Instruction Manual
DAB+ FM/AM Portable Radio - BR-70DABB

Advertisement

Table of Contents
loading

Related Manuals for Blaupunkt BR-70DABB

Summary of Contents for Blaupunkt BR-70DABB

  • Page 1 Instruction Manual DAB+ FM/AM Portable Radio - BR-70DABB...

  • Page 3: Table Of Contents

    CONTENTS General Safety Product Overview Basic Operation Positioinig your DAB FM/AM Portable Radio Switch on Time and Date Using Headphones DAB Radio Mode Scanning for DAB Stations FM Radio Mode Audio Mode AM Radio Mode Storing AM Preset Sleep Timer Display Language Troubleshooting Specification...
  • Page 4 GENERAL SAFETY Read this manual thoroughly before you start using the radio. Store this manual, the completed warranty card, your receipt and the product packaging. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings.
  • Page 5 GENERAL SAFETY (CONT.) • If you notice any unusual odors or smoke around the unit, immediately disconnect the unit. • The product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or young children of any age, They must be supervised product by a person responsible for their safety.

  • Page 6: Product Overview

    PRODUCT OVERVIEW Preset store 1 LCD display Preset store 2 Menu / Info. Preset store 3 Preset set Preset store 4 Mode: AM/DAB/FM Preset store 5 Enter/Auto Scan/ Display On/Off/Standy Tune Up Volume +/- Tune Down Speaker...

  • Page 7: Basic Operation

    BASIC OPERATION PLEASE MAKE SURE NOT TO USE YOUR DAB+ FM/AM PORTABLE RADIO WHILE CHARGING THE UNIT. 100% CHARGE THE UNIT WITH THE MICRO USB CABLE THEN UNPLUG AND TURN ON THE RADIO BEFORE FIRST USE. DO NOT USE RADIO WHILE CHARGING, RADIO INTERFERENCE MAY OCCUR WHILE DOING SO.

  • Page 8: Switch On

    BASIC OPERATION (CONT.) Switch On Press and release the Power button on the top of your radio. Your radio will switch on to Standby Mode, short press the Power button and begin an automatic scan for DAB Stations. A progress bar will show the status of the scan and the number of stations found.

  • Page 9: Time And Date

    BASIC OPERATION (CONT.) Time and Date The time is normally set automatically after an auto scan. It can also be set manually. In the System menu scroll to Time. Press ENTER (13) and use the TUNING dial (2) to display the following options: <Set Time/Date>, <Auto update>, <Set 12/24 hour>,...

  • Page 10: Dab Radio Mode

    BASIC OPERATION (CONT.) Storing a DAB/FM/AM station 1-5 preset Your Radio can store up to 5 direct access radio stations in its preset buttons located at the top of the radio for instant access to your favourite stations. While on your favourite radio station on either DAB/FM/AM mode, press and hold any of the preset buttons number 1-5 at the top of the unit.
  • Page 11 BASIC OPERATION (CONT.) Storing an DAB station preset Your Radio can store up to 30 DAB stations in its preset memories for instant access to your favourite stations. Tune the Radio to the DAB station that you wish to preset. Press and hold the PRESET button for approximately 2 seconds until Preset Store <1:(Empty)>...

  • Page 12: Fm Radio Mode

    BASIC OPERATION (CONT.) FM Radio Mode If you are not already in FM mode, press DAB/FM button to go to FM mode (check the display). If you were listening to an FM station when you switched the Radio off then this station will be automatically selected when you switch the Radio back on.

  • Page 13: Audio Mode

    BASIC OPERATION (CONT.) Audio Mode The radio will automatically switch between Stereo and Mono, depending on the quality of the signal being received but you can override this function and manually switch between ‘Forced Mono’ and ‘Stereo Allowed’. Note: As this is a Mono radio, you may wish to only select the ‘Stereo Allowed’ option if you are listening to your radio using headphones.

  • Page 14: Am Radio Mode

    BASIC OPERATION (CONT.) AM Radio Mode If you are not already in AM mode, press and release the Mode button to go to AM mode (check the display). There are 20 memory presets for AM radio. The operation for presetting stations and recalling a preset in AM mode is same as DAB/FM modes.

  • Page 15: Display Language

    BASIC OPERATION (CONT.) Display Language You can change the display language of your radio, there are 4 options available; English, French, German and Italian. An ‘*’ will be displayed next to the current setting. With your radio switched on (not in Standby mode): Press and hold the MENU button to enter the menu options Use arrow buttons to scroll to <System>.

  • Page 16: Troubleshooting

    SPECIFICATIONS Problem Solutions Radio reception is Check that Adjust the Check that the poor the antenna is antenna direction radio is not close extended for the to improve the to microwaves, maximum signal signal. Move the fluorescent lights strength and radio closer to a or other improved...
  • Page 17 THIS PAGE HAS BEEN LEFT BLANK ON PURPOSE.
  • Page 18 THIS PAGE HAS BEEN LEFT BLANK ON PURPOSE.
  • Page 19 THIS PAGE HAS BEEN LEFT BLANK ON PURPOSE.
  • Page 20 CUSTOMER HELPLINE: info@ayonz.com DISTRIBUTED BY: Ayonz Pty Ltd...
