Summary of Contents for ATEN VM0404HA
- Page 1 4K HDMI Matrix Switch USER MANUAL VM0404HA...
-
Page 2: Emc Information
EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
Any other information you feel may be of help. International For online technical support – including troubleshooting, documentation, and software updates, go to http://eservice.aten.com For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 - 3 -... -
Page 4: User Notice
Documentation Support Software Updates Telephone Support 1-888-999-ATEN ext 4988 User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The manufacturer makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties as to merchantability or fitness for any particular purpose. -
Page 5: Package Contents
® Copyright © 2020 ATEN International Co., Ltd. Manual Date: 2020-02-12 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 5 -... - Page 6 Overview The ATEN VM0404HA, a 4x4 4K HDMI Matrix Switch supports up to 4K resolutions, including UHD (3840 x 2160) and DCI (4096 x 2160), and refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0). Ready for future high-...
- Page 7 HDMI (3D, Deep Color, 4K) and HDCP 1.4 compatible Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to a single remote control Supports ATEN LockPro™ HDMI cable lock for securing HDMI cables ESD protection for HDMI ports...
-
Page 8: System Requirements
Contact your dealer to purchase the correct cable sets. 2. If you wish to utilize the VM0404HA’s high-end serial controller function, you will need to purchase an appropriate RS-232 cable. See Installing the RS-232 Controller, page 13. - Page 9 Input These pushbuttons refer to the HDMI Input ports Pushbuttons found on the VM0404HA rear panel. Press to select the Input port and display the connected Output ports which are indicated by the Orange LED lights. When an Input pushbutton is pressed you can press one or multiple Output pushbuttons to connect them to the selected input source.
- Page 10 VM0404HA Rear View Component Function Grounding The grounding wire attaches here. See Grounding, Terminal page 11, for further details. Power Switch This is a standard rocker switch that powers the unit on and off. Power Jack This is the DC power jack. The power cord from a power source plugs in here.
-
Page 11: Ir Remote Control
IR Remote Control Component Function Power ON/OFF Use the ON and OFF pushbuttons to turn the Output displays on or off – by individual port, or all ports. See IR Remote Selection, page 16 for details. Output Press Output pushbuttons 1–4 to select the display Pushbuttons you want to configure, then within 2 seconds press the Input pushbutton 1–4 to select the source for the... -
Page 12: Installation
HDMI Out ports on the rear of the VM0404HA. 4. Use HDMI cables to connect the HDMI Out ports on the source device(s) to the HDMI In ports on the VM0404HA. Four HDMI In ports are located on the rear of the switch. -
Page 13: Installing The Rs-232 Controller
Installing the RS-232 Controller In order to use the RS-232 serial interface to attach a high-end controller (such as a PC) to the VM0404HA, use an appropriate serial cable (such as a modem cable). The end connecting to the VM0404HA should have a 9-pin male connector. -
Page 14: Rack Mounting
Keyboard Power On function. The VM0404HA can be mounted in a 19” (1U) system rack. For the most convenient front panel pushbutton configuration and operation at the local site, mount the unit at the front of the rack, as follows: 1. - Page 15 3. Screw the mounting brackets to the rack. - 15 -...
-
Page 16: Local Operations
VM0404HA via the front panel pushbuttons and IR remote control. Note: Before using the IR remote control, make sure you have plugged the IR External Receiver into the VM0404HA and place the device where IR signals can be received. To remotely operate the system, see RS-232 Serial Interface, page 20 for details. -
Page 17: Assigning Sources
Assigning Sources To assign a source by first selecting the display(s), follow the steps below. 1. On the device panel or the IR remote control, press one or multiple Output pushbuttons (1–4) to select the display(s) to which you wish to assign a particular source. - Page 18 Power on/off Individual Displays 1. On the IR remote control, press the Output pushbutton (1–4) you want to power on/off. 2. Within 2 seconds, press the ON or OFF pushbutton. Note: If the ON or OFF pushbutton is not pressed within 2 seconds, the output you selected in step 1 loses effect and all the displays will be powered on/off as you pressed the pushbutton.
-
Page 19: Firmware Upgrades
2. Save and unzip the VM0404HA_upgrade_tool.exe (upgrade file) to your computer. 3. Connect the computer to the VM0404HA’s Micro USB port via a USB cable. 4. Power on the VM0404HA. 5. After a few seconds, double click the VM0404HA_upgrade_tool.exe file to start the firmware upgrade process, and a window appears: 6. -
Page 20: Rs-232 Serial Interface
RS-232 Serial Interface The VM0404HA’s built-in bi-directional RS-232 serial interface allows system control through a high-end controller, PC, and/or home automation / home theater software package. Configuring the Serial Port The controller’s serial port should be configured as follows: Baud Rate... - Page 21 Output Command Description Output command Output Port Number Description 01-04 port (default is 01) All output ports Control Description Turn on Turn off Next port Previous port Note: 1. Each command string can be separated with a space. 2. The Port Number command string can be skipped, and the default value will be used.
-
Page 22: Read Commands
EDID Echo Commands If the Echo feature is enabled: for each action from the front panel (pushbuttons) or IR interface, the VM0404HA sends a corresponding acknowledgment message to the attached controller or management device via the RS-232 port. -
Page 23: Cec Commands
CEC Commands Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control. The formula for CEC mode selection commands is as follows: CEC Command + Output Command + Port Number + Control (Off / On) [Enter] For example, to enable CEC function on output port 1, type the following: cec o01 on [enter] The following tables show the possible values for commands:... -
Page 24: Panel Button Control Commands
Panel Button Control Commands The formula for Panel Button commands is as follows: Panel Button Command + Control + [Enter] For example, to enable the front panel pushbuttons, type the following: button on [Enter] The following tables show the possible values for commands: Command Description button... -
Page 25: Edid Mode Selection Commands
Extended Display Identification Data (EDID) is a data format that contains a display's basic information and is used to communicate with the video source/system. You can set which EDID mode the VM0404HA uses with the following command: EDID Command + Control + [Enter]... -
Page 26: Rs-232 Pin Assignment
RS-232 Pin Assignment Description Description Not connected Not connected Not connected Not connected Not connected Not connected - 26 -... -
Page 27: Safety Instructions
Safety Instructions General Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. This product is for indoor use only. Do not place the device on any unstable surface (cart, stand, table, etc.). - Page 28 Never push objects of any kind into or through cabinet slots. They may touch dangerous voltage points or short out parts resulting in a risk of fire or electrical shock. Do not attempt to service the device yourself. Refer all servicing to qualified service personnel.
- Page 29 Make sure that all equipment used on the rack – including power strips and other electrical connectors – is properly grounded. Ensure that proper airflow is provided to devices in the rack. Ensure that the operating ambient temperature of the rack environment does not exceed the maximum ambient temperature specified for the equipment by the manufacturer.
-
Page 30: Specifications
Specifications Video Input Interface 4 x HDMI Type A Female (Black) Impedance 100 Ώ Max Distance 1.8 m Video Output Interface 4 x HDMI Type A Female (Black) Impedance 100 Ώ Max Distance 15 m Video Max Data Rate 10.2 Gbps (3.4 Gbps Per Lane) Max Pixel Clock 340 MHz Compliance... - Page 31 EDID Settings EDID Modes: Default / Port1 / Remix Power Connectors 1 x DC Jack (Black) Consumption 5 VDC, 10.58 W Environmental Operating Temperature 0 - 40° C Storage Temperature -20 - 60° C Humidity 0 - 80% RH, Non-Condensing Physical Properties Housing Metal...
-
Page 32: Limited Warranty
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
