C
(-4) (36) (°F)
-10 °C
F03
(14) (°F)
500 °C
F02
(932) (°F)
1 20 ºC
(1) (36) (ºF)
no(0) 180 sec.
-
1 5
sec.
15
1
sec.
1 15
no
sec. no(0)
15
(0)
no
sec.
30
(0)
dddd SET
DEFAU
0
0
(0)
0
(32)
230
(446)
3
(5)
90
3
3
3
1
