Front Panel Components
FIGURE 1
1. Menu button—Opens the Display Menu.
2. Brightness/Previous button—Can be used to adjust Brightness, or to move to the
previous selection in the Display Menu.
3. Contrast/Next button—Can be used to adjust Contrast, or to move to the next
selection in the Display Menu.
4. Access Function button—Accesses functions and submenus in the Display Menu.
5. Power LED—Illuminates when the appliance is powered on.
6. Smart card LED—Illuminates when a smart card is inserted.
7. Smart card reader—Accepts a valid smart card.
8. Headphone output—Designed to work with low impedance stereo headphones.
9. Microphone input—Adjust microphone volume through software
(see page en-10).
en-2 Sun Ray 100 Enterprise Appliance User's Guide • June 2000
1 2 3 4
5
6
7
Front Panel of the Sun Ray 100 Enterprise Appliance
9
8
