Page 8: About This Manual
VM3200 / VM3250 User Manual About this Manual This user manual is provided to help you get the most from your VM3200 / VM3250, I/O boards, and compatible receivers, which includes the following the following product models: Device Type Model...
Page 9 The VM3200 / VM3250 product firmware may have been updated with new features after the release of this manual. For an up-to-date VM3200 / VM3250 user manual, visit http://www.aten.com/global/en/...
Page 10: Conventions
For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International...
Page 11: User Information
VM3200 / VM3250 User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America...
Page 12: Package Contents
VM3200 / VM3250 User Manual Package Contents Check to make sure that all of the components are present and in good order. If anything is missing or was damaged in shipping, contact your dealer. VM3200 The VM3200 package consists of:...
Page 13: Vm7514 / Vm8514
VM3200 / VM3250 User Manual The K2 package (10 km) consists of: 1 VM7584 4-Port 10G Optical Input Board or VM8584 4-Port 10G Optical Output Board 4 SFP+ modules 4 3-pole Terminal Blocks 1 IR Receiver 1 IR Emitter 1 User Instructions...
Page 14: Vm7814 / Vm8814
VM3200 / VM3250 User Manual VM7814 / VM8814 The 4-Port 4K HDMI Input / Output Board package consists of: 1 VM7814 4-Port 4K HDMI Input Board / 1VM8814 4-Port 4K HDMI Output Board 4 Terminal Blocks LockPro 4 HDMI 1 User Instructions...
Page 15: Vm7404
VM3200 / VM3250 User Manual VM7404 The 4-Port 3G-SDI Input Board package consists of: 1 VM7404 4-Port 3G-SDI Input Board 4 Terminal Blocks 1 User Instructions VE805R The HDMI HDBaseT Lite Receiver with Scaler package consists of: 1 VE805R HDMI HDBaseT Lite Receiver with Scaler...
Page 16 VM3200 / VM3250 User Manual This Page Intentionally Left Blank...
Page 17: Introduction
The VM7584 and VM8584 (4-Port 10G Optical Input / Output Board) offer an easy way for the VM3200 / VM3250 to route 4 HDMI sources over long distances via optical extenders, the VE883 to 4 HDMI-enabled displays. These...
Page 18 The VM7814 / VM8814 is a 4-Port 4K HDMI input/output board that works with VM3200 / VM3250 to route 4 HDMI sources to 4 displays. The VM7814 / VM8814 is equipped with 4 input/output ports to allow for stereo audio ™...
Page 19 HDBaseT transmitter or splitter to extend your HDMI display up to 100 m from the source using a single Cat 6a cable or ATEN 2L-2910 Cat 6 cable. With a built-in scaler, the VE805R / VE816R supports the scaling of different video resolutions.
Page 20 RS-232 and RS-485/RS-422 ports allows the switch to be configured through a high-end controller or PC. The ATEN Modular Matrix Solution Series is a powerful integrated AV setup targeted towards broadcasting stations, traffic and transportation-related control rooms, emergency service centers and any application that requires...
Page 21: Features
Multiple control methods – including front-panel pushbuttons, RS-232/ 422/485 control, and Ethernet connections for web GUI or Telnet 4K resolutions – the VM3200 supports up to UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0)* True 4K resolutions –...
Page 22 VM3200 / VM3250 User Manual Consumer Electronics Control (CEC) supported* Rack mountable (9U design) ESD protection for HDMI Note: Features marked with an asterisk (*) are supported only with specific I/O boards. For more information, see the feature descriptions for I/O boards in this manual.
Page 23: Vm7584 / Vm8584
Chapter 1. Introduction VM7584 / VM8584 Compatible with the VM3200 / VM3250; mix and match with modular output boards of any type for optimum flexibility Extends audio, video, IR, and RS-232 control signals over long distances via duplex fiber optic cables...
Page 24: Vm7514 / Vm8514
VM3200 / VM3250 User Manual VM7514 / VM8514 Compatible with the VM3200 / VM3250; mix and match with modular I/ O boards of any type for optimum flexibility Superior video quality up to 4K when used with VE816R Long-distance transmission up to 100 m...
Page 25: Vm7904
Chapter 1. Introduction VM7904 Compatible with the VM3200 / VM3250; mix and match with modular I/ O boards of any type for optimum flexibility Connects up to 4 DisplayPort inputs to up to 32 displays Superior video quality – up to 4096 x 2160 / 3840 x 2160 @ 30 Hz (4:4:4)
Page 26: Vm7824 / Vm8824
VM3200 / VM3250 User Manual VM7824 / VM8824 Compatible with the VM3200 / VM3250; mix and match with modular I/O boards of any type for optimum flexibility Superior video quality: For VM3200: HDTV resolutions of 480p, 720p, 1080i, and 1080p (1920 x 1080);...
Page 27: Vm7814 / Vm8814
Chapter 1. Introduction VM7814 / VM8814 Compatible with the VM3200 / VM3250; mix and match with modular I/O boards of any type for optimum flexibility Superior video quality – HDTV resolutions of 480p, 720p, 1080i, and 1080p (1920 x 1080); 4K2K @ 60Hz (4:2:0)
Page 28: Vm7804 / Vm8804
VM3200 / VM3250 User Manual VM7804 / VM8804 Compatible with the VM3200 / VM3250; mix and match with modular I/ O boards of any type for optimum flexibility Superior video quality – HDTV resolutions of 480p, 720p, 1080i (1920 x...
Page 29: Vm7604 / Vm8604
Chapter 1. Introduction VM7604 / VM8604 Compatible with the VM3200 / VM3250; mix and match with modular I/ O boards of any type for optimum flexibility 4 DVI-D input ports (VM7604); 4 DVI-D output ports (VM8604) Scaler – features a video scaling function to convert input resolutions to the optimum display resolutions* (VM8604 only) Seamless Switch™...
Page 30: Vm7104
VM3200 / VM3250 User Manual VM7104 Compatible with the VM3200 / VM3250; mix and match with modular I/ O boards of any type for optimum flexibility Connects up to 4 VGA or Component inputs Supports RGBHV / RGBS / YPbPr / YCbCr input signals...
Page 31: Ve805R
Note: The Seamless Switch™ and the video wall functions are only available when the VE805R is used with the ATEN HDBaseT I/O boards. When Seamless Switch™ or Video Wall is enabled, videos may not display within range, in which case make sure to adjust the display settings on your device.
Page 32: Ve816R
Note: The Seamless Switch™ and the video wall functions are only available when the VE816R is used with ATEN HDBaseT I/O boards. When Seamless Switch™ or Video Wall is enabled, videos may not display within range, in which case make sure to adjust the display settings on your device.
Page 33: Requirements
Chapter 1. Introduction Requirements The following are required for a complete VM3200 / VM3250 Modular Matrix Solution Series installation: Input / Output Board VM7584 (4-Port 10G Optic Input Board) and VM8584 (4-Port 10G Optic Output Board) VM7514 (HDBaseT input board) and VM8514 (HDBaseT output board)
Page 34: Display Devices
VM3200 / VM3250 User Manual For VM7104 4-Port VGA input board: AV source device with VGA output connector(s) For VM7404 4-Port 3G-SDI Input Board: SDI sources, including 3G-SDI, HD-SDI and SD-SDI Display Devices For VM8584 4-Port 10G Optic Input Board + VE883R HDMI Optical...
Page 35: Compatible Browsers
V1.8.0_181 (64 bit) 10.2.1 MAC 10.10 V1.8.0_25 Safari Optional Equipment Purchase optional equipment such as a secondary power module, fan, or rack mount kit to get the most out of your ATEN Modular Matrix. For more information, go to https://www.aten.com/global/en/...
Page 36: Components
VM3200 / VM3250 Front View Component Description LCD Display The LCD Display shows the options for configuring and operating the VM3200 / VM3250. See Front Panel Pushbuttons, page 43, for details. Function Use the UP, DOWN and CANCEL buttons to navigate the LCD Pushbuttons display to configure the installation.
Page 37 Chapter 1. Introduction Component Description Input These pushbuttons refer to the Input ports on the VM3200 / Pushbuttons VM3250 rear panel. Press to select the Input port. These (1-32) pushbuttons may also correspond to menu options, profiles and other selections.
Page 38: Vm3200 / Vm3250 Rear View
In order to access the VM3200 / VM3250’s web Graphical User Interface (GUI), the VM3200 / VM3250 must be connected to the network. The cable that connects the VM3200 / VM3250 to your LAN plugs in here. See Installation, page 37, for further details RS-232 Serial Port Connect a computer or high-end system controller via this serial port.
Page 39 Note: The extra power module is not included in the VM3200 / VM3250 package.See , page 18, for details. Grounding Terminal The grounding wire attaches here. See Installation, page 37, for further details.
Page 40: Vm7584 Front View
VM3200 / VM3250 User Manual VM7584 Front View Component Description Link LEDs Light up to indicate stable connection with the connected source devices. SFP+ Ports Connect up to four VE883T units via SFP+ modules to receive data from input devices.
Page 41: Vm8584 Front View
Chapter 1. Introduction VM8584 Front View Component Description Link LEDs Light up to indicate stable connection with the connected source devices. SFP+ Ports Connect up to four VE883R units via SFP+ modules to transmit data to output devices. IR Ports Connect to the supplied IR Receiver or IR Emitter to bypass IR signals via the VM8584.
Page 42: Vm7514 Front View
VM3200 / VM3250 User Manual VM7514 Front View Component Description HDBaseT Input Ports Connect the Cat 5e cables from your HDBaseT transmitter to these ports. IR / RS-232 Connect the cables from your IR transmitter to the mini stereo jack ports, and connect the cables from your Input Ports RS-232 device to the RS-232 ports.
Page 43: Vm7904 Front View
Link LEDs Lights up to indicate stable connection with the connected source devices. ATEN LockPro™ Optionally secure an ATEN LockPro™ to hold a the Screws HDMI cable in place and prevent it from falling off. Status LED Indicates the working status of the unit.
Page 44: Vm8824 Front View
Link LEDs Lights up to indicate stable connection with the connected display devices. ATEN LockPro™ Optionally secure an ATEN LockPro™ to hold a the Screws HDMI cable in place and prevent it from falling off. Status LED Indicates the working status of the unit.
Page 45: Vm8814/Vm8804 Front View
Chapter 1. Introduction VM8814/VM8804 Front View Component Description HDMI Output Ports Connect the cables from your HDMI display devices (monitors, projectors, TVs) to these ports. Audio Output Ports Connect the cables from your output audio devices or speakers to these ports. Status LED Indicates the working status of the unit.
Page 46: Vm8604 Front View
VM3200 / VM3250 User Manual VM8604 Front View Component Description DVI Output Ports Connect the cables from display devices (monitors, projectors, TVs) to these ports. Audio Output Ports Connect the cables from your output audio devices or speakers to these ports.
Page 47: Vm7404 Front View
Chapter 1. Introduction VM7404 Front View Component Description SDI Input Ports Connect the cables from your video source devices to these ports. Analog Stereo Audio Connect the cables from your audio source devices to these ports. Input Ports Status LED The VM7404 has an LED to indicate the working status.
Page 48: Ve805R / Ve816R Front View
VM3200 / VM3250 User Manual VE805R / VE816R Front View VE805R / VE816R Rear View Component Description LEDs Three LEDs – Power, Link and HDMI Out – light when the unit is properly connected to an appropriate source. Power - lights Green to indicate the unit is receiving power.
Page 49: Hardware Setup
VM3200 / VM3250 due to improper handling. When not rack mounted, the VM3200 / VM3250 should be placed on a flat and level surface with the bottom side down. The unit should never be placed with the front, rear or sides facing the ground.
Page 50: Rack Mounting
2. Use screws to attach the unit to the rack. Note: Please allow 1U (44 mm) of space between the top of the VM3200 / VM3250 and any object to prevent obstruct of the air flow. To ensure the VM3200 / VM3250 has sufficient air flow, do not stack items on top or in front of the unit.
Page 51 Chapter 2. Hardware Setup Mounting with Brackets You can also use mounting brackets to install the VM3200 / VM3250, as shown below. Note: The Easy Installation Mounting Kit is not included with the package (see page 19). To purchase a mounting kit please contact your dealer.
Page 52 3. Screw the front panel to the rack. Note: Please allow 1U (44 mm) of space between the top of the VM3200 / VM3250 and any object to prevent obstruct of the air flow. To ensure the VM3200 / VM3250 has sufficient air flow, do not stack items on top or in front of the unit.
Page 53: Installation
Chapter 2. Hardware Setup Installation Follow the steps below to safely install devices to the VM3200 / VM3250. 1. Use a grounding wire to ground the unit by connecting one end of the wire to the grounding terminal, and the other end of the wire to a suitable grounded object.
Page 54 Serial port. Use the supplied terminal block for this connection. 7. (Optional) To remotely operate the VM3200 / VM3250 via the web interface, plug an Ethernet cable into the Ethernet port on the VM3200 / VM3250. Note: For VM3200, you can also use the Video Matrix Control app to remotely operate the unit.
Page 55: Installing The Input / Output Boards
To access these settings, use the front-panel pushbuttons (page 56) or the web interface (page 112). 1. On the rear of the VM3200 / VM3250, remove two screws from a left and right side slot, and then remove both covers.
Page 56 VM3200 / VM3250 User Manual 2. Slide an output board into a left side slot and then tighten the two screws to secure the board to the VM3200 / VM3250. Note: The eight slots toward the right are for input boards, and the other...
Page 57 Chapter 2. Hardware Setup 3. Slide an input board into a right side slot and then tighten the screws to secure the board to the VM3200 / VM3250. 4. Repeat steps 2 and 3 to install additional I/O boards.
Page 58 VM3200 / VM3250 User Manual This Page Intentionally Left Blank...
Page 59: Front Panel Operation
The VM3200 / VM3250 front panel has easy-to-use pushbuttons for selecting which video/audio source shows on which display. Basic Navigation The VM3200 / VM3250’s front panel LCD display operation is easy and convenient. Please note the following front panel button operations: Press the VIDEO pushbutton to configure the video connections.
Page 60: Front Panel Lcd
LCD Password If the VM3200 / VM3250 has been configured to require a password for local operation (see Security Mode, page 61), the password screen appears when the VM3200 / VM3250 is powered on, and the cursor flashes on the first digit.
Page 61 3. Press Cancel to clear the password. The digits revert to 4 asterisks (*) and the cursor returns to the first digit. Note: 1. The VM3200 / VM3250 password can be any four digit combination between 1111 to 9999. 2. If you enter an incorrect password, the cursor goes back to the first digit and reverts to flashing.
Page 62: Port Switching
VM3200 / VM3250 User Manual Port Switching From the Main Screen, you can configure the Input-to-Output port connections to associate an Input source device to an Output display. Video / Audio Pushbutton Before switching port connections, use the Video or Audio pushbuttons to select whether to switch only the video or the audio signal exclusively.
Page 63: Port Selection
Chapter 3. Front Panel Operation Port Selection Input Port Selection Use the Input Port pushbuttons to select the Input port you want to configure. INPUT V + A OUTPUT INPUT ↓ :Next OUTPUT 9 10 11 12 13 14 15 16 To select which input source displays on each output port, do the following: 1.
Page 64 VM3200 / VM3250 User Manual 3. To switch to another Input port, press any Input port pushbutton. The Output port LED(s) tied to the said Input port light up. In the example below, pressing Input port 2 shows it is tied to Output ports 3 and 4.
Page 65 Chapter 3. Front Panel Operation Output Port Selection Use the Output Port pushbuttons to select the Output port you want to configure. INPUT V + A OUTPUT INPUT ↓ :Next OUTPUT 9 10 11 12 13 14 15 16 To select which output display corresponds to each input source, do the following: 1.
Page 66 VM3200 / VM3250 User Manual 4. To switch Output ports 2, 3 and 4 to another Input port (and disconnect it from Input port 2), press another Input port pushbutton to which you want them tied. In the example below, Input port 3 has been pressed and is now connected to Output ports 2, 3 and 4.
Page 67: Profile Pushbutton
Note: If a Profile is available for selection, its corresponding Input/Output port LED lights. The selected pushbutton lights steady, and the VM3200 / VM3250 immediately applies the port connections configured in the Profile. The selected Profile is shown as P1-P64 in the LCD’s lower right corner.
Page 68: Lcd Menu
01-32 Play/Stop the Profile Schedule Turn Video Wall Off Note: 1. The highlighted values are the default settings of the VM3200 / VM3250. 2. Upon VM3200 / VM3250 startup, check the front panel LCD to view the loading progress. If the LCD Menu fails to load, an error message...
Page 69: Lcd Main Screen
Chapter 3. Front Panel Operation LCD Main Screen The Main Screen shows the Input–Output port pairs, with the Output ports shown in sequential order (1–16) at the bottom half. V + A INPUT OUTPUT INPUT ↓: Next OUTPUT 9 10 11 12 13 14 15 16 The front panel pushbutton label (1–32) corresponds to the Input ports and Output ports on the unit’s rear panel.
Page 70: Ip Setting
VM3200 / VM3250 User Manual IP Setting To view the VM3200 / VM3250’s IP settings, press the Menu pushbutton (lights). This takes you to the Menu page, shown below: 1: IP Se ng 2: Serial Port Se ng 3: Opera on Mode ↓: Next...
Page 71: Serial Port Setting
Chapter 3. Front Panel Operation Serial Port Setting To configure the VM3200 / VM3250’s serial port settings, select Serial Port Setting from the Menu page. 1: IP Se ng 2: Serial Port Se ng 3: Opera on Mode ↓: Next...
Page 72: Operation Mode
VM3200 / VM3250 User Manual Operation Mode The EDID, CEC, OSD, and Output Status features are adjusted from the Operation Mode menu. 1: EDID Mode: Default 2: CEC 3: OSD ↓: Next 4: Output Status EDID (extended display identification data) is used to apply a preset video configuration (EDID Mode), which utilizes the best resolution across different monitors.
Page 73: Cec
EDID Mode options are: EDID Option Description 1: Default ATEN’s default EDID data is passed to all video sources by default when the system is powered on. 2: Port1 EDID data read from port 1 is passed to all video sources. The system will enforce the Default EDID setting if port 1 is not occupied.
Page 74: Osd
The On-Screen Display or OSD feature enables real-time text updates to appear on the display device’s screen for any configuration changes made to the Output port via the VM3200 / VM3250’s front panel, remote control or Web GUI. To configure the OSD setting for each output port, do the following: 1.
Page 75: Output Status
Chapter 3. Front Panel Operation 4. Press Cancel to return to the previous step without saving. Output Status To configure the Output Status settings for each output port, do the following: 1. From the Operation Mode screen, press pushbutton 4 to access the Output Status page: 1: EDID Mode: Default 2: CEC...
Page 76 VM3200 / VM3250 User Manual 4. If configuring the output port status for stereo audio, press pushbuttons 1– 32 to select the output port. Adjust the audio volume for the port by pressing the Up or Down pushbutton: Note: The audio volume range from 0 (mute) and 1 (~27dB) to 10 (0dB).
Page 77: Security Mode
4 to access the Security Mode page. 1: Mode 2: Change Password Mode 1. To set the VM3200 / VM3250 so that it requires a password for local operation, press pushbutton 1 in the Security Mode page. 1: Mode 2: Change Password 2.
Page 78: Change Password
VM3200 / VM3250 User Manual 4. To enable a lock screen, press pushbutton 3. When Lock Screen is enabled, pressing any pushbutton from the home screen will trigger the following message: Please press “Menu” to start. 1: None 2: Password Enable 3: Lock Screen Note: By default the password requirement is disabled.
Page 79 Old Password : * * * * New Password: * * * * 4. Re-enter the new password in the following screen. The new password is applied by the VM3200 / VM3250 immediately. Old Password : * * * *...
Page 80: Saving Configurations To Profile
VM3200 / VM3250 User Manual Saving Configurations to Profile The VM3200 / VM3250 allows you to store up to 64 (P1–P64) different connection profiles that can be saved and recalled later. When profiles are saved, they are saved according to the current connection configuration on the Main Screen.
Page 81: Playing/Stopping The Profile Schedule
Chapter 3. Front Panel Operation Playing/Stopping the Profile Schedule Inputting port pushbutton 2 will Play or Stop the active Profile Schedule. :Prev 1: Save to a profile 2: Play/stop the profile schedule 3: Turn video wall off Turning Video Wall Off If a video wall is currently playing, a submenu will appear.
Page 82 VM3200 / VM3250 User Manual This Page Intentionally Left Blank...
Page 83: Browser Operation
Logging In To access the GUI, type the VM3200 / VM3250’s IP address into the address bar of any browser. If a Security Alert dialog box appears, accept the certificate – it can be trusted. The login screen appears: The default IP address is http://192.168.0.60...
Page 84: Main Page
VM3200 / VM3250 User Manual Main Page The Main Page opens to the Profile List. This is where you configure the input to output connections by creating profiles. The page is divided into three parts: the Menu Bar, Profile List, and Profile Scheduling.
Page 85: Menu Bar
For details, see Profile List, page 70. Standby Click to set the VM3200 / VM3250 to standby mode. For details, see Profile List, page 70. Logout Click to log out of the VM3200 / VM3250 web GUI.
Page 86: Profile List
VM3200 / VM3250 User Manual Profile List The Profile List lets you configure the input to output port connections by creating profiles to use. You can store up to 64 differently configured profiles that can be saved and played later by two methods: locally via the unit’s front...
Page 87: Creating A Profile
Chapter 4. Browser Operation Creating a Profile 1. From the Profile List, click an empty profile icon. This window appears. 2. Select New to create a new profile or Copy to use configuration from a pre-existing profile. This screen appears. In this example, the profile is set to a quad view (2 x 2 divisions) using 16 displays.
Page 88 VM3200 / VM3250 User Manual 5. Click Save. This profile is added to the Profile List.
Page 89: Editing A Profile
Chapter 4. Browser Operation Editing a Profile 1. Click a profile from the Profile List, and then click Edit. This screen appears. 2. You can choose either the Normal View or the Grid View to edit the profile. Normal View In a normal view, the profile is configured via a preview and a separate audio settings page that opens by clicking the audio icon at the...
Page 90 VM3200 / VM3250 User Manual For detailed information, see Editing a Profile in Normal View, page 75. Grid View In grid view, the audio and video outputs are assigned by mapping the audio/video input on the vertical axis to the audio/video output on a horizontal axis.
Page 91: Editing A Profile In Normal View
Chapter 4. Browser Operation Editing a Profile in Normal View Profile Layout Settings Control Description Number of Use the following controls to configure the layout type and the number Displays of displays. Video Wall: Select this option for displays that are tiled together, where multiple monitors form one large screen –...
Page 92: Display Preferences
VM3200 / VM3250 User Manual Display Preferences To configure the display preferences for one or more displays, click the display(s) in the preview, the Display Preference settings page appears. Configure the settings as required. Option Description Output This indicates the selected displays.
Page 93: Video Wall Settings
Chapter 4. Browser Operation Video Wall Settings Each icon represents an Output port and the connected display. Use the icons to create Independent and Grouped Outputs. Independent Outputs will display video on a single monitor. Grouped Outputs will display video across multiple monitors as one large screen.
Page 94 VM3200 / VM3250 User Manual Null Input Option Description Null Icon Click Null Input icons to highlight icons in green and use the Display see Display Preferences menu to set the video options ( Preferences , page 76). Select a single icon to set the Output and Video Input for an independent display (see Independent Output, page 78).
Page 95 Chapter 4. Browser Operation Grouping Option Description Grouping Click multiple icons to Group Outputs (highlighted in green) and →|← click to group the displays into one screen. Use the Display Preferences menu to select the Video Input for the group - each Output icon in the Group will appear with the same Video Input see page 76 number and icon color (...
Page 96 VM3200 / VM3250 User Manual Option Description Mute / Video Click the speaker icon to mute the audio on/off. Click the video icon to turn the video off/on. Video Wall Example 1 This example shows a video wall with 8 displays.
Page 97 Chapter 4. Browser Operation Video Wall Example 2 This example shows a video wall with 16 displays. This video wall has 3 Groups and 2 Independent displays. Each Group and Independent Output has a unique color. The Blue Group will show video Input 02 across six displays as one large screen.
Page 98 VM3200 / VM3250 User Manual Audio Output Settings Use this page to configure digital and analog audio output settings. To access these settings, click from the top-right corner in the profile settings page. Digital Audio Output: Use this column to assign audio inputs to the digital audio outputs.
Page 99 Chapter 4. Browser Operation Analog Audio Output: Use this column to assign audio inputs to the analog audio output ports. Port: Use this field to apply the same audio setting to all analog audio output ports. All ports follow video path: Sets all analog audio outputs to receive the digital audio inputs that come with their video inputs as these videos display.
Page 100: Editing A Profile In Grid View
VM3200 / VM3250 User Manual Editing a Profile in Grid View In a grid view, the audio and video outputs are assigned by mapping the audio/ video input on the vertical axis to the audio/video output on a horizontal axis.
Page 101 Chapter 4. Browser Operation Example 2 To assign the same input for all outputs, click the input from the vertical axis. In the following illustration, all output ports are assigned with input Example 3 To have an audio output automatically switch to the audio input that comes along with the assigned video input, click AFV (audio following video).
Page 102: Playing A Profile
VM3200 / VM3250 User Manual Playing a Profile 1. Click the profile you wish to apply and then click Apply. 2. The profile is immediately applied and appears in the large Play window.
Page 103 Chapter 4. Browser Operation 3. To adjust the played profile, click on the Play window. The following controls appear. Option Description Show OSD Check Show OSD to show the current connection status via OSD. When Show OSD is unchecked, the OSD will disappear. Mute All Check Mute All to mute the audio for all ports.
Page 104: Change Input
VM3200 / VM3250 User Manual Change Input The Change Input page gives you a preview of what’s displayed on all screens, allows you to change the inputs and view a live stream of each input. To access this page, click Change Input from the Play Window (see Change Input, page 88).
Page 105: Live Streaming View
Chapter 4. Browser Operation Live Streaming View This window gives you a live stream of the video source. To access this page, click an input from the right column on the Change Input page (see Change Input, page 88). Option Description Click the icon to increase / decrease the size of the live preview window.
Page 106: Exporting A Profile
A configuration file starts downloading. Importing a Profile To import connection profiles to the VM3200 / VM3250, do the following: 1. From the main screen, click Import Profiles. 2. Browse to the configuration file, select it and click Open.
Page 107: Streaming Out Videos Live
Chapter 4. Browser Operation Streaming Out Videos Live You can stream out video sources live via the VM3250 to a video livestreaming platform of your choice, such as YouTube or Twitch. Note: This is a VM3250-only feature. The VM3250 currently streams videos only. For a source that contains both video and audio, only the video will be streamed.
Page 108 VM3200 / VM3250 User Manual a) Click Profile List to switch to the Profile List page. b) From the green toolbar, click Start Streaming. This dialog box appears. Note: To see previews of video sources, open the Change Input page. For details, see Live Streaming View, page 89.
Page 109 Chapter 4. Browser Operation 3. Click OK to confirm the settings. A live icon appears in main screen to indicate that the selected input is being streamed out.
Page 110: Profile Scheduling
(green) or disable (gray) profile schedules. Note: For VM3200 using firmware prior to version 1.4.138, if profile scheduling is disabled and re-enabled within the scheduled time frame of a playlist, the VM3200 will resume playing the first profile in the playlist For VM3250 or VM3200 using firmware version 1.4.138 or later, if...
Page 111: Adding Profile Playlists
Chapter 4. Browser Operation Adding Profile Playlists Adding a Recurring Playlist To add a playlist that plays periodically, follow the steps below. 1. From the Profile List page, click PROFILE SCHEDULING. A profile calendar appears. 2. Click the Add Playlist button or a day on the calendar to add a playlist. The Add Playlist window appears.
Page 112 VM3200 / VM3250 User Manual 3. Configure the playlist. a) Configure the Name, Start Time, End time, and Frequency. b) Click to open the Select Profiles window. Click one or more profiles to add to the playlist. c) Click OK. The selected profiles are added to the playlist. The profiles...
Page 113 Chapter 4. Browser Operation Adjust the play duration and the order of the added profiles if required. See the table below for more details. Option Description Use the drop-down menu to select Hour(s), Minutes, or Seconds and then enter a duration (1-999) for the profile to play.
Page 114 VM3200 / VM3250 User Manual Adding a One-off Profile Playlist To add a playlist that plays once, follow the steps below. 1. From the Profile List page, click PROFILE SCHEDULING. A profile calendar appears. 2. Use the buttons to adjust the calendar to a time frame to which you wish to add profiles.
Page 115: Editing, Removing, Or Copying Profile Playlists
Chapter 4. Browser Operation Editing, Removing, or Copying Profile Playlists To edit, remove, or copy profile playlists: 1. Click the button from the Profile List page to open the All Playlist window. 2. Move the cursor to a playlist you want to edit, copy, or remove. 3.
Page 116: System Settings
VM3200 / VM3250 User Manual System Settings Overview The setting pages allow you to configure the VM3200 / VM3250’s system settings. If your Web GUI is not showing these setting, click the Settings icon from the top-right corner in the web interface.
Page 117 Select EDID modes. Status For more information, View statuses of the input/output boards see YCBCR 4:2:0 Video installed to the VM3200 / VM3250 and Data Block, page 123. enable/disable FrameSynce and Long Reach mode for the board. View system information such as...
Page 118 VM3200 / VM3250 User Manual Supported Functions Detailed Information Maintenance See Maintenance, Upgrade the firmware for the installed page 129. input and output boards Back up or restore the VM3200 / VM3250’s configuration Add, edit, or remove user accounts Configure the system network settings...
Page 119: General
Chapter 4. Browser Operation General Basics Device Name: Type to name your Modular Matrix Switch. Language: Click to select a language for the web interface. System Time Click Edit to configure the system date and time settings. Fan Status Fan speed: Click to select a fan speed. Temperature and fan icons: Indicates the internal temperature and status of the cooling fans.
Page 120: Power Status
VM3250’s system via RS-232 serial commands. RS-232 Control Mode: Allows the user to control remote devices that are connected to VM3200 / VM3250 through its RS-232 channels. To enable this feature, select the RS232 Control Mode and configure the input to output settings. For details, see Channel, page 127.
Page 121: Port Settings
Chapter 4. Browser Operation Port Settings OSD/CEC The OSD/CEC page lets users view and set OSD and CEC settings for all ports.
Page 122 VM3200 / VM3250 User Manual OSD: Sets the default OSD option for the port. When OSD is on, real- time text updates appear on the display for 10 seconds when configuration and port changes are made to its output. Use the drop-down menu to apply options to all ports, or ON/OFF button to enable/disable the OSD for each port.
Page 123: Hdcp
Chapter 4. Browser Operation HDCP The HDCP page lets users view and set HDCP key settings between input and output ports for digital copy protection and to ensure Seamless Switch™ is used between different devices. This is an Administrator and Advanced User only function.
Page 124: Scaler
VM3200 / VM3250 User Manual Scaler The Video settings page allows you to set Seamless Switch™ options which determine how a display performs when the Input port is changed. Note: Seamless Switch™ is enabled: When The Transition, Period and Scale Resolution options can be enabled.
Page 125 Chapter 4. Browser Operation Enable Seamless Switch™ to remove the video distortion and delay seen when an input port is switched. Use the drop-down menu to apply options to all ports, or the On/Off button to enable/disable Seamless Switch™ per port. With Seamless Switch™...
Page 126: Port Name
VM3200 / VM3250 User Manual Port Name The Annotation page lets users name the Input and Output ports for easy identification.
Page 127 Chapter 4. Browser Operation To name an Input/Output port, enter a descriptive name of up to 16 characters (including 0-9, a-z, A-Z, _, -) in the corresponding field. To change an Input/Output port’s name, enter another value and click Save. Note: The Input and Output port names can be the same.
Page 128: Edid Settings
The EDID Setting page lets users view and select an EDID Mode so that the VM3200 / VM3250 can use the best resolution for its displays. Note: The EDID Mode can also be selected via the Front Panel pushbuttons –...
Page 129 In the left panel of the page, users can select a pre-configured EDID Mode using the EDID Mode radio buttons. Select the EDID Mode to use and click Apply. The VM3200 / VM3250 uses the settings configured for that EDID mode.
Page 130 VM3200 / VM3250 User Manual EDID & CEA Description The middle panel of the screen lets users view and configure the EDID or the CEA mode. From the middle column, click the option that you want to view and/or edit. There are two categories: EDID (Extended Display Identification Data) and CEA (Consumer Electronics Association).
Page 131: Customized Mode
Chapter 4. Browser Operation Customized Mode Use the Customized mode to automatically retrieve and save the EDID of a connected monitor/display device to an input source port. In the left panel, select Customized from the EDID Mode section and click Apply. Port EDID Status: Select the input source port to which you want to store the EDID configuration.
Page 132: Customized Edid Parameters
VM3200 / VM3250 User Manual Customized EDID Parameters The EDID structure is comprised of 128 bytes in total – each heading shown in the left column corresponds to a specific number of bytes. The pages for the pre-configured EDID Modes (Port 1, Default and Remix) cannot be edited.
Page 133 Chapter 4. Browser Operation Standard Timings This page shows eight resolutions/timings that display devices can support in addition to those listed in the Established Timings page. Select the H Active Pixel from the drop-down menu. Select the Aspect Ratio from the drop-down menu. Click Save to apply the changes.
Page 134 VM3200 / VM3250 User Manual Monitor Description This screen lets you specify the viewing specifications, namely horizontal and vertical scan ranges and pixel clock rate, of your monitor/display device. Enter the values that correspond to your device and click Save to apply the...
Page 135 Chapter 4. Browser Operation CEA Settings CEA is an extension data of the EDID structure, which further extends the standard definitions of EDID to support advanced features of monitors/display devices. Display Support This screen describes the display’s basic digital components. Select the YCbCr mode applicable to your display and click Save.
Page 136 VM3200 / VM3250 User Manual Video Data This screen lists additional video resolution/timing displays that may be supported by other devices, other than PC monitors (for example, 1080i). Select the native resolution of the attached display device. Select the resolutions that work with the attached monitor/display device.
Page 137 Chapter 4. Browser Operation Audio Data This screen lets you select advanced audio configurations for your device. Use the drop down menu to select the Audio Format (1~6) applicable to your audio output device, and click Save to apply the changes.
Page 138 VM3200 / VM3250 User Manual HDMI Forum Vendor Specific Block This screen shows the display device’s supported video parameters. Use the toggle button to enable or disable this function. 3D OSD Disparity: Select this option to have Sink support receiving 3D OSD Disparity Indication in the HF-VSIF.
Page 139: Ycbcr 4:2:0 Video Data Block
Chapter 4. Browser Operation YCBCR 4:2:0 Video Data Block Use this page to configure a list of supported YCBCR 4:2:0 video resolutions and select one to be applied. Use the toggle button at the top-right to enable or disable this feature. To add a supported resolution, click an item in the Select column, and then click Add.
Page 140 VM3200 / VM3250 User Manual YCBCR 4:2:0 Compatibility Map Data Block Use this page to configure a list of supported video resolutions for YCBCR 4:2:0 Compatibility Map Data Block and select one to be applied. Use the toggle button at the top-right to enable or disable this feature.
Page 141: Status
Connections The connections tab provides a status summary of the input/output boards installed to the VM3200 / VM3250 and the devices that are connected to the ports on the input/output boards. If the connected devices support FrameSync and Long Reach mode, you can also enable/disable the function on this page.
Page 142: System Information
VM3200 / VM3250 User Manual System Information Use this page to look up system settings, including system network settings, firmware version, video/audio input assignments, output audio volumes, CED/ OSD settings, output resolutions, HDMI audio mode settings, and power statuses. Hint: Click to view details and to refresh the system.
Page 143: Channel
Chapter 4. Browser Operation Channel IR/RS-232 The IR/RS-232 page is used to configure the IR/RS-232 communication routes between the input and output ports. Note: The IR/RS-232 pages are only supported by VM7514/VM7584 and VM8514/VM8584 boards.
Page 144: Ir/Rs-232
VM3200 / VM3250 User Manual In-Board: Use this set of settings to configure the IR/RS-232 signals for each input port. Port 1 ~ Port 32: Configure each input port to use the Local IR/RS- 232, Tx IR/RS-232, or Loopback for IR/RS-232 signals.
Page 145: Maintenance
You can use the System Setup page to do any of the following: Upgrade the VM3200 / VM3250’s mainboard, its streaming board, and any installed I/O boards Back up or restore the VM3200 / VM3250’s settings. Note that account settings cannot be backed up or restored.
Page 146 PC. 2. Click Restore to begin the restoration procedure. Note: User accounts cannot be backed up or restored. To reset the VM3200 / VM3250 to its default settings, click the reset to default button on the far right.
Page 147: User Account
Note: This is an Administrator only function. Add account – Click the Add account button to add another user to the list. The VM3200 / VM3250 supports up to 32 users and up to 16 concurrent logins (see page 132 for more details).
Page 148: Add Account
Click Create User to save the data. Click Cancel to discard the changes and exit. If a user is logged into the VM3200 / VM3250’s GUI, their user settings cannot be edited, and the fields in this screen are grayed out.
Page 149: Permission Level
The three available permission levels are as follows: Administrator – this level provides full access and control of the VM3200 / VM3250, in addition to full User Management privileges. Advanced User – this level provides full access and control with no User Management privileges.
Page 150 VM3200 / VM3250 User Manual Network The Network page lets you configure the VM3200 / VM3250’s IP settings for connecting to it via the web GUI, and enable/disable Telnet. Enable DHCP to allow the DHCP server to assign an IP address to the VM3200 / VM3250.
Page 151: Mobile Control
Supported Version 12.0 or later Android 8.0 or later The VM3200 needs to be connected to a local area network via the Ethernet port. Installation and Connections To install the Video Matrix Control App on a mobile device, do the following: 1.
Page 152: The Control Interface
The Video Matrix Control App is designed to control one VM3200 device at a time. If you cannot find the VM3200 device, make sure that the VM3200 is connected to LAN and that the app is connected to the same LAN and then try again.
Page 153 In the Control tab, you can instantly switch video inputs for each of the output. In the Audio tab, you can specify the audio input for the digital and analog outputs of the VM3200. Note: The fields available in this tab may vary for the connected device.
Page 154 VM3200 / VM3250 User Manual Control Interface Description In the Settings tab, you can look up notification for system firmware upgrades, the current app version, and technical support contact, or log out of the app.
Page 155: Cli Commands
RS-232 serial session and a list of commands. Connecting to the Matrix Switch via Telnet To establish a Telnet session with the VM3200 / VM3250, do the following: 1. Open a command-line interpreter program from your computer.
Page 156: Connecting To The Matrix Switch Via Rs-232
Connecting to the Matrix Switch via RS-232 You can control and operate the VM3200 / VM3250 using a high-end controller or PC. To connect to the VM3200 / VM3250 via RS-232, do the following: 1. Connect the RS-232 serial port on the VM3200 / VM3250 to the RS-232 serial port on your computer using a 9-wire straight cable, with only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 connected.
Page 157: Commands
Chapter 6. CLI Commands Commands After connecting to the VM3200 / VM3250 via Telnet or RS-232, you can operate the system using the following commands. Switch Port Command The formula for Switch commands is as follows: Switch Command + Input + Num1 + Output + Num2 + Address + Num3 + Stream + Control [Enter] 1.
Page 158: Switch Port Command
VM3200 / VM3250 User Manual Num2 Description All output ports Address Description Device address command (RS-422 and RS-485 only) Num3 Description Device address zz: 01~16 (default is 01) (RS-422 and RS-485 only) All devices Stream Description video Switch Video channel only...
Page 159 Chapter 6. CLI Commands The following table shows the available command list: Input Output Device Command Input Output Address Stream Control Enter Description Port Port video [Enter] Switch Input Port xx to Output Port yy on Address zz audio xx:01~32 * yy:01~32, * zz: 01~16, * video...
Page 160: Mute Command
VM3200 / VM3250 User Manual Mute Command Mute allows you to enable or disable an output port(s) audio. The Mute command will turn on/off the HDMI audio and stereo audio. When the HDMI audio is off, the stereo's volume can be adjusted using the volume command.
Page 161 Chapter 6. CLI Commands Control Description Mute off; audio on output port is enabled (default) Note: 1. Each command string can be separated with a space. 2. The Address command is for RS-422/485 only. If the address parameter is missing from RS-422/485 commands, the default a00 will be used.
Page 162: Volume Command
VM3200 / VM3250 User Manual Volume Command The volume command allows adjusts the stereo volume for an output port. The formula for the Volume command is as follows: Command + Output + Num1 + Address + Num2 + Volume + Control + [Enter] 1.
Page 163 Chapter 6. CLI Commands Control Description Audio volume level zz: 01~10 (default is 10) Note: 1. Each command string can be separated with a space. 2. The Address command is for RS-422/485 only. If the address parameter is missing from RS-422/485 commands, the default a00 will be used.
Page 164 VM3200 / VM3250 User Manual Save/Load Profile Commands The Save/Load Profile command allows you to save the current connection configuration as a profile and load connection profiles. The formula for Save/Load Profile commands is as follows: Command + Profile + Num1 + Address + Num2 + Control + [Enter] 1.
Page 165: Save/Load Profile Commands
Chapter 6. CLI Commands Control Description load Load a saved profile Note: 1. Each command string can be separated with a space. 2. The Address command is for RS-422/485 only. If the address parameter is missing from RS-422/485 commands, the default a00 will be used.
Page 166 Port 1, and pass it to the video source. remix Implement the EDID of each connected display according to its connection when the VM3200 / VM3250 is first powered on, or immediately after selecting the Remix option. default Implements ATEN’s default EDID.
Page 167: Edid Mode Command
[Enter] The EDID from Port 1 is passed to the video source. zz: 01~16 edid remix [Enter] The VM3200 / VM3250 implements the EDID of each connected display according to its connection when the device is first powered on, or immediately after selecting the Remix option.
Page 168: Cec Command
VM3200 / VM3250 User Manual CEC Command Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to the same remote control. The formula for the CEC command is as follows: Command + Output + Number + Control + [Enter] 1.
Page 169: Read Command
Chapter 6. CLI Commands Read Command The Read command allows you to view information about the devices. The formula for the Read command is as follows: Command + Address + Number + [Enter] 1. To view information, type: read [Enter] 1.
Page 170 VM3200 / VM3250 User Manual How to read the commands: 1. o01 i03 video on i06 audio v10 HDMI-a on 1080p Output 01 is connected to Input 03 with video on; audio is on from Input 06 with volume 10 using the HDMI audio source; the resolution is scaled to 1080p 2.
Page 171: Reset Command
Chapter 6. CLI Commands Reset Command The Reset command allows you to reset the VM3200 / VM3250 back to the default factory settings. Reset includes resetting the devices IP address. The formula for the Reset command is as follows: Command + Address + Number + [Enter] 1.
Page 172: Baud Rate Command
Baud Rate Command The Baud Rate command allows you to set the RS-232 data rate for the VM3200 / VM3250 to use. Options are 9600, 19200 (default) 38400 and 115200. The formula for the Baud Rate command is as follows: Command + Control + [Enter] 1.
Page 173: Osd Command
Chapter 6. CLI Commands OSD Command To enable or disable the On-Screen Display (OSD) for displays, use the following command: Command + Output + Number + Control + [Enter] 1. For example, to enable the OSD for output 07, type: osd o07 on [Enter] 2.
Page 174: Echo Command
VM3200 / VM3250 User Manual Echo Command The Echo function updates the RS232 controller when operations are made via the front panel pushbuttons, web browser or telnet. The changes echo back to the RS232 controller to keep the settings in sync with the device.
Page 175: Scaling Command
Chapter 6. CLI Commands Scaling Command The Scaling command allows you to set a resolution for scaling the display connected to an output port. The formula for the Scaling command is as follows: Command + Output + Number 1 + Address + Number 2 + Horizontal Resolution + Number 3+ Vertical Resolution + Number 4 + Frequency + Number 5 + Control + [Enter] 1.
Page 176 VM3200 / VM3250 User Manual Horizontal Description Resolution Horizontal resolution command for scaling Resolution Number Description hhhh Horizontal resolution Vertical Resolution Description Vertical resolution command for scaling Resolution Number Description vvvv Vertical resolution Frequency Description freq Frequency command for scaling...
Page 177 Chapter 6. CLI Commands 3. The Port Number command string can be skipped, and the default value will be used. The following table lists the available Scaling commands: Hori Verti Freq zont Out N1 Add Description scaling freq Turn off ter] scaling for output yy...
Page 178 VM3200 / VM3250 User Manual Hori Verti Freq zont Out N1 Add Description scaling hor 12 freq Scale ter] output yy device zz 1280x720 @60Hz yy: 01~32 or * zz: 01~16 or * scaling hor 19 1200 freq Scale ter]...
Page 179 Chapter 6. CLI Commands Hori Verti Freq zont Out N1 Add Description scaling hor 12 1024 freq Scale ter] output yy device zz 1280x102 4@60Hz yy: 01~32 or * zz: 01~16 or * scaling hor 10 freq Scale ter] output yy device zz 1024x768 @60Hz...
Page 180: Fan Speed Command
VM3200 / VM3250 User Manual Fan Speed Command The Fan Speed command allows you to set the VM3200 / VM3250’s internal fan speed. To set the fan speed, use the following command: Command + Control + [Enter] 1. For example, to set the fan to auto detect, type:...
Page 181: Alert Command
Chapter 6. CLI Commands Alert Command To trigger a warning when issues arise for a specific input port, use the following command: Command + Input + Number + Control + [Enter] 1. For example, to enable the basic Alert function for input port 1, type: alert i01 m1 [enter] The following tables show the possible values for the Alert command: Command...
Page 182: Framesync Command
VM3200 / VM3250 User Manual FrameSync Command The FrameSync command allows you enable or disable the Frame Synchronization function on the VM3200 / VM3250. Note: This feature is only supported by VM8814. The formula for the Frame Synchronization command is as follows:...
Page 183: Long Reach Mode Command
Chapter 6. CLI Commands Long Reach Mode Command Long Reach Mode allows you to extend the maximum transmission distance to 150m. Note: This feature is only supported by VM8514. The formula for the Long Reach Mode command is as follows: Command + Output<port_number>...
Page 184 VM3200 / VM3250 User Manual This Page Intentionally Left Blank...
Page 185: Appendix
Appendix Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. This product is for indoor use only. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result.
Page 186 VM3200 / VM3250 User Manual If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
Page 187: Rack Mounting
Appendix Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack.
Page 188: Technical Support
VM3200 / VM3250 User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For telephone support, see Telephone Support, page xi: North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support Technical Documentation Support Software Updates...
Page 189: Specifications
Appendix Specifications VM3250 Input and Output Boards Board Input 8 x Slot Board Output 8 x Slot Video Input Interfaces Depends on which I/O board is inserted Max. Data Rate 22.5 Gbps Audio Input Depends on which Input board is inserted Output Depends on which Output board is inserted Control...
Page 190 VM3200 / VM3250 User Manual Environmental Operating Temperature 0–40ºC Storage Temperature -20–60ºC Humidity 0–80% RH, Non-condensing Physical Properties Housing Metal Weight 18.20 kg (40.09 lb) Dimensions (L x W x H) 48.20 x 47.19 x 39.90 cm (18.98 x 18.58 x 15.71 in.)
Page 191: Vm3200
Appendix VM3200 Input and Output Boards Board Input 8 x Slot Board Output 8 x Slot Video Input Interfaces Depends on which I/O board is inserted Max. Data Rate 15.2 Gbps (3.8 Gbps per lane) Audio Input Depends on which Input board is inserted...
Page 192 VM3200 / VM3250 User Manual Environmental Operating Temperature 0–40ºC Storage Temperature -20–60ºC Humidity 0–80% RH, Non-condensing Physical Properties Housing Metal Weight 18.20 kg (40.09 lb) Dimensions (L x W x H) 48.20 x 47.19 x 39.90 cm (18.98 x 18.58 x 15.71 in.)
Page 193: Vm7584 / Vm8584
Appendix VM7584 VM8584 VM7584 VM8584 Fiber Optics Date Rate 10.3 Gbps Wavelength VM7584K1: 850 nm VM8584K1: 850 nm VM7584K2: 1310 nm VM8584K2: 1310 nm Fiber Type VM7584K1: Multimode (MM), VM8584K1: Multimode (MM), OM3, LC Duplex Type OM3, LC Duplex Type VM7584K2: Single-mode (SM), VM8584K2: Single-mode (SM), LC Duplex Type...
Page 194 The operating distance may vary depending on the fiber type, network bandwidth, connector splicing, signal losses, modal or chromatic dispersion, environmental factors, and kinks. ATEN recommends using single-mode optical fibers that conform to IEC60793-2- 50 B1.1 or ITU-T G.652.B specifications; multimode optical fibers that conform to IEC11801 (OM3) specifications.
Page 195: Vm7514 / Vm8514
Appendix VM7514 / VM8514 VM7514 VM8514 Video Input Interfaces 4 x RJ-45 Female (Silver) Impedance 100 Ώ Video Output Interfaces 4 x RJ-45 Female (Silver) Impedance 100 Ώ Video Max. Data Rate 10.2 Gbps (3.4 Gbps per lane) Max. Pixel Clock 340 MHz Compliance HDBaseT, HDCP 1.4 compatible...
Page 196: Vm7904
VM3200 / VM3250 User Manual VM7904 Video Input Interfaces 4 x DisplayPort Female (Black) Impedance 100 Ώ Max. Distance Up to 3m Video Max. Data Rate 10.8 Gbps (2.7 Gbps Per Lane) Max. Pixel Clock 340 MHz Compliance HDCP Compatible Max.
Page 197: Vm7824 / Vm8824
Appendix VM7824 / VM8824 VM7824 VM8824 Video Input Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Max. Distance Up to 3.0 m Video Output Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Up to 3.0 m Video Max.
Page 198: Vm7814 / Vm8814
VM3200 / VM3250 User Manual VM7814 / VM8814 VM7814 VM8814 Video Input Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Max. Distance Up to 5m Video Output Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ...
Page 199: Vm7804 / Vm8804
Appendix VM7804 / VM8804 VM7804 VM8804 Video Input Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Video Output Interfaces 4 x HDMI Type A Female (Black) Impedance 100 Ώ Video Max. Data Rate 6.75 Gpbs (2.25 Gbps per Lane) Max.
Page 200: Vm7604 / Vm8604
VM3200 / VM3250 User Manual VM7604 / VM8604 VM7604 VM8604 Video Input Interfaces 4 x DVI-D Female (White) Impedance 100 Ώ Video Output Interfaces 4 x DVI-D Female (White) Impedance 100 Ώ Video Max. Data Rate 6.75 Gpbs (2.25 Gbps per Lane) Max.
Page 201: Vm7104
Appendix VM7104 Video Input Interfaces 4 x HDB-15 Female (Blue) Impedance 75 Ώ Max. Bandwidth 300 MHz Max. Resolution 1920 x 1200 Max. Distance 1.8 m Audio Input Interfaces 4 x Captive Screw Connector, 5 Pole Audio Signal Type stereo, balanced, unbalanced* Power Consumption 7.1W...
Page 202: Vm7404
VM3200 / VM3250 User Manual VM7404 Video Input Interfaces 4 x BNC Female Impedance 75 Ώ Video Supported Resolutions PAL /50 PAL and NTSC/59.94 720p 25, 29.97, 30,50,59.94, 60 1080i 50, 59.94, 60 1080PsF 25, 29.97,30 1080p 23.98, 24, 25, 29.97, 30,50,59.94, 60 Max.
Page 203: Ve805R
Appendix VE805R Video Input Interfaces 1 x RJ-45 Female (Silver) Impedance 100 Ώ Video Output Interfaces 1 x HDMI Type A Female (Black) Impedance 100 Ώ Video Max. Data Rate 6.75 Gpbs (2.25 Gbps per Lane) Max. Pixel Clock 225 MHz Compliance HDMI (3D, Deep Color) HDCP 1.4 Compatible...
Page 204: Ve816R
HDMI (3D, 4K, Deep Color) HDCP 2.2 Compatible HDBaseT Compatible Max. Resolution / Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Distance Cat6); 1080p@100m (Cat 5e/6/6a) *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);...
Page 205: Vm-Pwr800
Appendix Weight 0.67 kg (1.48 lb) Dimensions (L x W x H) 16.80 x 14.69 x 3.00 cm with bracket (6.61 x 5.78 x 1.18 in.) Dimensions (L x W x H) 16.60 x 12.49 x 2.90 cm without bracket (6.54 x 4.92 x 1.14 in.) VM-PWR800 Properties...
Page 206: Telnet Operation
The VM3200 can be operated and configured via a remote terminal session using Telnet. To log into the VM3200 by means of a Telnet session, do the following: 1. On your computer, open a terminal (command line) session. 2. At the prompt, key in the VM3200’s IP address in the following way: telnet [IP address]:23 3.
Page 207: Ip - Set Ip Address
Appendix 2. IP – Set IP address Old IP address: 192.168.0.60 New IP address: 3. LO – Load connections from profile LO 01 Load profile 01 OK. 4. PW – Change password Old password: ******** New password: 5. RI – Read what input is connected to nn output RI 01 Input port 02 04 08 is connected to output port 01 6.
Page 208: 9. Sv - Save The Current Connections Into A Profile
VM3200 / VM3250 User Manual 9. SV – Save the current connections into a profile SV 01 Save the current connections into profile 01 10. TI – Set timeout TI 30 Set 30 minute timeout 11. VR – Software version information Software version 1.0.
Page 209: Limited Warranty
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.

This manual is also suitable for:

Vm3250

ATEN VM3200 User Manual

Introduction

Hardware Setup

Front Panel Operation

Browser Operation

Mobile Control

CLI Commands

Appendix

Quick Links

Related Manuals for ATEN VM3200

Summary of Contents for ATEN VM3200

This manual is also suitable for:

Table of Contents
