Applied Machines: C554/C454/C364/C284/C224
COLOR MFP: 55 ppm/45 ppm/36 ppm/28 ppm/22 ppm
Product Code: A2XK/A4FJ/A161/A4FK/A4FM
I. Accessory parts
No.
Name
1. Heater
2. Wire saddle
(large)
3. Wire saddle
*1
(medium)
4. Wire saddle
*2
(small)
5. Edge cover
6. Screw
7. Installation
manual
*1
To install the heater to a paper feed cabinet, 14
wire saddles are used.
*2
To install the heater to the Desk, this wire saddle
is not used.
After unpacking, be sure to get rid of the
packaging materials and keep them out of
the reach of children.
Putting the head in the plastic bag
involves danger of suffocation.
HT-509
INSTALLATION MANUAL
Shape
Q'ty
1
A4NHIXC001DA
1
A4NHIXC030DA
15
A4NHIXC029DA
1
A4NHIXC031DA
2
A4NHIXC028DA
4
9J08IXC078DA
1
set
4980IXC019DA
Heater
Note:
• To use the heater HT-509, the paper feed cabi-
net PC-110/210/410 or Desk DK-510 as well as
the power supply Box MK-734 are required.
• This manual provides the illustrations of the
accessory parts and machine that may be
slightly different in shape from yours. In that
case, instead of the illustrations, use the
appearance of your machine to follow the
installation procedure. This does not cause any
significant change or problem with the proce-
dure.
• When the heater HT-509 and the transformer
kit TK-101 are installed at the same time, install
the heater first.
E-1
A4NH-9550-01
