Specifications

Video/Audio Input
HDMI
Connectors 8 x HDMI
Embedded PCM/
Audio
Dolby Digital Pass Through
Component/Composite
8 Sets of Mini DIN to 6x RCA
(Y, Pb, Pr) or
Connectors
(Video, Audio L & R) 2.to Mini
DIN?
Audio Analog
EAS
Composite (Video, Audio L & R)
Connectors
from Mini DIN to 6x RCA Cable
Trigger 5-12 VDC & Dry Contact Closure
Mechanism (Terminal Strip)
Output
QAM
Connector 1x "F" Female
Modulation 256-QAM
Standard J.83 Annex B
57 to 861 MHz (Under STD Mode)
Frequency Range
4 Independent RF Frequencies
Channels'
6 MHz
Bandwidth
Output Level 40dBmV (± 1dBmV) Typical
Output Impedance 75 ohm
Level Adjustment 0 to -20 dB
Auto (Major & Minor)/Manual
VCN
(Major & Minor) /Manual (1 Part)
Carrier
55 dB
Suppression
RF Output
10 dB Typical
Return Loss
Signal-to-
42 dB Typical
Noise Ratio
MER 40dB Typical
ASI
Single Connector, 8 Contents in
Connector
MPTS
Format DVB-ASI
Standard ETSI EN 50083-9
GigE
Connector Dual RJ-45
Web Management100Base-T
Ethernet, Full Duplex IP Streaming
Standard
Output 1000Base-T Ethernet,
Full Duplex
MPEG-TS over UDP / RTP
UDP/RTP Unicast and Multicast, 8 Separate
SPTS
NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | DT-IPTV-QAM-ASI-8HCW Manual v1.0
Video/Audio Encoding Profile
Video
Resolution
Video Codecs
MPEG-2
Resolution
Video Codecs
H.264 (HD)
Video Codecs
H.264 (SD)
Aspect Ratio
Video Bitrate
(Bitrate
Adjustable)
Audio
Audio Codecs
Closed Captioning
Mini DIN to 6x
RCA (Y,Pb, Pr;
Y, L, R)
Mini DIN to
Mini DIN with
1x RCA (Y)
General
Forensic
Watermarking
Local Monitoring
Browsers
Supported
Password
Protected
Fan Cooled
Power Supply
Consumption
Dimension
Weight
Language
*Subject to change without notifications
5
1080p (H.264 Only)/
1080i/720p/480p/576i/480i
MP@HL
1080p (H.264 Only)/
1080i/720p/480p/576i/480i
≦1080p30, HP@Level 4
> 1080p30, HP@Level 4.2/
≦720p30, HP@Level 3.1
>720p30, HP@Level 3.2/
≦30, Level 3
Frame Rate> 30, MP@Level 3.1/
4:3 &16:9
MPEG-2 HD:10.0Mbps - 20.0Mbps/
MPEG-2 SD 2.0 Mbps - 8.0 Mbps/
H.264 HD: 2.0Mbps - 10.0Mbps/
H.264 SD: 1.0Mbps - 4.0Mbps
MPEG-2 Layer II/AAC/AC-3
Pass Through/AC-3 Encode
EIA-608; 1x RCA (cc)
EIA-608; 1x RCA (cc)
Capable for users to key in 64
Alphanumeric Characters
(Model Name with Suffix "W")
8 Input Status LEDs /
Single Power LED
Firefox, Chrome
GUI: Changeable
Internal
12VDC 5.4 Amp.
Quad: 30W/Octo: 50W Typical
1RU, Housing:
17.24 in. x 11.25 in. x 1.74 in.
438mm x 286mm x 44.20mm
11.3 lbs.
English
