- Page 1 Bluetooth Card Reader User Manual UD04705B...
- Page 2 INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
- Page 3 User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 4 User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
- Page 5 User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer recommended battery type.
-
Page 6: Table Of Contents
User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Table of Contents Chapter 1 Introduction ........................6 1.1 Product Overview ....................... 6 1.2 Features and Functions ...................... 6 Chapter 2 Overview .......................... 8 2.1 Structure..........................8 2.2 Cabling Requirements ......................9 Chapter 3 Function Configuration .................... -
Page 7: Chapter 1 Introduction
User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Chapter 1 Introduction 1.1 Product Overview Thank you for purchasing the long range card reading system. For best results, please read the manual carefully, and follow the instructions to install and debug the device. 1.2 Features and Functions ... - Page 8 User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Two operating modes are available: indoor and outdoor. The outdoor mode is applicable to open-air parking, while indoor mode should be set for underground parking as IR signal may be deflected thus interfered. ...
-
Page 9: Chapter 2 Overview
Chapter 2 Overview 2.1 Structure Figure 2-1 Internal Structure... -
Page 10: Cabling Requirements
User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Table 2-1 Description Description Card reading indicators IR emitters Operating mode button (ON for outdoor, otherwise indoor) Function indicator Power indicator 12 V operating power Loop signal interface Wiegand output RS-485 output Relay output Signal strength indicator 2.2 Cabling Requirements... -
Page 11: Chapter 3 Function Configuration
User Manual of DS-TRI4XX-X Series Bluetooth Card Reader Chapter 3 Function Configuration Before you can configure the functions of the device, first enter configuration mode: press and hold S2 button for about 2 seconds, and release the button after hearing a long buzzing sound to enter configuration mode. -
Page 12: Switching Wiegand 26/34
User Manual of DS-TRI4XX-X Series Bluetooth Card Reader 3.4 Switching Wiegand 26/34 Step 1 After entering configuration mode, press S2 button until LED flashes. Step 2 Press S1 button to switch between Wiegand 26 or 34: Wiegand 26 is enabled when the light is on, and Wiegand 34 is enabled when the light is off. - Page 13 User Manual of DS-TRI4XX-X Series Bluetooth Card Reader...
