- Page 1 USER GUIDE AND MANUAL Independent Output Allocation 4-Input Encoder-Modulator with ASI MODEL: DT-IPTV-QAM-ASI-4HC Version 1.0 Last Update: 01-15-2019 DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019...
- Page 2 • 24/7/365 Live Technical Service Support • Expertly Trained and Highly Knowledgeable Sales and Support Team • Full Product Line of Cable and Satellite Infrastructure Products • Customized Site-Survey Process to Ensure Project Success DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019...
-
Page 3: Table Of Contents
Encoder Setup ................................ 9 connecting to a PC/Laptop..............................9 Enter Device's IP address in web browser to access the Overview Page..............9 Overview Page of DT-IPTV-QAM-ASI-4HC ..........................9 System Parsing / Response Time: .............................. 9 GUI Login Password: ..................................9 Encoder Programming and Setup via GUI Interface: ..................... -
Page 4: Safety Precautions
DO NOT cover or obstruct the device’s fan or fan openings. If the device has been in a cold environment allow it to warm to room temperature for at least 2 hours before connecting to an AC outlet. DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019... -
Page 5: Package Contents
Package Contents This package contains: • DT-IPTV-QAM-ASI-4HC Encoder / Modulator • One power cable • Five Mini Din 10pin/6 RCA Cables • Four HDMI Cables • User Guide and Manual Inspect the package before starting installation to ensure there is no damage and all supplied contents are present. -
Page 6: Product Description
4 IP and ASI (MPTS) streams making it ideal for any commercial RF system. The high quality HD design allows for watching action packed movies and sports channels on any HDTV. The DT-IPTV-QAM-ASI-4HC Encoder/Modulator is a feature rich Digital Encoding platform allowing it to be deployed in a variety of installations. This space saving design delivers up to 4 High Quality HD/SD QAM channels in a single 1RU space. -
Page 7: Specifications
GUI: Changeable Fan Cooled Internal Power Supply 12VDC 7.5 Amp Consumption 34W typical 482.7mm x 286mm x 44.2mm / 1RU 19” EIA Dimension (Housing Body: 438mm x 286mm x 44.2mm) *Subject to change without notifications DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019... -
Page 8: Device Programming And Setup
3. Enter ‘192.168.1.9’ into your web browser. 4. Enter GUI and make required device changes. 5. Save all changes as required, upload and reboot for changes to take effect. 6. Verify parameters then end web session. DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019... -
Page 9: Encoder Setup
Enter Device's IP address in web browser to access the Overview Page. Overview Page of DT-IPTV-QAM-ASI-4HC The Overview page of DT-IPTV-QAM-ASI-4HC shows inputs 1-4 system status including: Video Source parameter, Video Output setting, Audio Output, Bitrate, and more. The Overview page provides a quick snapshot of the DT-IPTV-QAM-ASI-4HC when fully functioning. - Page 10 Encoder Setup Page of DT-IPTV-QAM-ASI-4HC Encoder Setup page allows the integrator to select and set the parameters needed for each stream. 1. Select the “Edit” Icon: 2. Select and set the specific parameters settings as required. Note: you can select and set all the parameters for all the encoders at one time.
-
Page 11: Enabling Ip Streams
4. Select ‘Save and Confirm’ once all the streams are setup. Disabling IP Streams The DT-IPTV-QAM-ASI-4HC offers the user a SPTS output stream. Each Stream can be disabled as required. To disable an IP Stream “uncheck” the checkbox in front of the appropriate IP Stream_ID (1-4). -
Page 12: Rf Setup
Use the Output Setup Page to setup each RF Output. The DT-IPTV-QAM-ASI-4HC offers the integrator the ability to set the output channel independently of the other output channels of the DT-IPTV-QAM-ASI-4HC Encoder. This professional parameter allows the integrator greater flexibility for placing video streams within the system. - Page 13 Note: The DT-IPTV-QAM-ASI-4HC allows the integrator the ability to set the output channels independently of the other 3 output channels. Example 1: Example 1 shows RF1- RF2 with a large frequency separation. CH # 54 CH# 120 (405.000 MHz) (771.000 MHz) Example 2: Example 2 shows RF1- RF2 with a small frequency separation.
-
Page 14: Asi Control
3. Select Save and Confirm to save all modified parameters. Disable RF/QAM The DT-IPTV-QAM-ASI-4HC offers the integrator the ability to disable a RF QAM. To disable a RF (QAM) output, “uncheck” the checkbox associated with the RF QAM. Application Notes When installing more than 1 device into a system, each device must have a unique RF TS_ID and ASI TS_ID. -
Page 15: Streaming Ip Setup
Use the Streaming IP tab to modify the Streaming IP port of the device as required. Save and Confirm: Once all parameters are set remember to Save and confirm all changes have been made. Administration Administration Setup Page of DT-IPTV-QAM-ASI-4HC Reboot Device: Use the Reboot command button to reboot the device. -
Page 16: Restore/Upload Saved File Configurations
It is important to note that only some of the 172.xx.xx.xx and the 192.xx.xx.xx address ranges are designated for private use. The remaining addresses are public and can be routable via the global Internet. More information regarding private addresses can be found at http://www.iana.org and https://www.arin.net DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019... -
Page 17: Product Notes
Accordingly, additional statements such as dealer advertising or presentations, whether oral or written, do not constitute warranties by the Company and should not be relied upon. This warranty gives you specific legal rights. You may also have other rights which vary from one jurisdiction to another. DT-IPTV-QAM-ASI-4HC | Manual V1.0 | 01152019...
