Summary of Contents for HTC VIVE ENTERPRISE

  • Page 1 Batch configuration for your headset...

  • Page 2: Table Of Contents

    Contents Contents Setup Downloading the config file Downloading the batch configuration template package Batch configuration What is Kiosk mode? Activating Kiosk mode Enabling and disabling features Choosing the apps to show on the headset Packaging the files for installation Installing the batch configuration file on the headset Appendix Country codes Feature version requirements...
  • Page 3 This is a warning. Take note to avoid potential problems or prevent damage to your hardware. Information contained in this guide may have changed. For the most up-to-date information, including the latest version of this guide, contact HTC.

  • Page 4: Setup

    Setup Setup Downloading the config file You need the config file to run batch configure on the headset. ™ All registered VIVE Focus headsets are included in the config file. You do not need different config files for each registered headset. On your computer's Web browser, go to https://enterprise.vive.com/portal/advantage/ focus/kioskmode.

  • Page 5: Batch Configuration

    Batch configuration Batch configuration What is Kiosk mode? Kiosk mode lets your business fine tune the VIVE Focus headset to cater to your business needs. With Kiosk mode, lock down the apps customers can experience when using the headset. You need to register the headset serial number first to be able to use Kiosk mode on your headset.

  • Page 6: Enabling And Disabling Features

    Batch configuration Enter the names for the app and app package. <set name="plenty"> <item name="app name">xxxx</item> <item name="app_package_name">xxxx</item> </set> § To find the package name, enter #adb dumpsys app | grep package. § Duplicate <set/> to add more app entries. Save the file.
  • Page 7 Batch configuration Available features These are the features that can be configured for the headset. Feature name Setting text USB Debug Enable or disable USB debugging for the headset. <enableUSBdebug>x</enableUSBdebug> Virtual Wall Show or hide the virtual wall for the play area. <enableVirtualWall>x</enableVirtualWall>...
  • Page 8 Batch configuration Feature name Setting text <SetPlayareaSize>2x2</SetPlayareaSize> Feature version requirements on page 14 to check the system version requirement for each feature. Configuring the Wi-Fi settings file Edit the Wi-Fi configuration file so you can connect VIVE Focus to a specific Wi-Fi network. In the folder where you extracted the contents of the batch configuration template package, open the xml folder.

  • Page 9: Choosing The Apps To Show On The Headset

    Batch configuration Open the desc.txt file using a text editor app. The desc.txt file defines how the images inside the part0 folder are displayed. Update the code according to your preferences. 2880 1600 part0 § 2880 The width, in pixels, of the images used in the animation. §...

  • Page 10: Packaging The Files For Installation

    Batch configuration Packaging the files for installation Once you're done setting up the batch configuration template and other files, package the files in order to run your custom batch configuration on the headset. Make sure the cota_config.xml, mns.xml, cc_config.xml, and wifi_config.xml files are inside the xml folder.
  • Page 11 Batch configuration Open the headset's storage card slot door. Insert the microSD card into the slot. Close the storage card door. Turn on the headset. Follow the instructions in the headset to install the batch configuration file. Wait a few minutes for the installation to finish.
  • Page 12 Batch configuration Under Personal, select Reset. Select Factory data reset Reset Headset Erase Everything. A factory reset may not permanently erase all data from the headset, including personal information.

  • Page 13: Appendix

    Appendix Appendix Country codes Here is a list of countries and their country codes to use for the Wi-Fi setting in the mns.xml file. Region Country Country code North America Canada United States of America Europe Austria Belgium Czech Republic Denmark Finland France...

  • Page 14: Feature Version Requirements

    Appendix Region Country Country code Taiwan Feature version requirements On your headset, check the system version by selecting Settings More Settings About device Build number. ™ Feature name VIVE Focus VIVE Focus Plus USB Debug 1.69.623.6 or later 1.10.623.1 or later Virtual Wall 1.69.623.6 or later 1.10.623.1 or later...

  • Page 15: Trademarks And Copyrights

    © 2020 HTC Corporation. All Rights Reserved. VIVE, the VIVE logo, VIVE Focus, the VIVE Focus logo, HTC, the HTC logo, VIVEPORT, and all other HTC product and service names are trademarks and/or registered trademarks of HTC Corporation and its affiliates in the U.S. and other countries.
