  • Page 1 Fingerprint Card Reader User Manual...
  • Page 2 Hikvision marks are the property of Hikvision and are registered trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other trademarks mentioned in this manual are the properties of their respective owners. No right of license is given to use such trademarks without express permission.
  • Page 3 BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.
  • Page 4 Fingerprint and Card Reader User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Fingerprint and Card Reader User Manual 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
  • Page 6 Fingerprint and Card Reader User Manual Use only power supplies listed in the user instructions: Model Manufacturer Standard DSA-12PFT-12FUK 120100 Dee Van Enterprise Co., Ltd. DSA-12PFT-12FAU 120100 Dee Van Enterprise Co., Ltd. DSA-12PFT-12FIN 120100 Dee Van Enterprise Co., Ltd. DSA-12PFT-12FUS 120100 Dee Van Enterprise Co., Ltd.
  • Page 7 Fingerprint and Card Reader User Manual  Please use the power adapter, which is provided by normal company. The power consumption cannot be less than the required value.  Do not connect several devices to one power adapter as adapter overload may cause over-heat or fire hazard.
  • Page 8 Fingerprint and Card Reader User Manual  Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger).  Do not aim the device at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.

  • Page 9: Table Of Contents

    Fingerprint and Card Reader User Manual Content Chapter 1 Introduction ............3 Product Overview ............. 3 Product Appearance ..........3 Chapter 2 Installation ............5 Introduction for DIP Switch ........5 Definition of Cable ............ 6 Wiring Cables ............6 Installing Card Reader ..........

  • Page 10: Chapter 1 Introduction

    Fingerprint and Card Reader User Manual Chapter 1 Introduction 1.1 Product Overview Fingerprint and card reader is a kind of high-performance product, with a 32 bit high-speed processor. It communicates with access controller via the RS-485 protocol. And a built-in tamper-proof module helps to protect card reader from malicious damage.
  • Page 11 Fingerprint and Card Reader User Manual Table 1-1 Components Description Name Fingerprint Scanner Cable Interface of RS-485, Power, LED Control, etc. DIP Switch...

  • Page 12: Chapter 2 Installation

    Fingerprint and Card Reader User Manual Chapter 2 Installation 2.1 Introduction for DIP Switch The DIP switch module is shown below. The No. of DIP switch from left to right is 1 to 4, representing the RS-485 address. Figure 2-1 DIP Switch Module Table 1-2 Description of DIP Switch Icon Description...

  • Page 13: Definition Of Cable

    Fingerprint and Card Reader User Manual 2.2 Definition of Cable The description of 5 cables is shown below. Table 1-3 Description of Cables Color Description Blue RS-485 - Yellow RS-485 + PWR (DC +12V) Black GND (Power Grounding) Black GND (RS-485 Grounding) 2.3 Wiring Cables Purpose: Wire the cables between the controller and the card reader, thus to...

  • Page 14: Installing Card Reader

    Fingerprint and Card Reader User Manual Figure 2-3 Wiring for RS-485 Communication Mode 2.4 Installing Card Reader Before you start: Set the DIP switch. For details, refer to 2.1 Introduction for DIP Switch. Steps:...
  • Page 15 Fingerprint and Card Reader User Manual Fix the mounting plate on the wall with 2 provided screws. Note: Do not warp the mounting plate when installing. Connect the cables between the controller and the card reader. For details, refer to 2.3 Wiring Cables.

  • Page 16: Sound Prompt And Indicator

    Fingerprint and Card Reader User Manual Chapter 3 Sound Prompt and Indicator After the card reader is powered on, LED status indicator will turn green and blink for 1 time. Then it will turn red and blink for 3 times. At last the buzzer will send out a beep sound indicating the starting up process is completed.
  • Page 17 Fingerprint and Card Reader User Manual Table 1-5 Description of LED Indicator LED Indicator Status Description Green (blink for 1 time), and red (blink The card reader is power on. for 3 times) For Card + Fingerprint authentication: prompt for pressing the fingerprint after swiping the card.

  • Page 18: Appendix: Tips For Scanning Fingerprint

    Fingerprint and Card Reader User Manual Appendix: Tips for Scanning Fingerprint Recommended Finger Forefinger, middle finger or the third finger. Correct Scanning The figure displayed below is the correct way to scan your finger: You should press your finger on the scanner horizontally. The center of your scanned finger should align with the scanner center.
  • Page 19 Fingerprint and Card Reader User Manual successfully. You can blow your finger and scan again after drying the finger. Others If your fingerprint is shallow, or it is hard to scan your fingerprint, we recommend you to use other authentication methods. If you have injuries on the scanned finger, the scanner may not recognize.
  • Page 20 Fingerprint and Card Reader User Manual UD06570B-A...
