INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
4300 SERIES
WOOD APPLIANCES
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBERS:
43M-ACC-C
43ST-ACC-C
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
R
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified.
Failure to comply may cause house fire.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre
revendeur ou visitez
7037-801B
WARNING
WARNING
WARNING
www.quadrafire.com
February 19, 2020

Advertisement

Table of Contents
loading

Related Manuals for Quadra-Fire 4300 Series

Summary of Contents for Quadra-Fire 4300 Series

  • Page 1 INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is 4300 SERIES not followed exactly, a fire could result causing property damage, personal injury, WOOD APPLIANCES or death.

  • Page 2: Table Of Contents

    H. Proper Draft......Quadra-Fire is a registered trademark of Hearth & Home Technologies.

  • Page 3: Important Safety Information

    Important Safety Information A. Appliance Safety Certification C. BTU & Efficiency Specifications Model: 43M-ACC-C & 43ST-ACC-C EPA Certification Number: N/A Number: Laboratory: OMNI Test Laboratories, Inc. EPA Certified Report Number: 0061WS067S 1.6 grams per hour Emissions: Listed Room Appliance, Solid Type: *LHV Tested Efficiency: 80.2% Fuel Type...

  • Page 4: Mobile Home Approved

    D. Mobile Home Approved WARNING • This appliance is approved for mobile home installations; when not installed in a sleeping room and when an outside combustion air inlet is provided. Fire Risk • The structural integrity of the mobile home floor, ceiling, Hearth &...

  • Page 5: Getting Started

    Install Guide Getting Started A. Design and Installation Considerations B. Fire Safety Consideration must be given to: To provide reasonable fire safety, the following should be • Safety given serious consideration: • Convenience 1. Install at least one smoke detector on each floor of •...

  • Page 6: Tools And Supplies Needed

    E. Inspection of Appliance and Components To minimize the effects of negative air pressure: • Install optional outside air kit with the intake facing • Remove appliance and components from packaging prevailing winds during the heating season and inspect for damage. •...

  • Page 7: Removal Of Appliance From Shipping Materials

    F. Removal of Appliance from Shipping Step Top: 1. Remove box and 2x4 structural boards being careful Materials not to damage product. 2. Using 7/16 inch socket or wrench, remove and discard WARNING the two lag bolts from mounting brackets; one on each side, that is attaching the appliance to the pallet Fire Risk.

  • Page 8: Install Checklist

    G. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________ Date Installed: ______________________________________________________________________________ Lot / Address: ________________________________________________________________________ Location of Appliance:...

  • Page 9: Dimensions And Clearances

    Dimensions and Clearances A. Appliance Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 43M-ACC-C 26-1/4 in [667mm] 3-5/8 in 13-1/8 in [92mm] [333mm] 6-3/4 in [170mm] 11 in [278mm] 30-1/2 in [773mm] 15-1/8 in [ 383mm] 21 in [533mm] Figure 9.1 - Front View Figure 9.3 - Top View 28-5/8 in [728mm]...
  • Page 10 43ST-ACC-C WITH PED-KIT-43 (PEDESTAL KIT) 26 in (660mm) 26 in (660mm) 3-1/2 in 13 in [87mm] [330mm] 6-3/4 in [170mm] 11 in 11 in (278mm) (278mm) 34-1/4 in 34-1/4 in (868mm) (868mm) 15-1/8 in (383mm) 15-1/8 in (383mm) 21 in (533mm) 21 in (533mm) Figure 10.1 - Front View Figure 10.3 - Top View...
  • Page 11 43ST-ACC-C WITH LEG-KIT-BK OR LEG-KIT-NL (QUEEN ANNE LEG KIT) 26 in [660mm] 3-1/2 in 13 in [87mm] [330mm] 6-3/4 in [170mm] 11 in [278mm] 32-7/8 in [834mm] 15-1/8 in [383mm] 25 in [636mm] Figure 11.1 - Front View Figure 11.3 - Top View 28-5/8 in [728mm] 26-3/8 in [668mm] 34-1/8 in...
  • Page 12 43ST-ACC-C WITH TRAD-LEG-BK (TRADITIONAL LEG KIT) 26 in [660mm] 3-1/2 in 13 in [87mm] [330mm] 6-3/4 in [170mm] 11 in [278mm] 32-7/8 in [834mm] 15-1/8 in [383mm] 23-3/8 in [595mm] Figure 12.1 - Front View Figure 12.3 - Top View 28-5/8 in [728mm] 26-3/8 in [668mm] 34-1/8 in...

  • Page 13: Hearth Protection Requirements

    B. Hearth Protection Requirements In Canada, similar floor protection must be provided 18 inches (457mm) in front and 8 inches (203mm) EMBER PROTECTION: Ember protection shall be either a from the sides and rear of the appliance unless the Type 1 floor protector or made of non-combustible material hearth pad is placed against the wall (for 43M-ACC-C to the requirements below.
  • Page 14 43ST-ACC-C USA, minimum flat wall hearth pad dimensions 31-5/8 in minimum Corner hearth pad dimensions with single wall pipe 41 in minimum 1440mm 54-3/4 in Fuel loading door 8 in 8 in 16 in 16 in 33-1/8 in 785mm from fuel door from fuel door opening opening...

  • Page 15: Clearances To Combustibles

    C. Clearances to Combustibles MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS in inches (Millimeters) NOTE: A, C, and F Dimensions are to the center of the fl ue collar 43M-ACC-C AND 43ST-ACC-C WOOD APPLIANCE (2020) INSTALLATION: FULL VERTICAL OR HORIZONTAL WITH MINIMUM 2 FOOT VERTICAL OFF STOVE TOP SINGLE WALL PIPE 43M-ACC-C 18-1/2 (470)

  • Page 16: Chimney Systems

    Chimney Systems A. Locating Your Appliance & Chimney Location of the appliance and chimney will affect • Consider the appliance location in order to avoid floor performance. As shown in Figure 16.1 the chimney should: and ceiling attic joists and rafters. •...

  • Page 17: Chimney Termination Requirements

    B. Chimney Termination Requirements NOTICE: Locating the appliance in a basement or in Follow manufacturer’s instructions for clearance, securing a location of considerable air movement flashing and terminating the chimney (Figure 17.1 and can cause intermittent smoke spillage from Figure 17.2). appliance.

  • Page 18: Chimney Height / Rise And Run

    D. Chimney Height / Rise and Run Chimney: The chimney can be new or existing, masonry or This product was designed for and tested on a 6 inch prefabricated and must meet the following minimum (152mm) chimney, 14 to 16 feet (420-480cm) high, requirements and as specified in Section 4 - (includes appliance height) measured from the base of the Chimney Systems.
  • Page 19 Thimble Listed Termination Cap Site constructed for masonry chimney installation: Storm Collar Components A minimum length of 12 inches [305mm] (longer for thicker Flashing walls) of solid insulated factory-built chimney length constructed to UL 103 Type HT 6 inch (152mm) inside diameter.

  • Page 20: Installing Chimney Components

    Figure 20.2 combustibles H. Proper Draft To be sure that your Quadra-Fire appliance burns properly, the chimney draft (static pressure) should be approximately -0.10 inches water column (W.C.) during a high burn and -0.04 inches W.C. during a low burn, measured 6 inches (152mm) above the top of the appliance after one hour of operation at each burn setting.

  • Page 21: Appliance Set-Up

    Appliance Set-Up A. Pedestal Assembly & ARS Installation Remove and discard NOTE: The Ash Removal System, must be installed first before installing the pedestal. Begin installing the ARS System: 1. Remove leg mount brackets packaged inside of firebox and discard. 2.
  • Page 22 Ash Removal Spacer Figure 22.1 Figure 22.4 Door latch with the ash door rod locked in place Ped Kit and Ash Removal System (Cont’d) Knob Installing Ped Kit 1. Follow Begin installing the ARS System instructions provided on page 2. Slide pedestal over adapter on bottom of appliance and secure with bolts from heat shield (Figure 23.1 on page...

  • Page 23: Access Cover Handle

    B. Access Cover Handle Ash Removel Insert Access Cover Handle handle into slot of ARS Cover Drawer to remove ARS Cover for cleaning ash out of firebox (Figure 23.4). Adapters Figure 23.1 Figure 23.4 ARS Access Cover C. Leg Kit & ARS Installation Channel NOTE: The Ash Removal System, must be installed first before installing the legs.
  • Page 24 6. Remove knock out from bottom of firebox by using a hammer (Figure 21.2 on page 21). 7. Install ash door assembly by sliding the rod at an angle Align top holes into the slot on the left side (Figure 21.3 on page 21).

  • Page 25: Traditional Leg Installation

    D. Traditional Leg Installation CAUTION! Installing your traditional legs to your appliance: 1. Remove leg brackets from inside of firebox CHECK BAFFLE BOARDS & CERAMIC BLANKET! of appliance. • Verify that the baffle boards and ceramic blanket are 2. Lay body of appliance on its back on a protective pad in their proper locations.

  • Page 26: Outside Air Kit Installation

    E. Outside Air Kit Installation WARNING A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via Fire Risk. Asphyxiation Risk. air leakage around windows and under doors. In homes Do not draw outside combustion air from: that have tightly sealed doors and windows, an outside air •...

  • Page 27: Door Handle Assembly

    F. Door Handle Assembly 43ST-ACC-C 1. Slide door handle shaft through hole on door 43M-ACC-C (Figure 27.2). Install spring handle using a counter-clockwise motion until 2. Add up to three 3/8 washers on the inside of the door. the spring handle has a 2 inch clearance from bend of door hand rod (Figure 27.1).

  • Page 28: Blower (Optional)

    G. Blower (Optional) 1. Locate bolts supplied with the blower. 2. Align holes in mounting flange of blower with bolt holes in appliance. Blower should be positioned at bottom of rear outer skin as shown in Figure 28.1 3. Re-insert and tighten bolts, securing blower onto outer wall of appliance.

  • Page 29: Mobile Home Installation

    Mobile Home Installation You must use a Quadra-Fire Outside Air Kit Part CAUTION OAK-ACC; and (depending on floor installation), Part SRV7033-041 for installation in a mobile home. THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST 1. An outside air inlet must be provided for combustion.

  • Page 30: Reference Materials

    Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service 7037-801B February 19, 2020...
  • Page 31 Date of Service Performed By Description of Service February 19, 2020 7037-801B...
  • Page 32 Date of Service Performed By Description of Service 7037-801B February 19, 2020...
  • Page 33 Date of Service Performed By Description of Service February 19, 2020 7037-801B...

  • Page 34: 4300 Millennium Accessories

    B. 4300 Millennium Accessories 43M-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.

  • Page 35: 4300 Step Top Accessories

    SRV7000-194 7033-051 Upgrade, Door (Nickel Handles, Hinge Pins & Logo) Snap Disc Bracket Assembly Nickel SRV7033-036 UK-DRNL Snap Disc, # 1, Convection Blower Logo, Quadra-Fire Pkg of 10 SRV230-0470 7000-649/10 Cast Legs, Black Wire Harness (Blower) Set of 4 7033-262...
  • Page 36 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
