- Page 1 VIVE Wireless Adapter for VIVE Cosmos...
- Page 2 Contents Contents VIVE Wireless Adapter for VIVE Cosmos Unboxing Setup Power bank VIVE Console app Multiuser environment Solutions and FAQs Information and support Trademarks and copyrights...
- Page 3 About this guide About this guide We use the following symbols to indicate useful and important information: This is a note. It provides detailed information for setup, common questions, and what to do in specific situations. This is a tip. It will give you an alternative way to do a particular step or procedure that you may find helpful.
- Page 4 ™ To provide complete wireless adapter accessories for users who may be using both VIVE VIVE Cosmos headsets, HTC is supplying two packages: VIVE Wireless Adapter for VIVE and VIVE Cosmos Wireless Adapter Attachment Kit. VIVE Wireless Adapter for VIVE package In-box items 1.
- Page 5 VIVE Wireless Adapter for VIVE Cosmos VIVE Cosmos Wireless Adapter Attachment Kit To use VIVE Wireless Adapter with VIVE Cosmos, make sure you replace the items in the VIVE Wireless Adapter for VIVE package with the following items from the attachment kit for VIVE...
- Page 6 VIVE Wireless Adapter for VIVE Cosmos About VIVE Wireless Adapter Freeing you from cables, the wireless adapter attaches to your VIVE Cosmos headset and wirelessly receives VR data from your computer. 1. LED 2. Pair button 3. USB power port 4.
- Page 7 Setup Setting up VIVE Wireless Adapter Here's what you need to do to set up VIVE Wireless Adapter for your headset. Install the PCIe card in your computer. Connect the wireless link box to the card. See Installing the PCIe WiGig card...
- Page 8 VIVE Wireless Adapter for VIVE Cosmos Clip the power bank to somewhere on your body such as your belt. Avoid direct skin contact with the power bank as it may get hot during use. From your computer, open the VIVE Console app.
- Page 9 VIVE Wireless Adapter for VIVE Cosmos Installing the PCIe WiGig card Expansion cards such as PCIe cards contain sensitive circuitry and components. Please ® handle your PCIe WiGig card with care. To avoid possible damage from static electricity, follow these precautions when handling the card: §...
- Page 10 VIVE Wireless Adapter for VIVE Cosmos Use the provided clip to mount the wireless link box in place. § A typical setup is to mount it on top of your computer monitor. Flip open the base of the clip and attach it upright on top of the computer monitor.
- Page 11 VIVE Wireless Adapter for VIVE Cosmos Try moving the clipped wireless link box. You can also try placing the wireless link box higher than your height. Turn your computer back on. Replacing the headset cable Replace the original VIVE Cosmos headset cable with the short headset cable from the VIVE Cosmos Wireless Adapter Attachment Kit.
- Page 12 VIVE Wireless Adapter for VIVE Cosmos Remove the face cushion frame from the headset. See Detaching the face cushion frame on page 12. Unplug the original headset cable. Then connect the short headset cable to the headset cable port. Reattach the face cushion frame. See Reattaching the face cushion frame on page 13.
- Page 13 VIVE Wireless Adapter for VIVE Cosmos Avoid pulling or squeezing on the sides of the face cushion frame to prevent damaging the frame. Reattaching the face cushion frame Align and push the tabs on the frame into their corresponding slots on the headset.
- Page 14 VIVE Wireless Adapter for VIVE Cosmos Attaching the left on-ear headphone Attach the left headphone to the left side of the headset band. Pin the short headset cable along the cable guide on the left headphone. Hook the headphone clip back to the left side of the headset band.
- Page 15 VIVE Wireless Adapter for VIVE Cosmos Close the clasp around the headset band and snap into place. Attaching the thin velcro pad Attach the thin velcro pad from the VIVE Cosmos Wireless Adapter Attachment Kit to the headset strap. At the rear end of the headset strap, insert the hooks on the buckle into the holes on the thin velcro pad.
- Page 16 VIVE Wireless Adapter for VIVE Cosmos Hold the headset strap against the headset band so that it stays in place. Then with your other hand, gently pull up on the headset strap to lock it into place. To reattach the back pad, align the tabs (the printed arrow marker should point up) with the corresponding slots on the headset band.
- Page 17 VIVE Wireless Adapter for VIVE Cosmos Attach the cradle for VIVE Cosmos to the base of the wireless adapter. When attached, screw in tightly. Attaching the wireless adapter to VIVE Cosmos Undo the velcro strap at the bottom of the wireless adapter. You'll see a clip on the bottom.
- Page 18 VIVE Wireless Adapter for VIVE Cosmos Align the head pad with the thin velcro pad, and then press to adhere. The headset strap should be sandwiched between them. Wrap the velcro strap on the wireless adapter around the head pad and press to adhere.
- Page 19 Cosmos, use only the 21-watt QC 3.0 power bank (model 148DUT) from the attachment kit. Avoid using third-party power banks. § Use the original power bank holder and power cable from the VIVE Wireless Adapter for VIVE package. With the POWER button facing up, insert the power bank into the holder.
- Page 20 VIVE Wireless Adapter for VIVE Cosmos Push the tab on the holder inward to lock the power bank in place so it won't fall out of the holder. Connect one end of the power cable into the USB power port on the wireless adapter.
- Page 21 Fully charge the power bank before you use it for the first time. Connect the power bank charging cable to the USB Type-C port on the power bank. Connect the other end of the USB cable to an HTC power adapter. The HTC power adapter is not included with VIVE Wireless Adapter.
- Page 22 Pairing VIVE Wireless Adapter with your computer After installing the VIVE Console app on your computer, use it to pair VIVE Wireless Adapter with your computer. This allows the VIVE Cosmos headset to wirelessly connect with your computer. From your computer, open the VIVE Console app.
- Page 23 Below are the requirements for setting up a multiuser environment. § Each user needs to have the following: § A computer running the VR content § A VIVE Cosmos headset with VIVE Wireless Adapter connected wirelessly to the computer § Their own play area §...
- Page 24 How do I set the audio output for VIVE Cosmos when I'm using it with VIVE Wireless Adapter? When using VIVE Cosmos with VIVE Wireless Adapter, you can only choose VIVE Cosmos Multimedia Audio as the playback device, since it's been tested to provide better wireless audio performance.
- Page 25 Sometimes the wireless signal seems weak or the headset display gets disrupted. What should I do? For the best experience while using VIVE Wireless Adapter with your headset, try the following: ® § Use an enclosed space as the WiGig signal will bounce off walls rather than penetrate through them.
- Page 26 I sometimes have connectivity, audio or display issues while using the VIVE Wireless Adapter with VIVE Cosmos. What should I do? If you experience connectivity, audio or display issues while using the VIVE Wireless Adapter with VIVE Cosmos, you need to disable USB power management.
- Page 27 VIVE Wireless Adapter for VIVE Cosmos On the menu bar, click View Devices by connection. Right-click Generic USB Hub Properties.
- Page 28 VIVE Wireless Adapter for VIVE Cosmos Right-click the last Generic USB Hub in the list. On the Power Management tab, clear the Allow the computer to turn off this device to save power option. Click OK. Information and support For information, support, and assistance §...
- Page 29 © 2019 HTC Corporation. All Rights Reserved. VIVE, the VIVE logo, HTC, the HTC logo, and all other HTC product and service names are trademarks and/or registered trademarks of HTC Corporation and its affiliates in the U.S. and other countries.
