- Page 1 INSTALLATION MANUAL HT-502 Heater Applied Machine: for Product Code 4034/4035 NOTE • Before installing, be sure to unplug the power cord of the machine. • Keep all packing materials out of the reach of children. 4034-7190-01...
- Page 2 HT-502 I Introduction Observe these precautions to prevent accidents. Thoroughly understand the meanings of the symbols before reading the precautions. I Warning and Precaution Symbols Before setting up this unit, be sure to turn OFF the Power Switch Ignoring this warning could cause of the machine and unplug the power cord of the machine.
- Page 3 HT-502 I Unpacking I Installation Position of the Dehumidifier Heater Check that the following accessories are available in the box. The installation position of the dehumidifier heater differs according to the paper feed unit or desk that are installed. Install the dehumidifier heater at the locations shown in Heater....................
- Page 4 HT-502 I Removal of the Power Supply Unit Harness 2. Place the dehumidifier heater on top of 1. Remove two screws from the power box the paper feed unit/desk, and then secure and remove the cover. it with the screws.
- Page 5 HT-502 <When attaching the dehumidifier heater 4. Fix the paper feed unit or the desk to the machine. to the desk> (1) Use four screws C to secure the dehumidifier heater to the desk. Secure the paper feed unit/desk to the machine by using screws.
- Page 6 HT-502 <The desk to the machine> 6. Plug the power cord of the power supply Open the cassette. Fix it with a Plastic Plate and six screws. unit in the machine. 7. Turn on the power supply unit for the dehumidifier heater.
